Page 2721 of 4647
EC-1192
[VK45DE]
DTC P0605 ECM
Revision: 2007 April2007 M35/M45
2. REPLACE ECM
1. Replace ECM.
2. Perform initialization of IVIS (NATS) system and registration of all IVIS (NATS) ignition key IDs. Refer to
BL-248, "
ECM Re-Communicating Function" .
3. Perform EC-787, "
VIN Registration" .
4. Perform EC-788, "
Accelerator Pedal Released Position Learning" .
5. Perform EC-788, "
Throttle Valve Closed Position Learning" .
6. Perform EC-788, "
Idle Air Volume Learning" .
>>INSPECTION END
Page 2722 of 4647
![INFINITI M35 2007 Factory Service Manual DTC P0643 SENSOR POWER SUPPLY
EC-1193
[VK45DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: 2007 April2007 M35/M45
DTC P0643 SENSOR POWER SUPPLYPFP:18919
On Board Diagnosis LogicNBS005JY
This self-diagnosis ha INFINITI M35 2007 Factory Service Manual DTC P0643 SENSOR POWER SUPPLY
EC-1193
[VK45DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: 2007 April2007 M35/M45
DTC P0643 SENSOR POWER SUPPLYPFP:18919
On Board Diagnosis LogicNBS005JY
This self-diagnosis ha](/manual-img/42/57024/w960_57024-2721.png)
DTC P0643 SENSOR POWER SUPPLY
EC-1193
[VK45DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: 2007 April2007 M35/M45
DTC P0643 SENSOR POWER SUPPLYPFP:18919
On Board Diagnosis LogicNBS005JY
This self-diagnosis has the one trip detection logic.
FAIL-SAFE MODE
When the malfunction is detected, ECM enters fail-safe mode and the MIL lights up.
DTC Confirmation ProcedureNBS005JZ
NOTE:
If DTC Confirmation Procedure has been previously conducted, always turn ignition switch OFF and wait at
least 10 seconds before conducting the next test.
TESTING CONDITION:
Before performing the following procedure, confirm that battery voltage is more than 10V at idle.
WITH CONSULT-II
1. Turn ignition switch ON.
2. Select “DATA MONITOR” mode with CONSULT-II.
3. Start engine and let it idle for 1 second.
4. If DTC is detected, go to EC-1196, "
Diagnostic Procedure" .
WITH GST
Follow the procedure “WITH CONSULT-II” above.
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
P0643
0643Sensor power supply
circuit shortECM detects a voltage of power source
for sensor is excessively low or high.
Harness or connectors
(APP sensor 1 circuit is shorted.)
(EVAP control system pressure sensor is
shorted.)
(Refrigerant pressure sensor circuit is
shorted.)
(PSP sensor circuit is shorted.)
(Battery current sensor circuit is shorted.)
Accelerator pedal position sensor
EVAP control system pressure sensor
Refrigerant pressure sensor
Power steering pressure sensor
Battery current sensor
Engine operation condition in fail-safe mode
ECM stops the electric throttle control actuator control, throttle valve is maintained at a fixed opening (approx. 5 degrees) by the return
spring.
SEF058Y
Page 2723 of 4647
EC-1194
[VK45DE]
DTC P0643 SENSOR POWER SUPPLY
Revision: 2007 April2007 M35/M45
Wiring DiagramNBS005K0
TBWT1496E
Page 2724 of 4647
![INFINITI M35 2007 Factory Service Manual DTC P0643 SENSOR POWER SUPPLY
EC-1195
[VK45DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: 2007 April2007 M35/M45
Specification data are reference values and are measured between each terminal and ground.
CAU INFINITI M35 2007 Factory Service Manual DTC P0643 SENSOR POWER SUPPLY
EC-1195
[VK45DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: 2007 April2007 M35/M45
Specification data are reference values and are measured between each terminal and ground.
CAU](/manual-img/42/57024/w960_57024-2723.png)
DTC P0643 SENSOR POWER SUPPLY
EC-1195
[VK45DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: 2007 April2007 M35/M45
Specification data are reference values and are measured between each terminal and ground.
CAUTION:
Do not use ECM ground terminals when measuring input/output voltage. Doing so may result in dam-
age to the ECM's transistor. Use a ground other than ECM terminals, such as the ground.
