INFINITI M35 2007 Factory Service Manual BL-84
INTELLIGENT KEY SYSTEM
Revision: 2007 April2007 M35/M45
Trouble Diagnosis Symptom ChartNIS001XK
ALL FUNCTIONS OF INTELLIGENT KEY SYSTEM DOES NOT OPERATE
NOTE:
Before performing the diagnosis in

BL-84
INTELLIGENT KEY SYSTEM
Revision: 2007 April2007 M35/M45
Trouble Diagnosis Symptom ChartNIS001XK
ALL FUNCTIONS OF INTELLIGENT KEY SYSTEM DOES NOT OPERATE
NOTE:
Before performing the diagnosis in the following table, check “Trouble Diagnosis Procedure”. Refer to BL-
77, "Trouble Diagnosis Procedure" .
Make sure that vehicle is under the condition shown in “Conditions of vehicle” before starting diagnosis,
and check each symptom.
If the following “symptoms” are detected, check systems shown in the “Diagnosis/service procedure” col-
umn in this order.
Conditions of Vehicle (Operating Conditions)
“ENGINE START BY I-KEY” and “LOCK/UNLOCK BY I-KEY” are ON when setting on CONSULT-II.
All doors are closed.
DOOR LOCK/UNLOCK FUNCTION MALFUNCTION
NOTE:
Before performing the diagnosis in the following table, check “Trouble Diagnosis Procedure”. Refer to BL-
77, "Trouble Diagnosis Procedure" .
Make sure that vehicle is under the condition shown in “Conditions of vehicle” before starting diagnosis,
and check each symptom.
If the following “symptoms” are detected, check systems shown in the “Diagnosis/service procedure” col-
umn in this order.
Conditions of Vehicle (Operating Conditions)
“LOCK/UNLOCK BY I-KEY” is ON when setting on CONSULT-II.
Intelligent Key is out of key slot.
All doors are closed.
ENGINE SW ILLUMIThis test is able to check push-ignition switch illumination operation.
Push-ignition switch illumination illuminates when “ON” on CONSULT-II screen is touched.
LOCK INDCATORThis test is able to check LOCK indicator in push-ignition switch operation.
LOCK indicator in push-ignition switch illuminates when “ON” on CONSULT-II screen is touched.
ACC INDCATORThis test is able to check ACC indicator in push-ignition switch operation.
LOCK indicator in push-ignition switch illuminates when “ON” on CONSULT-II screen is touched.
IGNITION ON INDThis test is able to check INGITION ON indicator in push-ignition switch operation.
LOCK indicator in push-ignition switch illuminates when “ON” on CONSULT-II screen is touched.
KEY SLOT ILLUMIThis test is able to check key slot illumination operation.
Key slot illumination flash when “ON” on CONSULT-II screen is touched. Test item Description
Symptom Diagnosis/service procedure Reference page
All function of Intelligent Key system dose not
operate.1.Check Intelligent Key unit power supply and ground
circuit.BL-91
2. Check Intelligent Key battery inspection.BL-124
3. Check remote keyless entry receiver.BL-115
4. Replace Intelligent Key unit.BL-123
Symptom Diagnosis/service procedure Reference page
Door lock/unlock do not operate by door
request switch.1.Check Intelligent Key unit power supply and ground
circuit.BL-91
2. Check door switch.BL-94
3. Check key slot.BL-92
4. Replace Intelligent Key unit.BL-123

Page 1018 of 4647

INFINITI M35 2007 Factory Service Manual INTELLIGENT KEY SYSTEM
BL-85
C
D
E
F
G
H
J
K
L
MA
B
BL
Revision: 2007 April2007 M35/M45
REMOTE KEYLESS ENTRY FUNCTION MALFUNCTION
NOTE:
Before performing the diagnosis in the following table, check �

