Page 4577 of 4647
WT-28
TROUBLE DIAGNOSES
Revision: 2007 April2007 M35/M45
DIAGNOSIS CHART BY SYMPTOM
Symptom Reference
Warning lamp does not come on when ignition switch is turned on.WT-35, "
Warning Lamp Does Not Come On When
Ignition Switch Is Turned ON"
Warning lamp stay on when ignition switch turned on.WT-35, "Warning Lamp Stay On When Ignition
Switch Is Turned ON"
Warning lamp blinks 1 min and then turns on when ignition switch is turned on.WT-36, "Warning Lamp Blinks 1 Minute and Then
Turns ON When Ignition Switch Is Turned ON"
Warning lamp blinks when ignition switch is turned on.WT-37, "Warning Lamp Blinks When Ignition Switch
Is Turned ON"
Turn signal lamp blinks when ignition switch is turned on.WT-38, "Turn Signal Lamp Blinks When Ignition
Switch Is Turned ON"
ID registration can not be operated.WT-38, "ID Registration Can Not Be Completed"
Page 4578 of 4647

TROUBLE DIAGNOSIS FOR SYSTEM
WT-29
C
D
F
G
H
I
J
K
L
MA
B
WT
Revision: 2007 April2007 M35/M45
TROUBLE DIAGNOSIS FOR SYSTEMPFP:00000
Transmitter no DataNES000KA
MALFUNCTION CODE NO. 21, 22, 23, 24
1. CHECK CONTROL UNIT
Drive for several minutes. Check all tire pressures with CONSULT-II “DATA MONITOR”.
Are all tire pressures displayed 0 kPa?
YES >> GO TO 2.
NO >> GO TO 3.
2. CHECK TIRE PRESSURE RECEIVER CONNECTOR
1. Disconnect tire pressure receiver harness connector E74 (FR-LH), E75 (FR-RH), B482 (RR-RH), B115
(RR-LH).
2. Check terminals for damage or loose connection.
3. Reconnect harness connector.
OK or NG
OK >> Replace low tire pressure warning control unit. Refer to WT-40, "Low Tire Pressure Warning Con-
trol Unit" , then GO TO 3.
NG >> Repair or replace tire pressure receiver harness connector.
3. ID REGISTRATION
Perform ID registration of all transmitters.
Are there any tires that ID can not be registered to?
YES >> Replace transmitter of the tire, then GO TO 5.
NO >> GO TO 4.
4. VEHICLE DRIVING
Drive at a speed of 40 km/h (25 MPH) or more for several minutes without stopping.
Check all tire pressures with CONSULT-II “DATA MONITOR” within 15 minutes after vehicle speed becomes
17 km/h (11 MPH).
Does
“DATA MONITOR ” display tire pressure as normal without any warning lamp?
YES >>INSPECTION END
NO >> GO TO 5.
5. ID REGISTRATION AND VEHICLE DRIVING
1. Perform ID registration of all transmitters.
2. Drive at a speed of 40 km/h (25 MPH) or more for 3 minutes, and then drive the vehicle at any speed for
10 minutes. Then check all tire pressures with CONSULT-II “DATA MONITOR” within 5 minutes.
Does
“DATA MONITOR” display tire pressure as normal without any warning lamp?
YES >>INSPECTION END
NO >> GO TO the inspection applicable to DTC.
Page 4579 of 4647