TER-
MINAL
NO.WIRE
COLORITEM CONDITION DATA (DC Voltage)
48 BRSensor power supply
(EVAP control system pres-
sure sensor)[Ignition switch: ON]Approximately 5V
49 B/YSensor power supply
(Refrigerant pressure sen-
sor, Battery current sensor)[Ignition switch: ON]Approximately 5V
68 L/YSensor power supply
(Power steering pressure
sensor)[Ignition switch: ON]Approximately 5V
82 WSensor ground
(APP sensor 1)[Engine is running]
Warm-up condition
Idle speedApproximately 0V
83 PSensor ground
(APP sensor 2)[Engine is running]
Warm-up condition
Idle speedApproximately 0V
90 LSensor power supply
(APP sensor 1)[Ignition switch: ON]Approximately 5V
91 BRSensor power supply
(APP sensor 2)[Ignition switch: ON]Approximately 5V
98 RAccelerator pedal position
sensor 2[Ignition switch: ON]
Engine stopped
Accelerator pedal: Fully released0.20 - 0.55V
[Ignition switch: ON]
Engine: Stopped
Accelerator pedal: Fully depressed1.85 - 2.40V
106 LGAccelerator pedal position
sensor 1[Ignition switch: ON]
Engine: Stopped
Accelerator pedal: Fully released0.4 - 1.1V
[Ignition switch: ON]
Engine: Stopped
Accelerator pedal: Fully depressed3.7 - 4.8V
Page 2725 of 4647
EC-1196
[VK45DE]
DTC P0643 SENSOR POWER SUPPLY
Revision: 2007 April2007 M35/M45
Diagnostic ProcedureNBS005K1
1. CHECK GROUND CONNECTIONS
1. Turn ignition switch OFF.
2. Loosen and retighten ground screws on the body.
Refer to EC-864, "
Ground Inspection" .
OK or NG
OK >> GO TO 2.
NG >> Repair or replace ground connections.
2. CHECK ACCELERATOR PEDAL POSITION SENSOR 1 POWER SUPPLY CIRCUIT
1. Disconnect accelerator pedal position (APP) sensor (1) harness
connector.
2. Turn ignition switch ON.
3. Check voltage between APP sensor terminal 4 and ground with
CONSULT-II or tester.
OK or NG
OK >> GO TO 5.
NG >> GO TO 3.
1. Body ground M70 2. Body ground M16
PBIB2782E
PBIB2704E
Voltage: Approximately 5V
PBIA9606J
Page 2726 of 4647
![INFINITI M35 2007 Factory Service Manual DTC P0643 SENSOR POWER SUPPLY
EC-1197
[VK45DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: 2007 April2007 M35/M45
3. CHECK SENSOR POWER SUPPLY CIRCUITS
Check harness for short to power and short to ground, be INFINITI M35 2007 Factory Service Manual DTC P0643 SENSOR POWER SUPPLY
EC-1197
[VK45DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: 2007 April2007 M35/M45
3. CHECK SENSOR POWER SUPPLY CIRCUITS
Check harness for short to power and short to ground, be](/manual-img/42/57024/w960_57024-2725.png)
DTC P0643 SENSOR POWER SUPPLY
EC-1197
[VK45DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: 2007 April2007 M35/M45
3. CHECK SENSOR POWER SUPPLY CIRCUITS
Check harness for short to power and short to ground, between the following terminals.
OK or NG
OK >> GO TO 4.
NG >> Repair short to ground or short to power in harness or connectors.
4. CHECK COMPONENTS
Check the following.
EVAP control system pressure sensor (Refer to EC-1144, "Component Inspection" .)
Refrigerant pressure sensor (Refer to AT C - 9 7 , "COMPONENT INSPECTION" .)
Battery current sensor (Refer to EC-1242, "Component Inspection" .)
Power steering pressure sensor (Refer to EC-1185, "Component Inspection" .)
OK or NG
OK >> GO TO 7.
NG >> Replace malfunctioning component.
5. CHECK APP SENSOR
Refer to EC-1341, "
Component Inspection" .
OK or NG
OK >> GO TO 7.
NG >> GO TO 6.
6. REPLACE ACCELERATOR PEDAL ASSEMBLY
1. Replace accelerator pedal assembly.
2. Perform EC-788, "
Accelerator Pedal Released Position Learning" .