INTELLIGENT KEY SYSTEM
BL-85
C
D
E
F
G
H
J
K
L
MA
B
BL
Revision: 2007 April2007 M35/M45
REMOTE KEYLESS ENTRY FUNCTION MALFUNCTION
NOTE:
Before performing the diagnosis in the following table, check “Trouble Diagnosis Procedure”. Refer to BL-
77, "Trouble Diagnosis Procedure" .
Make sure that vehicle is under the condition shown in “Conditions of vehicle” before starting diagnosis,
and check each symptom.
If the following “symptoms” are detected, check systems shown in the “Diagnosis/service procedure” col-
umn in this order.
Conditions of Vehicle (Operating Conditions)
Intelligent Key is out of key slot.
Ignition switch is not ON position.
All doors are closed.
Door lock/unlock does not operate by request
switch (driver side).1. Check door request switch (driver side).BL-992. Check outside key antenna (driver side).BL-106
3. Replace Intelligent Key unit.BL-123
Door lock/unlock does not operate by request
switch (passenger side).1. Check door request switch (passenger side).BL-992. Check outside key antenna (passenger side).BL-106
3. Replace Intelligent Key unit.BL-123
Selective unlock function does not operate by
door request switch (driver side) (other door
lock function operate).1.Check “SELECT UNLOCK FUNCTION” setting in
“WORK SUPPORT”.BL-81
2.Check selective unlock function with a remote control-
ler or door key cylinder.BL-26
3. Replace BCM.BCS-15
Selective unlock function does not operate by
door request switch (passenger side) (other
door lock function operate).1.Check “SELECT UNLOCK FUNCTION” setting in
“WORK SUPPORT”.BL-81
2. Replace Intelligent Key unit.BL-123
Auto lock function does not operate.1.Check “AUTO RELOCK TIMER” setting in “WORK
SUPPORT”.BL-812. Check door switch.BL-94
3. Check key slot.BL-92
4. Replace BCM.BCS-15
Key reminder function does not operate.1.Check “ANTI KEY LOCK IN FUNCTION” setting in
“WORK SUPPORT”.BL-81
2. Check door switch.BL-94
3. Check inside key antenna.BL-110
4. Check unlock sensor.BL-103
5. Check Intelligent Key battery inspection.BL-124
6. Replace Intelligent Key unit.BL-123
Symptom Diagnosis/service procedure Reference page
Symptom Diagnosis/service procedureReference
page
All of the remote keyless entry functions
do not operate.1. Check Intelligent Key battery inspection.BL-124
2. Replace Intelligent Key unit.BL-123
Selective unlock function does not operate
by Intelligent Key.1.Check “SELECT UNLOCK FUNCTION” setting in “WORK SUP-
PORT”.BL-81
2. Check Intelligent Key battery inspection.BL-124
3. Replace Intelligent Key unit.BL-123

Page 1019 of 4647

INFINITI M35 2007 Factory Service Manual BL-86
INTELLIGENT KEY SYSTEM
Revision: 2007 April2007 M35/M45
TRUNK OPEN FUNCTION MALFUNCTION
NOTE:
Before performing the diagnosis in the following table, check “Trouble Diagnosis Procedure”. Re

BL-86
INTELLIGENT KEY SYSTEM
Revision: 2007 April2007 M35/M45
TRUNK OPEN FUNCTION MALFUNCTION
NOTE:
Before performing the diagnosis in the following table, check “Trouble Diagnosis Procedure”. Refer to BL-
77, "Trouble Diagnosis Procedure" .
Make sure that vehicle is under the condition shown in “Conditions of vehicle” before starting diagnosis,
and check each symptom.
If the following “symptoms” are detected, check systems shown in the “Diagnosis/service procedure” col-
umn in this order.
Conditions of Vehicle (Operating Conditions)
Intelligent Key is out of key slot.
All doors are closed.
Auto lock function does not operate prop-
erly.1. Check “AUTO RELOCK TIMER” setting in “WORK SUPPORT”.BL-812. Check door switch.BL-94
3. Check key slot.BL-92
4. Replace BCM.BCS-15
Key reminder function does not operate.1.Check “ANTI KEY LOCK IN FUNCTION” setting in “WORK SUP-
PORT”.BL-81
2. Check door switch.BL-94
3. Check inside key antenna.BL-110
4. Check unlock sensor.BL-103
5. Check Intelligent Key battery inspection.BL-124
6. Replace Intelligent Key unit.BL-123
Panic alarm function does not operate.1. Check “PANIC ALARM DELAY” setting in “WORK SUPPORT”.BL-81
2. Check theft warning operation.BL-217
3. Check Intelligent Key battery inspection.BL-124
4. Check key slot.BL-92
5. Replace Intelligent Key unit.BL-123
Symptom Diagnosis/service procedureReference
page
Symptom Diagnosis/service procedure Reference page
Trunk open function does not operate by trunk
opener request switch.1. Check trunk opener request switch.BL-101

