Page 905 of 4647
![INFINITI M35 2007 Factory Service Manual AV-280
[WITH MOBILE ENTERTAINMENT SYSTEM]
REMOVAL AND INSTALLATION
Revision: 2007 April2007 M35/M45
2. Remove screws (A) and disconnect connector.
3. Remove woofer (1).
INSTALLATION
Installation is th INFINITI M35 2007 Factory Service Manual AV-280
[WITH MOBILE ENTERTAINMENT SYSTEM]
REMOVAL AND INSTALLATION
Revision: 2007 April2007 M35/M45
2. Remove screws (A) and disconnect connector.
3. Remove woofer (1).
INSTALLATION
Installation is th](/manual-img/42/57024/w960_57024-904.png)
AV-280
[WITH MOBILE ENTERTAINMENT SYSTEM]
REMOVAL AND INSTALLATION
Revision: 2007 April2007 M35/M45
2. Remove screws (A) and disconnect connector.
3. Remove woofer (1).
INSTALLATION
Installation is the reverse order of removal.
BOSE AmpNKS004BP
: Vehicle front
REMOVAL
1. Remove trunk front finisher. Refer to EI-56, "Removal and Installation for Trunk Room Trim" .
2. Remove screws (A), and disconnect connector.
3. Remove BOSE amp (1).
INSTALLATION
Installation is the reverse order of removal.
AudioPilot® MicrophoneNKS004BQ
REMOVAL
1. Remove steering column lower cover. Refer to IP-11, "Removal and Installation of Instrument Panel &
Pad" .
2. Remove screws (A) and disconnect connector.
3. Remove Microphone (2) from steering column lower cover (1).
INSTALLATION
Installation is the reverse order of removal.
Satellite Radio TunerNKS004BR
REMOVAL
1. Remove trunk front finisher. Refer to EI-56, "Removal and Installation for Trunk Room Trim" .
2. Remove rear parcel shelf finisher. Refer to EI-42, "
Removal and Installation" .
SKIB4348E
SKIB4349E
SKIB4350E
Page 906 of 4647
![INFINITI M35 2007 Factory Service Manual REMOVAL AND INSTALLATION
AV-281
[WITH MOBILE ENTERTAINMENT SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
AV
Revision: 2007 April2007 M35/M45
3. Remove screws (A).
4. Disconnect connector and remove satellite radio t INFINITI M35 2007 Factory Service Manual REMOVAL AND INSTALLATION
AV-281
[WITH MOBILE ENTERTAINMENT SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
AV
Revision: 2007 April2007 M35/M45
3. Remove screws (A).
4. Disconnect connector and remove satellite radio t](/manual-img/42/57024/w960_57024-905.png)
REMOVAL AND INSTALLATION
AV-281
[WITH MOBILE ENTERTAINMENT SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
AV
Revision: 2007 April2007 M35/M45
3. Remove screws (A).
4. Disconnect connector and remove satellite radio tuner (1) from
trunk room side.
5. Disconnect screws (A), and remove bracket (1).
INSTALLATION
Installation is the reverse order of removal.
Antenna AmpNKS004BS
REMOVAL
1. Remove rear pillar finisher (RH). Refer to EI-37, "Removal and Installation" .
2. Disengaged the clip (A) to separate glass terminal (1).
3. Remove screw (B) and remove antenna amp (2) from vehicle.
INSTALLATION
Installation is the reverse order of removal.
Satellite Radio AntennaNKS004BT
: Vehicle front
REMOVAL
1. Remove rear pillar finisher. Refer to EI-37, "Removal and Installation" .
2. Remove personal lamp. Refer to LT- 2 8 9 , "
REMOVAL AND INSTALLATION" .
3. Remove assist grip (rear). Refer to EI-52, "
Removal and Installation" .
4. Remove rear display cover. Refer to AV- 2 8 3 , "
Rear Display Unit" .
5. Remove head lining assembly (rear) to obtain work space between the head lining assembly and vehicle.
SKIB4396E
SKIB8875E
SKIB4344E
Page 907 of 4647
AV-282
[WITH MOBILE ENTERTAINMENT SYSTEM]
REMOVAL AND INSTALLATION
Revision: 2007 April2007 M35/M45
6. Remove nut (A), and then disconnect connector (1).
7. Remove satellite radio antenna.
INSTALLATION
Installation is the reverse order of removal.
AV (NAVI) Control UnitNKS004BV
REMOVAL
1. Remove glove box cover. Refer to IP-10, "INSTRUMENT PANEL ASSEMBLY" .
2. Remove screws (A), and remove knee assist protector assem-
bly (1).
