INFINITI M35 2007 Factory Service Manual FL-14
SERVICE DATA AND SPECIFICATIONS (SDS)
Revision: 2007 April2007 M35/M45

Page 3106 of 4647

INFINITI M35 2007 Factory Service Manual FSU-1
FRONT SUSPENSION
E SUSPENSION
CONTENTS
C
D
F
G
H
I
J
K
L
M
SECTION FSU
A
B
FSU
Revision: 2007 April2007 M35/M45
FRONT SUSPENSION
2WD
PRECAUTIONS ................................................

FSU-1
FRONT SUSPENSION
E SUSPENSION
CONTENTS
C
D
F
G
H
I
J
K
L
M
SECTION FSU
A
B
FSU
Revision: 2007 April2007 M35/M45
FRONT SUSPENSION
2WD
PRECAUTIONS .......................................................... 3
Caution ..................................................................... 3
PREPARATION ........................................................... 4
Special Service Tools [SST] ..................................... 4
Commercial Service Tools ........................................ 4
NOISE, VIBRATION AND HARSHNESS (NVH)
TROUBLESHOOTING ................................................ 5
NVH Troubleshooting Chart ..................................... 5
FRONT SUSPENSION ASSEMBLY ........................... 6
On-Vehicle Inspection .............................................. 6
INSPECTION OF UPPER LINK BALL JOINT
END PLAY ............................................................. 6
SHOCK ABSORBER INSPECTION ..................... 6
Wheel Alignment Inspection ..................................... 6
DESCRIPTION ...................................................... 6
PRELIMINARY CHECK ........................................ 6
GENERAL INFORMATION AND RECOMMEN-
DATIONS .............................................................. 6
THE ALIGNMENT PROCESS .............................. 7
INSPECTION OF CAMBER, CASTER AND
KINGPIN INCLINATION ANGLES ........................ 7
Components ............................................................. 8
Removal and Installation .......................................... 9
REMOVAL ............................................................. 9
INSTALLATION ................................................... 10
COIL SPRING AND SHOCK ABSORBER ................11
Removal and Installation ......................................... 11
REMOVAL ............................................................ 11
INSTALLATION .................................................... 11
Disassembly and Assembly .................................... 11
DISASSEMBLY .................................................... 11
INSPECTION AFTER DISASSEMBLY ............... 12
ASSEMBLY ......................................................... 12
TRANSVERSE LINK ................................................ 14
Removal and Installation ........................................ 14
REMOVAL ........................................................... 14
INSPECTION AFTER REMOVAL ....................... 14
INSTALLATION ................................................... 15UPPER LINK ............................................................. 16
Removal and Installation ........................................ 16
REMOVAL ........................................................... 16
INSPECTION AFTER REMOVAL ....................... 16
INSTALLATION ................................................... 16
STABILIZER BAR ..................................................... 18
Removal and Installation ........................................ 18
REMOVAL ........................................................... 18
INSPECTION AFTER REMOVAL ....................... 18
INSTALLATION ................................................... 18
SERVICE DATA AND SPECIFICATIONS (SDS) ...... 19
Wheel Alignment (Unladen *) ................................. 19
Ball Joint ................................................................. 19
Wheelarch Height (Unladen*) ................................. 20
AWD
PRECAUTIONS ........................................................ 21
Caution ................................................................... 21
PREPARATION ......................................................... 22
Special Service Tools [SST] ................................... 22
Commercial Service Tools ...................................... 22
NOISE, VIBRATION AND HARSHNESS (NVH)
TROUBLESHOOTING .............................................. 23
NVH Troubleshooting Chart ................................... 23
FRONT SUSPENSION ASSEMBLY ......................... 24
On-Vehicle Inspection ............................................. 24
INSPECTION OF UPPER LINK BALL JOINT
END PLAY ........................................................... 24
SHOCK ABSORBER INSPECTION .................... 24
Wheel Alignment Inspection ................................... 24
DESCRIPTION .................................................... 24
PRELIMINARY CHECK ....................................... 24
GENERAL INFORMATION AND RECOMMEN-
DATIONS ............................................................. 24
THE ALIGNMENT PROCESS ............................. 25
INSPECTION OF CAMBER, CASTER AND
KINGPIN INCLINATION ANGLES ....................... 25

Page 3107 of 4647

INFINITI M35 2007 Factory Service Manual FSU-2Revision: 2007 April2007 M35/M45 Components ........................................................... 26
Removal and Installation ........................................ 27
REMOVAL ..........