3. Perform EC-788, "
Throttle Valve Closed Position Learning" .
4. Perform EC-788, "
Idle Air Volume Learning" .
>>INSPECTION END
7. CHECK INTERMITTENT INCIDENT
Refer to EC-857, "
TROUBLE DIAGNOSIS FOR INTERMITTENT INCIDENT" .
>>INSPECTION END
ECM terminal Sensor terminal Reference Wiring Diagram
90 APP sensor terminal 4EC-1194
48 EVAP control system pressure sensor terminal 3EC-1141
49Refrigerant pressure sensor terminal 1EC-1425Battery current sensor terminal 1EC-1239
68 PSP sensor terminal 1EC-1182
Page 2727 of 4647
![INFINITI M35 2007 Factory Service Manual EC-1198
[VK45DE]
DTC P0850 PNP SWITCH
Revision: 2007 April2007 M35/M45
DTC P0850 PNP SWITCHPFP:23006
Component DescriptionNBS005K2
When the selector lever position is P or N, park/neutral position (PN INFINITI M35 2007 Factory Service Manual EC-1198
[VK45DE]
DTC P0850 PNP SWITCH
Revision: 2007 April2007 M35/M45
DTC P0850 PNP SWITCHPFP:23006
Component DescriptionNBS005K2
When the selector lever position is P or N, park/neutral position (PN](/manual-img/42/57024/w960_57024-2726.png)
EC-1198
[VK45DE]
DTC P0850 PNP SWITCH
Revision: 2007 April2007 M35/M45
DTC P0850 PNP SWITCHPFP:23006
Component DescriptionNBS005K2
When the selector lever position is P or N, park/neutral position (PNP) switch is ON.
ECM detects the position because the continuity of the line (the ON signal) exists.
CONSULT-II Reference Value in Data Monitor ModeNBS005K3
Specification data are reference values.
On Board Diagnosis LogicNBS005K4
DTC Confirmation ProcedureNBS005K5
CAUTION:
Always drive vehicle at a safe speed.
NOTE:
If DTC Confirmation Procedure has been previously conducted, always turn ignition switch OFF and wait at
least 10 seconds before conducting the next test.
WITH CONSULT-II
1. Turn ignition switch ON.
2. Select “P/N POSI SW” in “DATA MONITOR” mode with CON-
SULT-II. Then check the “P/N POSI SW” signal under the follow-
ing conditions.
If NG, go to EC-1201, "
Diagnostic Procedure" .
If OK, go to following step.
3. Select “DATA MONITOR” mode with CONSULT-II.
4. Start engine and warm it up to normal operating temperature.
5. Maintain the following conditions for at least 50 consecutive sec-
onds.
6. If 1st trip DTC is detected, go to EC-1201, "
Diagnostic Procedure" .
MONITOR ITEM CONDITION SPECIFICATION
P/N POSI SW
Ignition switch: ONSelector lever: P or N ON
Selector lever: Except above OFF
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
P0850
0850Park/neutral position
switchThe signal of the park/neutral position (PNP)
switch is not changed in the process of engine
starting and driving.
Harness or connectors
[The park/neutral position (PNP) switch
circuit is open or shorted.]
Park/neutral position (PNP) switch
Unified meter and A/C amp.
TCM
Position (Selector lever) Known-good signal
N or P position ON
Except above position OFF
SEF212Y
ENG SPEED 1,300 - 6,375 rpm
COOLAN TEMP/S More than 70°C (158°F)
B/FUEL SCHDL 3.0 - 31.8 msec
VHCL SPEED SE More than 64 km/h (40 MPH)
Selector lever Suitable position
SEF213Y
Page 2728 of 4647
DTC P0850 PNP SWITCH
EC-1199
[VK45DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: 2007 April2007 M35/M45
Overall Function CheckNBS005K6
Use this procedure to check the overall function of the park/neutral position (PNP) switch circuit. During this
check, a 1st trip DTC might not be confirmed.
WITH GST
1. Turn ignition switch ON.
2. Check voltage between ECM terminal 102 (PNP switch signal)
and ground under the following conditions.
3. If NG, go to EC-1201, "
Diagnostic Procedure" .
Position (Selector lever) Voltage (Known good data)
P or N position Approx. 0V
Except above positionBATTERY VOLTAGE
(11 - 14V)
MBIB0043E