WT-30
TROUBLE DIAGNOSIS FOR SYSTEM
Revision: 2007 April2007 M35/M45
Receiver Data ErrorNES000KB
MALFUNCTION CODE NO. 25, 26, 27, 28
1. CHECK LOW TIRE PRESSURE WARNING CONTROL UNIT AND RECEIVER CONNECTOR
1. Turn ignition switch OFF, disconnect low tire pressure warning control unit harness connector and receiver
harness connector, and check terminal for deformation, disconnection, looseness, and so on. If there is a
malfunction, repair or replace the terminal.
2. Reconnect harness connector securely, and perform self-diagnosis.
Does
“SELF-DIAG RESULTS” display as normal without any warning lamp?
YES >> Connector terminal connection is loose, damaged, open, or shorted.
NO >> GO TO 2.
2. CHECK TIRE PRESSURE RECEIVER POWER SUPPLY AND GROUND CIRCUIT
1. Turn ignition switch OFF, and disconnect tire pressure receiver harness connector E74, E75, B115, B482.
2. Check continuity between tire pressure receiver harness con-
nector E74, E75, B115, B482 and ground.
3. Turn ignition switch ON, and then check voltage between tire
pressure receiver harness connector E74, E75, B115, B482 and
ground.
OK or NG
OK >> GO TO 3.
NG >> GO TO 4.
3. CHANGE THE TIRE PRESSURE RECEIVER POSITION (EXAMPLE OF FRONT LH SIDE)
1. Replace right from left for front and rear receivers.
2. Perform self-diagnosis.
Is the initial indication of self-diagnosis displayed?
YES >> GO TO 4
NO >> Replace tire pressure receiver front RH when indicating RH tire pressure receiver malfunction.Terminal 4 – Ground : Continuity should exist.
SGIA1249E
1 – Ground : Battery voltage (Approx.12 V)
SGIA1250E
Page 4580 of 4647

TROUBLE DIAGNOSIS FOR SYSTEM
WT-31
C
D
F
G
H
I
J
K
L
MA
B
WT
Revision: 2007 April2007 M35/M45
4. CHECK RECEIVER HARNESS (EXAMPLE OF FRONT LH SIDE)
1. Turn ignition switch OFF, disconnect low tire pressure warning
control unit harness connector M19 (A) and receiver harness
connector E74 (B).
2. Check continuity between low tire pressure warning control unit
harness connector M19 (A) and receiver harness connector E74
(B).
OK or NG
OK >> Replace low tire pressure warning control unit.
NG >> Harness between Low tire warning control unit and receiver open or shorted. Repair or replace
harness.
Transmitter Pressure Data ErrorNES000KC
MALFUNCTION CODE NO. 35, 36, 37, 38
1. CHECK ALL TIRE PRESSURES
Check all tire pressures. Refer to WT-41, "
SERVICE DATA AND SPECIFICATIONS (SDS)" .
Are there any tires whose pressure is
“64 psi” or more?
YES >> Adjust tire pressure to specified value.
NO >> GO TO 2.
2. VEHICLE DRIVING
1. Perform ID registration of all transmitters.
2. Drive at a speed of 40 km/h (25 MPH) or more for several minutes without stopping.
Check all tire pressures with CONSULT-II “DATA MONITOR” within 15 minutes after vehicle speed
becomes 17 km/h (11 MPH).
>> Replace tire pressure transmitter with new one if “DATA MONITOR” display 64 psi or more. Then
GO TO 3.
3. ID REGISTRATION AND VEHICLE DRIVING
1. Perform ID registration of all tire pressure transmitters.
2. Drive at a speed of 40 km/h (25 MPH) or more for 3 minutes, and then drive the vehicle at any speed for
10 minutes. Then check all tire pressures with CONSULT-II “DATA MONITOR” within 5 minutes.
Does
“DATA MONITOR” display tire pressure as normal without any warning lamp?
YES >>INSPECTION END
NO >> GO TO the inspection applicable to DTC.Terminal 27 – 2 : Continuity should exist.
Terminal 11 – 3 : Continuity should exist.
SEIA0789E
Page 4581 of 4647