FSU-2Revision: 2007 April2007 M35/M45 Components ........................................................... 26
Removal and Installation ........................................ 27
REMOVAL ........................................................... 27
INSTALLATION .................................................... 28
COIL SPRING AND SHOCK ABSORBER ............... 29
Removal and Installation ........................................ 29
REMOVAL ........................................................... 29
INSTALLATION .................................................... 29
Disassembly and Assembly .................................... 29
DISASSEMBLY ................................................... 29
INSPECTION AFTER DISASSEMBLY ................ 30
ASSEMBLY ......................................................... 30
TRANSVERSE LINK ................................................. 32
Removal and Installation ........................................ 32
REMOVAL ........................................................... 32
INSPECTION AFTER REMOVAL ........................ 32
INSTALLATION .................................................... 33UPPER LINK ............................................................. 34
Removal and Installation ......................................... 34
REMOVAL ............................................................ 34
INSPECTION AFTER REMOVAL ........................ 34
INSTALLATION .................................................... 34
STABILIZER BAR ..................................................... 36
Removal and Installation ......................................... 36
REMOVAL ............................................................ 36
INSPECTION AFTER REMOVAL ........................ 36
INSTALLATION .................................................... 36
SERVICE DATA AND SPECIFICATIONS (SDS) ...... 37
Wheel Alignment (Unladen*) ................................... 37
Ball Joint ................................................................. 37
Wheelarch Height (Unladen*) ................................. 37

Page 3108 of 4647

INFINITI M35 2007 Factory Service Manual PRECAUTIONS
FSU-3
[2WD]
C
D
F
G
H
I
J
K
L
MA
B
FSU
Revision: 2007 April2007 M35/M45
[2WD]PRECAUTIONSPFP:00001
CautionNES000I6
When installing rubber bushings, the final tightening must be carried out

Page 3109 of 4647

INFINITI M35 2007 Factory Service Manual FSU-4
[2WD]
PREPARATION
Revision: 2007 April2007 M35/M45
PREPARATIONPFP:00002
Special Service Tools [SST]NES000I7
The actual shapes of Kent-Moore tools may differ from those of special service tools i

Page 3110 of 4647

INFINITI M35 2007 Factory Service Manual NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING
FSU-5
[2WD]
C
D
F
G
H
I
J
K
L
MA
B
FSU
Revision: 2007 April2007 M35/M45
NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTINGPFP:00003
NVH Troublesh

Page 3111 of 4647

INFINITI M35 2007 Factory Service Manual FSU-6
[2WD]
FRONT SUSPENSION ASSEMBLY
Revision: 2007 April2007 M35/M45
FRONT SUSPENSION ASSEMBLYPFP:54010
On-Vehicle Inspection NES000IA
Make sure the mounting conditions (looseness, back lash) of eac

