INFINITI M35 2007 Factory Service Manual BRC-20
[VDC/TCS/ABS]
TROUBLE DIAGNOSIS
Revision: 2007 April2007 M35/M45
TFWT0353E

Page 1322 of 4647

INFINITI M35 2007 Factory Service Manual TROUBLE DIAGNOSIS
BRC-21
[VDC/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
Revision: 2007 April2007 M35/M45
Control Unit Input/Output Signal StandardNFS000RH
REFERENCE VALUE FROM CONSULT-II
CAUTION:
The displa

TROUBLE DIAGNOSIS
BRC-21
[VDC/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
Revision: 2007 April2007 M35/M45
Control Unit Input/Output Signal StandardNFS000RH
REFERENCE VALUE FROM CONSULT-II
CAUTION:
The display shows ABS actuator and electric unit (control unit) calculation data, so a normal value
might be displayed even in the event the output circuit (harness) is open or short-circuited.
Monitor item Display contentData monitor
ConditionReference value in nor-
mal operation
FR LH SENSOR
FR RH SENSOR
RR LH SENSOR
RR RH SENSORWheel speedVehicle stopped 0 [km/h (MPH)]
Vehicle running (Note 1)Nearly matches the
speedometer display
(± 10 % or less)
STOP LAMP SW Brake pedal operationWhen brake pedal is depressed ON
When brake pedal is not depressed OFF
BATTERY VOLTBattery voltage supplied to the ABS
actuator and electric unit (control unit)Ignition switch ON 10 – 16 V
GEAR Gear position determined by TCM1st gear
2nd gear
3rd gear
4th gear
5th gear1
2
3
4
5
SLCT LVR POSI A/T select lever positionP position
R position
N position
D positionP
R
N
D
OFF SW VDC OFF switchVDC OFF switch :ON
(When VDC OFF indicator lamp is ON)ON
VDC OFF switch :OFF
(When VDC OFF indicator lamp is OFF)OFF
YAW RATE SENYaw rate detected by yaw rate/side G
sensorWhen vehicle stop Approx. 0 d/s
When vehicle turning (–75 to 75 d/s)
4WD MODE MON
(Note 2)AWD activated Engine running AUTO
ACCEL POS SIG Throttle actuator opening/closing is dis-
played (linked with accelerator pedal)Accelerator pedal not depressed
(Engine stopped)0 %
Depress accelerator pedal
(Engine stopped)0 - 100 %
SIDE G-SENSOR Transverse G detected by side G sensorVehicle stopped
Approx. 0 m/s
2
Vehicle turning rightNegative value
(m/s2 )
Vehicle turning leftPositive value
(m/s
2 )
STR ANGLE SIGSteering angle detected by steering
angle sensorStraight-ahead Approx. 0°
Steering wheel turned –720 to 720°
PRESS SENSORBrake fluid pressure detected by pres-
sure sensorWith ignition switch turned ON and brake
pedal releasedApprox. 0 bar
With ignition switch turned ON and brake
pedal depressed–40 to 300 bar
ENGINE RPM Engine speedWith engine stopped 0 rpm
Engine runningAlmost in accordance
with tachometer display
