INFINITI M35 2007 Factory Service Manual EC-864
[VK45DE]
POWER SUPPLY AND GROUND CIRCUIT
Revision: 2007 April2007 M35/M45
Ground Inspection NBS005AZ
Ground connections are very important to the proper operation of electrical and electronic c

Page 2394 of 4647

INFINITI M35 2007 Factory Service Manual DTC U1000, U1001 CAN COMMUNICATION LINE
EC-865
[VK45DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: 2007 April2007 M35/M45
DTC U1000, U1001 CAN COMMUNICATION LINEPFP:23710
DescriptionNBS005B0
CAN (Controller

Page 2395 of 4647

INFINITI M35 2007 Factory Service Manual EC-866
[VK45DE]
DTC U1000, U1001 CAN COMMUNICATION LINE
Revision: 2007 April2007 M35/M45
Wiring DiagramNBS005B3
TBWT1011E

Page 2396 of 4647

INFINITI M35 2007 Factory Service Manual DTC U1000, U1001 CAN COMMUNICATION LINE
EC-867
[VK45DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: 2007 April2007 M35/M45
Diagnostic ProcedureNBS005B4
Go to LAN-50, "CAN System Specification Chart" .

Page 2397 of 4647

INFINITI M35 2007 Factory Service Manual EC-868
[VK45DE]
DTC U1010 CAN COMMUNICATION
Revision: 2007 April2007 M35/M45
DTC U1010 CAN COMMUNICATIONPFP:23710
DescriptionNBS005B5
CAN (Controller Area Network) is a serial communication line for r

Page 2398 of 4647

INFINITI M35 2007 Factory Service Manual DTC U1010 CAN COMMUNICATION
EC-869
[VK45DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: 2007 April2007 M35/M45
Diagnostic ProcedureNBS005B8
1. INSPECTION START
With CONSULT-II
1. Turn ignition switch ON.
2.

Page 2399 of 4647

INFINITI M35 2007 Factory Service Manual EC-870
[VK45DE]
DTC P0011, P0021 IVT CONTROL
Revision: 2007 April2007 M35/M45
DTC P0011, P0021 IVT CONTROLPFP:23796
DescriptionNBS005B9
SYSTEM DESCRIPTION
*: This signal is sent to the ECM through CAN

Page 2400 of 4647

INFINITI M35 2007 Factory Service Manual DTC P0011, P0021 IVT CONTROL
EC-871
[VK45DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: 2007 April2007 M35/M45
Intake Valve Timing Control Position Sensor
Intake valve timing control position sensors are loc

DTC P0011, P0021 IVT CONTROL
EC-871
[VK45DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: 2007 April2007 M35/M45
Intake Valve Timing Control Position Sensor
Intake valve timing control position sensors are located in the front of
cylinder heads in both bank 1 and bank 2.
This sensor uses a Hall IC.
The cam position is determined by the intake primary cam sprocket
concave (in three places). The ECM provides feedback to the intake
valve timing control for appropriate target valve open-close timing
according to drive conditions based on detected cam position.
CONSULT-II Reference Value in Data Monitor ModeNBS005BA
Specification data are reference values.
On Board Diagnosis LogicNBS005BB
FAIL-SAFE MODE
When the malfunction is detected, the ECM enters fail-safe mode.
SEF359Z
MONITOR ITEM CONDITION SPECIFICATION
INT/V TIM (B1)
INT/V TIM (B2)
Engine: After warming up
Selector lever: P or N
Air conditioner switch: OFF
No loadIdle−5° - 5°CA
2,000 rpm Approx. 0° - 20°CA
INT/V SOL (B1)
INT/V SOL (B2)
Engine: After warming up
Selector lever: P or N
Air conditioner switch: OFF
No loadIdle 0% - 2%
2,000 rpm Approx. 25% - 50%
DTC No. Trouble diagnosis name Detecting condition Possible cause
P0011
0011
(Bank 1)
Intake valve timing control
performanceA)The alignment of the intake valve timing
control has been misresistered.
Harness or connectors
(Intake valve timing control solenoid
valve circuit is open or shorted.)
Harness or connectors
(Intake valve timing control position
sensor circuit is open or shorted.)
Intake valve timing control solenoid
valve
Intake valve timing control position
sensor
Crankshaft position sensor (POS)
Camshaft position sensor (PHASE)
Accumulation of debris to the signal
pick-up portion of the camshaft
sprocket
Timing chain installation
Foreign matter caught in the oil
groove for intake valve timing control P0021
0021
(Bank 2)B)There is a gap between angle of target
and phase-control angle degree.
Detected items Engine operating condition in fail-safe mode
Intake valve timing control The signal is not energized to the solenoid valve and the valve control does not function
