Page 409 of 4647

INFINITI M35 2007 Factory Service Manual AT-330 REPAIR FOR COMPONENT PARTS Revision: 2007 April2007 M35/M45 4. Disassemble input clutch assembly. a. Remove O-ring and seal rings from input clutch assembly. b. Remove needle bearing from input

Page 410 of 4647

INFINITI M35 2007 Factory Service Manual REPAIR FOR COMPONENT PARTS AT-331 D E F G H I J K L MA B AT Revision: 2007 April2007 M35/M45 CAUTION: If necessary, replace the input clutch assembly. Front Carrier Check for deformation, fatigue or

Page 411 of 4647

INFINITI M35 2007 Factory Service Manual AT-332 REPAIR FOR COMPONENT PARTS Revision: 2007 April2007 M35/M45 d. Install O-ring and seal rings in input clutch assembly. CAUTION: Do not reuse O-ring and seal rings. Apply ATF to O-ring. Apply

Page 412 of 4647

INFINITI M35 2007 Factory Service Manual REPAIR FOR COMPONENT PARTS AT-333 D E F G H I J K L MA B AT Revision: 2007 April2007 M35/M45 Mid Sun Gear, Rear Sun Gear, High and Low Reverse Clutch HubNCS001R7 COMPONENTS VQ35DE models VK45DE models

Page 413 of 4647

INFINITI M35 2007 Factory Service Manual AT-334 REPAIR FOR COMPONENT PARTS Revision: 2007 April2007 M35/M45 DISASSEMBLY 1. Remove needle bearing and bearing races from high and low reverse clutch hub. VQ35DE models VK45DE models 2. Using a

Page 414 of 4647

INFINITI M35 2007 Factory Service Manual REPAIR FOR COMPONENT PARTS AT-335 D E F G H I J K L MA B AT Revision: 2007 April2007 M35/M45 a. Remove needle bearing from high and low reverse clutch hub. 4. Remove rear sun gear assembly from mid su

Page 415 of 4647

INFINITI M35 2007 Factory Service Manual AT-336 REPAIR FOR COMPONENT PARTS Revision: 2007 April2007 M35/M45 INSPECTION High and Low Reverse Clutch Hub Snap Ring, Rear Sun Gear Snap Ring Check for deformation, fatigue or damage. CAUTION: If

Page 416 of 4647

INFINITI M35 2007 Factory Service Manual REPAIR FOR COMPONENT PARTS AT-337 D E F G H I J K L MA B AT Revision: 2007 April2007 M35/M45 3. Using a flat-bladed screwdriver, install snap ring to rear sun gear. 4. Install rear sun gear assembly t