WT-32
TROUBLE DIAGNOSIS FOR SYSTEM
Revision: 2007 April2007 M35/M45
Transmitter Function Code ErrorNES000KD
MALFUNCTION CODE NO. 41, 42, 43, 44
1. ID REGISTRATION (CORRECTION OF TRANSMITTER LOCATION)
1. Perform ID registration of all transmitters.
2. Drive at a speed of 40 km/h (25 MPH) or more for 3 minutes, and then drive the vehicle at any speed for
10 minutes.
>> GO TO 2.
2. REPLACE TIRE PRESSURE TRANSMITTER
1. Check low tire pressure warning lamp condition again, and replace malfunctioning tire pressure transmit-
ter.
2. Perform ID registration of all transmitter.
Can ID registration of all tire pressure transmitters be completed?
YES >> GO TO 3.
NO >> GO TO WT-29, "
Transmitter no Data" .
3. VEHICLE DRIVING
Drive at a speed of 40 km/h (25 MPH) or more for 3 minutes, and then drive the vehicle at any speed for 10
minutes. Then check all tire pressures with CONSULT-II “DATA MONITOR” within 5 minutes.
Does
“DATA MONITOR” display tire pressure as normal without any warning lamp?
YES >>INSPECTION END
NO >> Replace malfunctioning transmitter, and perform “Step 3” again.
Transmitter Battery Voltage LowNES000KE
MALFUNCTION CODE NO. 45, 46, 47, 48
1. ID REGISTRATION (CORRECTION OF TRANSMITTER LOCATION)
1. Perform ID registration of all transmitters.
2. Drive at a speed of 40 km/h (25 MPH) or more for 3 minutes, and then drive the vehicle at any speed for
10 minutes.
>> GO TO 2.
2. REPLACE TIRE PRESSURE TRANSMITTER
1. Check low tire pressure warning lamp condition again, and replace malfunctioning tire pressure transmit-
ter.
2. Perform ID registration of all tire pressure transmitter.
Can ID registration of all tire pressure transmitters be completed?
YES >> GO TO 3.
NO >> GO TO WT-29, "
Transmitter no Data" .
3. VEHICLE DRIVING
Drive at a speed of 40 km/h (25 MPH) or more for 3 minutes, and then drive the vehicle at any speed for 10
minutes. Then check all tire pressures with CONSULT-II “DATA MONITOR” within 5 minutes.
Does
“DATA MONITOR” display tire pressure as normal without any warning lamp?
YES >>INSPECTION END
NO >> Replace malfunctioning transmitter, and perform “Step 3” again.
Page 4582 of 4647

TROUBLE DIAGNOSIS FOR SYSTEM
WT-33
C
D
F
G
H
I
J
K
L
MA
B
WT
Revision: 2007 April2007 M35/M45
Receiver ID No RegistrationNES000KF
MALFUNCTION CODE NO. 51
1. ID REGISTRATION
1. Perform ID registration of all tire pressure transmitters. Refer to WT-18, "
ID Registration Procedure" .
2. Drive at a speed of 40 km/h (25 MPH) or more for 3 minutes, and then drive the vehicle at any speed for
10 minutes.
>> GO TO 2.
2. REPLACE TIRE PRESSURE TRANSMITTER
1. Check low tire pressure warning lamp condition again, and replace malfunctioning tire pressure transmit-
ter.
2. Perform ID registration of all transmitter.
Can ID registration of all tire pressure transmitters be completed?
YES >> GO TO 3.
NO >> GO TO WT-29, "
Transmitter no Data" .
3. VEHICLE DRIVING
Drive at a speed of 40 km/h (25 MPH) or more for 3 minutes, and then drive the vehicle at any speed for 10
minutes. Then check all tire pressures with CONSULT-II “DATA MONITOR” within 5 minutes.
Does
“DATA MONITOR” display tire pressure as normal without any warning lamp?
YES >>INSPECTION END
NO >> Replace malfunctioning transmitter, and perform “Step 3” again.
Vehicle Speed SignalNES000KG
MALFUNCTION CODE NO. 52
1. CHECK SELF-DIAGNOSIS RESULTS
1. Perform “CONSULT-II Start Procedure”. Refer to GI-38, "
CONSULT-II Start Procedure" .
2. Touch “SELF-DIAG RESULTS” on “SELECT DIAG MODE” screen.
3. Check display contents in self-diagnostic results.
4.
Is above displayed on self-diagnosis display?
YES >>If “CAN COMM CIRCUIT [U1000]” is displayed, print out self-diagnosis. And then, go to LAN-
50, "CAN System Specification Chart" .
Replace low tire pressure warning control unit if “CONTROL UNIT [CAN] [U1010]” is displayed.
NO >> Check combination meter refer to DI-18, "
Trouble Diagnosis" .
Self-diagnostic results
CAN COMM CIRCUIT [U1000]
CONTROL UNIT [CAN] [U1010]
Page 4583 of 4647