3. Remove screws (A), and disconnect connector.
4. Remove AV (NAVI) control unit (1).
5. Remove screws (A) and remove bracket (1).
INSTALLATION
Installation is the reverse order of removal.
SKIB4394E
Roof antenna mounting nut : 6.0 N·m (0.61 kg-m, 53 in-lb)
SKIB4273E
SKIB4274E
SKIB4275E
Page 908 of 4647
REMOVAL AND INSTALLATION
AV-283
[WITH MOBILE ENTERTAINMENT SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
AV
Revision: 2007 April2007 M35/M45
Front Display UnitNKS004BW
REMOVAL
1. Remove upper ventilator grille. Refer to IP-10, "INSTRUMENT PANEL ASSEMBLY" .
2. Remove multifunction switch. Refer to ATC-123, "
Removal and Installation of Multifunction Switch" .
3. Remove screw (A).
4. Remove screws (B) and disconnect connector, and remove dis-
play (1).
5. Remove screws (A) separate front display (1) unit from bracket
(2).
INSTALLATION
Installation is the reverse order of removal.
Rear Display UnitNKS004BX
: Vehicle front
REMOVAL
1. Insert cloth-covered driver into gaps between rear display cover
(1) and headlining, and remove rear display cover (1).
2. Remove nuts (A) and plastic nuts (B).
3. Disconnect connector, and remove rear display unit (2).
SKIB4373E
SKIB4391E
SKIB4354E
SKIB4355E
Page 909 of 4647
AV-284
[WITH MOBILE ENTERTAINMENT SYSTEM]
REMOVAL AND INSTALLATION
Revision: 2007 April2007 M35/M45
INSTALLATION
Installation is the reverse order if removal.
Multifunction SwitchNKS004BY
REMOVAL
1. Remove instrument panel finisher B and C. Refer to IP-10, "INSTRUMENT PANEL ASSEMBLY" .
2. Remove screw (A).
3. Disengage tabs (B) and connector to separate multifunction
switch (1) from instrument panel.
INSTALLATION
Installation is the reverse order of removal.
Preset SwitchNKS004BZ
REMOVAL
1. Remove cluster lid C. Refer to IP-10, "INSTRUMENT PANEL ASSEMBLY" .
2. Disengage tabs (A) to separate preset switch (1) from cluster lid
C (2).
INSTALLATION
Installation is the reverse order of removal.
SKIB4276E
SKIB4277E
Page 910 of 4647
REMOVAL AND INSTALLATION
AV-285
[WITH MOBILE ENTERTAINMENT SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
AV
Revision: 2007 April2007 M35/M45
Steering SwitchNKS004C0
REMOVAL
1. Refer to SRS-42, "DRIVER AIR BAG MODULE" .
INSTALLATION
Installation is the reverse order of removal.
1. Air bag 2. Steering switch 3. Screw
4. Spring 5. Bracket 6. Screw
SKIB4278E
Page 911 of 4647
AV-286
[WITH MOBILE ENTERTAINMENT SYSTEM]
REMOVAL AND INSTALLATION
Revision: 2007 April2007 M35/M45
Rear Control SwitchNKS004C1
REMOVAL
1. Remove tray box from armrest. Refer to SE-168, "Removal and Installation" .
2. Remove screws (A).
3. Disconnect connector (1) and disengage tabs (A) to separate
rear control switch (2).
INSTALLATION
Installation is the reverse order of removal.
Video DistributorNKS004C2
REMOVAL
1. Remove multifunction switch. Refer to AV- 2 8 4 , "Multifunction Switch" .
2. Remove audio unit assembly. Refer to AV- 2 7 7 , "
Audio Unit" .
3. Remove screws (A).
4. Disconnect connector and remove video distributor (1).
5. Remove screws (A) and remove bracket (1).
SKIB4300E
SKIB4301E
SKIB4392E
SKIB4393E
Page 912 of 4647
REMOVAL AND INSTALLATION
AV-287
[WITH MOBILE ENTERTAINMENT SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
AV
Revision: 2007 April2007 M35/M45
INSTALLATION
Installation is the reverse order of removal.
DVD PlayerNKS004C3
REMOVAL
1. Remove cup holder. Refer to IP-11, "Removal and Installation of Instrument Panel & Pad" .
2. Disconnect sub harness connector.
3. Remove sub harness connectors (A) from bracket.
4. Remove metal clips (A) and 8 pawls. Then remove DVD player
cover (1).
5. Remove screws (B) and remove DVD player (2).
6. Remove screws (A) and remove brackets (1).
INSTALLATION
Installation is the reverse order of removal.
PKIC0931E
PKIC0932E
SKIB4358E