2. Check trunk lid opener cancel switch.BL-119
3. Check outside key antenna (trunk room).BL-108
4. Replace Intelligent Key unit.BL-123
Trunk open function does not operate by Intelli-
gent Key.1.Check “TRUNK OPEN DELAY” setting in “WORK
SUPPORT”.BL-812. Check trunk lid opener system.BL-207
3. Check trunk room lamp switch.BL-97
4. Check Intelligent Key battery inspection.BL-124
5. Replace Intelligent Key unit.BL-123
Key reminder function does not operate.1. Check door switch.BL-94
2. Check trunk room lamp switch.BL-97
3. Check inside key antenna (trunk room).BL-110
4. Check trunk lid opener system.BL-207
5. Replace Intelligent Key unit.BL-123

Page 1020 of 4647

INFINITI M35 2007 Factory Service Manual INTELLIGENT KEY SYSTEM
BL-87
C
D
E
F
G
H
J
K
L
MA
B
BL
Revision: 2007 April2007 M35/M45
HAZARD AND BUZZER REMINDER FUNCTION MALFUNCTION
NOTE:
Before performing the diagnosis in the following table, c

INTELLIGENT KEY SYSTEM
BL-87
C
D
E
F
G
H
J
K
L
MA
B
BL
Revision: 2007 April2007 M35/M45
HAZARD AND BUZZER REMINDER FUNCTION MALFUNCTION
NOTE:
Before performing the diagnosis in the following table, check “Trouble Diagnosis Procedure”. Refer to BL-
77, "Trouble Diagnosis Procedure" .
If the following “symptoms” are detected, check systems shown in the “Diagnosis/service procedure” col-
umn in this order.
Conditions of Vehicle (Operating Conditions)
“LOCK/UNLOCK BY I-KEY” is ON when setting on CONSULT-II.
“ANSWER BACK FUNCTION” is ON when setting on CONSULT-II.
Ignition switch is in OFF position.
All doors are closed.
Intelligent Key is out of key slot.
HAZARD AND HORN REMINDER FUNCTION MALFUNCTION
NOTE:
Before performing the diagnosis in the following table, check “Trouble Diagnosis Procedure”. Refer to BL-
77, "Trouble Diagnosis Procedure" .
Make sure that vehicle is under the condition shown in “Conditions of vehicle” before starting diagnosis,
and check each symptom.
If the following “symptoms” are detected, check systems shown in the “Diagnosis/service procedure” col-
umn in this order.
Conditions of Vehicle (Operating Conditions)
“ANSWER BACK FUNCTION” is ON when setting on CONSULT-II.
Ignition switch is in OFF position.
All doors are closed.
Symptom Diagnosis/service procedure Reference page
Hazard reminder does not operate by
request switch.
(Horn reminder operate.)1.Check “HAZARD ANSWER BACK” setting in “WORK
SUPPORT”.BL-81
2. Check hazard function with hazard switch.LT-212
3. Replace Intelligent Key unit.BL-123
Buzzer reminder does not operate by request
switch.
(Hazard reminder operate.)1.Check “ANSWER BACK WITH I-KEY LOCK” or
“ANSWER BACK WITH I-KEY UNLOCK” setting in
“WORK SUPPORT”.BL-81
2. Check Intelligent Key warning buzzer.BL-105
3. Replace Intelligent Key unit.BL-123
Buzzer reminder does not operate by trunk
opener request switch.1.Check “TRUNK/GLASS HATCH OPEN” setting in “WORK
SUPPORT”.BL-812. Check Intelligent Key warning buzzer.BL-105
3. Check trunk opener lid system.BL-207
4. Replace Intelligent Key unitBL-123
Symptom Diagnosis/service procedure Reference page
Hazard reminder does not operate by Intelli-
gent Key button.
(Horn reminder operate.)1.Check “HAZARD ANSWER BACK” setting in “WORK
SUPPORT”.BL-81
2. Check hazard function with hazard switch.LT-212
3. Replace Intelligent KeyBL-123
Horn reminder does not operate by Intelligent
Key button (door lock/unlock button).
(Hazard reminder operate.)1.Check “HORN WITH KEYLESS LOCK” setting in “WORK
SUPPORT”.BL-81
2. Check horn function.BL-122
3. Replace Intelligent Key unitBL-123