WT-34
TROUBLE DIAGNOSIS FOR SYSTEM
Revision: 2007 April2007 M35/M45
Control Unit (EEPROM) MalfunctionNES000KT
MALFUNCTION CODE NO. 54
1. CHECK SELF-DIAGNOSIS RESULTS
1. Turn ignition switch “ON”. (Do not start engine.)
2. Select “SELF-DIAG RESULT” mode for “AIR PRESSURE MONITOR” with CONSULT-II.
3. Touch “ERASE”.
4. Turn ignition switch OFF, and wait at least 10 seconds.
5. Start engine.
6. Perform the self-diagnosis again.
Is the
“CONTROL UNIT (EEPROM) [C1754]” displayed?
YES >> Replace low tire pressure warning control unit. Refer to WT-40, "Low Tire Pressure Warning Con-
trol Unit" .
NO >>INSPECTION END
CAN Communication System MalfunctionNES000KS
1. CHECK LOW TIRE PRESSURE WARNING CONTROL UNIT CONNECTOR
1. Turn ignition switch OFF, disconnect low tire pressure warning control unit harness connector, and check
terminal for deformation, disconnection, looseness, etc.
2. Reconnect harness connector securely, and perform CONSULT-II self-diagnosis.
Is above displayed on self-diagnosis display?
YES >>If “CAN COMM CIRCUIT [U1000]” is displayed, print out self-diagnosis. And then, go to LAN-
50, "CAN System Specification Chart" .
Replace low tire pressure warning control unit if “CONTROL UNIT [CAN] [U1010]” is displayed.
NO >> Connector terminal connection is loose, damaged, open, or shorted. Repair or replace the termi-
nal.
Self-diagnostic results
CAN COMM CIRCUIT [U1000]
CONTROL UNIT [CAN] [U1010]
Page 4584 of 4647

TROUBLE DIAGNOSIS FOR SYMPTOMS
WT-35
C
D
F
G
H
I
J
K
L
MA
B
WT
Revision: 2007 April2007 M35/M45
TROUBLE DIAGNOSIS FOR SYMPTOMSPFP:00007
Warning Lamp Does Not Come On When Ignition Switch Is Turned ONNES000KH
1. CHECK SELF-DIAGNOSIS RESULTS
1. Perform “CONSULT-II Start Procedure”. Refer to GI-38, "
CONSULT-II Start Procedure" .
2. Touch “SELF-DIAG RESULTS”.
3. Check display contents in self-diagnostic results.
Is above displayed on self-diagnosis display?
YES >>If “CAN COMM CIRCUIT [U1000]” is displayed, print out self-diagnosis. And then, go to LAN-
50, "CAN System Specification Chart" .
Replace low tire pressure warning control unit if “CONTROL UNIT [CAN] [U1010]” is displayed.
NO >> GO TO 2.
2. CHECK COMBINATION METER
Check combination meter function.
OK or NG
OK >> GO TO 3.
NG >> Check combination meter. Refer to DI-18, "
Trouble Diagnosis" .
3. CHECK LOW TIRE PRESSURE WARNING LAMP
Disconnect low tire pressure warning control unit harness connector M19.
Does the warning lamp activate?
YES >> Replace low tire pressure warning control unit. Refer to WT-40, "Low Tire Pressure Warning Con-
trol Unit" .
NO >> Check combination meter and repair or replace.
Warning Lamp Stay On When Ignition Switch Is Turned ONNES000KW
1. CHECK ALL TIRE PRESSURES
Check all tire pressures. Refer to WT-41, "
SERVICE DATA AND SPECIFICATIONS (SDS)" .
OK or NG
OK >> Check combination meter. Refer to DI-5, "COMBINATION METERS" .
NG >> Adjust tire pressure to specified value.
Self-diagnostic results
CAN COMM CIRCUIT [U1000]
CONTROL UNIT [CAN] [U1010]