FSU-6
[2WD]
FRONT SUSPENSION ASSEMBLY
Revision: 2007 April2007 M35/M45
FRONT SUSPENSION ASSEMBLYPFP:54010
On-Vehicle Inspection NES000IA
Make sure the mounting conditions (looseness, back lash) of each component and component conditions
(wear, damage) are normal.
INSPECTION OF UPPER LINK BALL JOINT END PLAY
1. Set front wheels in a straight-ahead position. Do not depress brake pedal.
2. Place an iron bar or similar tool between transverse link and steering knuckle.
3. Measure axial end play by prying it up and down.
CAUTION:
Be careful not to damage ball joint boot. Do not damage the installation position by applying
excessive force.
SHOCK ABSORBER INSPECTION
Check for oil leakage, damage and breakage of installation positions.
Wheel Alignment InspectionNES000IB
DESCRIPTION
Measure wheel alignment under unladen conditions.
NOTE:
“Unladen conditions” means that fuel, engine coolant, and lubricant are full. Spare tire, jack, hand tools and
mats are in designated positions.
PRELIMINARY CHECK
Check tires for improper air pressure and wear.
Check road wheels for runout. Refer to WT-6, "ROAD WHEEL" .
Check wheel bearing axial end play. Refer to FAX-5, "WHEEL BEARING INSPECTION" .
Check transverse link ball joint axial end play. Refer to FSU-14, "INSPECTION AFTER REMOVAL" .
Check shock absorber operation.
Check each mounting part of axle and suspension for looseness and deformation.
Check each of suspension member, shock absorber, upper link and transverse link for cracks, deforma-
tion and other damage.
Check vehicle height (posture).
GENERAL INFORMATION AND RECOMMENDATIONS
A four-wheel thrust alignment should be performed.
–This type of alignment is recommended for any NISSAN/INFINITI vehicle.
–The four-wheel “thrust” process helps ensure that the vehicle is properly aligned and the steering wheel is
centered.
–The alignment rack itself should be capable of accepting any NISSAN/INFINITI vehicle.
–The rack should be checked to ensure that it is level.
Make sure the machine is properly calibrated.
–Your alignment equipment should be regularly calibrated in order to give correct information.
–Check with the manufacturer of your specific equipment for their recommended Service/Calibration
Schedule.Axial end play : 0 mm (0 in)

Page 3112 of 4647

INFINITI M35 2007 Factory Service Manual FRONT SUSPENSION ASSEMBLY
FSU-7
[2WD]
C
D
F
G
H
I
J
K
L
MA
B
FSU
Revision: 2007 April2007 M35/M45
THE ALIGNMENT PROCESS
IMPORTANT:
Use only the alignment specifications listed in this Service Manual.

FRONT SUSPENSION ASSEMBLY
FSU-7
[2WD]
C
D
F
G
H
I
J
K
L
MA
B
FSU
Revision: 2007 April2007 M35/M45
THE ALIGNMENT PROCESS
IMPORTANT:
Use only the alignment specifications listed in this Service Manual.
When displaying the alignment settings, many alignment machines use “indicators”: (Green/red, plus or
minus, Go/No Go). Do NOT use these indicators.
–The alignment specifications programmed into your machine that operate these indicators may not be cor-
rect.
–This may result in an ERROR.
Some newer alignment machines are equipped with an optional “Rolling Compensation” method to “com-
pensate” the sensors (alignment targets or head units). DO NOT use this “Rolling Compensation”
method.
–Use the “Jacking Compensation Method”. After installing the alignment targets or head units, raise the
vehicle and rotate the wheels 1/2 turn both ways.
–See Instructions in the alignment machine you're using for more information on this.
INSPECTION OF CAMBER, CASTER AND KINGPIN INCLINATION ANGLES
Camber, caster, kingpin inclination angles cannot be adjusted.
Before inspection, mount front wheels onto turning radius gauge. Mount rear wheels onto a stand that has
same height so vehicle will remain horizontal.
Using a CCK Gauge
Install the CCK gauge attachment [SST: KV991040S0 ( – )] with the following procedure on wheel, then
measure wheel alignment.
1. Remove three wheel nuts, and install the guide bolts to hub bolt.
2. Screw the adapter into the plate until it contacts the plate tightly.
3. Screw the center plate into the plate.
4. Insert the plate assembly on the guide bolt. Put the spring in,
and then evenly screw the three guide bolt nuts. When fastening
the guide nuts, do not completely compress the spring.
5. Place the dent of alignment gauge onto the projection of the
center plate and tightly contact them to measure.
CAUTION:
If camber, caster, or kingpin inclination angle is outside
the standard, check front suspension parts for wear and
damage. Replace suspect parts if a malfunction is
detected.
Kingpin inclination angle is reference value, no inspec-
tion is required.
SEIA0240E
Camber, caster, kingpin inclination angles:
Refer to FSU-19, "
SERVICE DATA AND SPECIFICA-
TIONS (SDS)" .
SEIA0241E

Load next 8 pages

Page: < prev 1-10 ... 3073-3080 3081-3088 3089-3096 3097-3104 3105-3112 3113-3120 3121-3128 3129-3136 3137-3144 ... 4648 next >

inflation pressure parking sensors transmission oil carplay oil temperature fuse box diagram