Page 1021 of 4647

INFINITI M35 2007 Factory Service Manual BL-88
INTELLIGENT KEY SYSTEM
Revision: 2007 April2007 M35/M45
POWER WINDOW DOWN FUNCTION MALFUNCTION
NOTE:
Before performing the diagnosis in the following table, check “Trouble Diagnosis Procedure

BL-88
INTELLIGENT KEY SYSTEM
Revision: 2007 April2007 M35/M45
POWER WINDOW DOWN FUNCTION MALFUNCTION
NOTE:
Before performing the diagnosis in the following table, check “Trouble Diagnosis Procedure”. Refer to BL-
77, "Trouble Diagnosis Procedure" .
If the following “symptoms” are detected, check systems shown in the “Diagnoses/service procedure” col-
umn in this order.
Conditions of Vehicle (Operating Conditions)
Ignition switch is in OFF or ACC position.
Retained power operation does not operate. Refer to GW-17, "RETAINED POWER OPERATION" .
WARNING FUNCTION MALFUNCTION
NOTE:
Before performing the diagnosis in the following table, check “Trouble Diagnosis Procedure”. Refer to BL-
77, "Trouble Diagnosis Procedure" .
Make sure that vehicle is under the condition shown in “Conditions of vehicle” before starting diagnosis,
and check each symptom.
If the following “symptoms” are detected, check systems shown in the “Diagnosis/service procedure” col-
umn in this order.
Conditions of Vehicle (Operating Conditions)
Warning chime functions operating condition is extremely complicated, during operating confirmations, recon-
firm the list above twice in order to ensure proper operation.
Symptom Diagnosis/service procedure Reference page
Power window down function does not
operate.1. Check “P/W DOWN DELAY” setting in “WORK SUPPORT”.BL-81
2. Check Intelligent Key battery inspection.BL-124
Symptom Diagnosis/service procedure Reference page
OFF position warn-
ing does not oper-
ate.For internal1. Check ignition switch position.BL-115
2. Check door switch.BL-94
3. Check warning chime function.BL-123
4. Replace Intelligent Key unit.BL-123
For external1. Check ignition switch position.BL-1152. Check door switch.BL-94
3. Check Intelligent Key warning buzzer.BL-105
4. Replace Intelligent Key unit.BL-123
P position warning does not operate.1. Check Park position switch.BL-113
2. Check door switch.BL-94
3. Check Intelligent Key warning buzzer.BL-105
4. Check warning chime function.BL-123
5. Check combination meter display.BL-122
6. Replace Intelligent Key unit. BL-123
ACC warning does not operate1. Check ignition switch position.BL-1152. Check warning chime function.BL-123
3. Check combination meter display.BL-122
4. Replace Intelligent Key unit.BL-123

Page 1022 of 4647

INFINITI M35 2007 Factory Service Manual INTELLIGENT KEY SYSTEM
BL-89
C
D
E
F
G
H
J
K
L
MA
B
BL
Revision: 2007 April2007 M35/M45
Take away warning
does not operate.Door open to close1. Check door switch.BL-94
2. Check inside key antenna.BL-

Page 1023 of 4647

INFINITI M35 2007 Factory Service Manual BL-90
INTELLIGENT KEY SYSTEM
Revision: 2007 April2007 M35/M45
Check CAN Communication SystemNIS001XL
1. CHECK SELF-DIAGNOSTIC RESULTS
CAUTION:
If CONSULT-II is used with no connection of CONSULT-II CO

Page 1024 of 4647

INFINITI M35 2007 Factory Service Manual INTELLIGENT KEY SYSTEM
BL-91
C
D
E
F
G
H
J
K
L
MA
B
BL
Revision: 2007 April2007 M35/M45
Check Power Supply and Ground CircuitNIS001XM
1. CHECK POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disc

Load next 8 pages

Page: < prev 1-10 ... 985-992 993-1000 1001-1008 1009-1016 1017-1024 1025-1032 1033-1040 1041-1048 1049-1056 ... 4648 next >

dashboard warning light suspension apple carplay trip computer jump cable
