FSU-16
[2WD]
UPPER LINK
Revision: 2007 April2007 M35/M45
UPPER LINKPFP:54524
Removal and InstallationNES000IH
REMOVAL
1. Remove tires from vehicle with a power tool.
2. Remove shock absorber. Refer to FSU-11, "
COIL SPRING AND SHOCK ABSORBER" .
3. Remove mounting nut and bolt with a power tool, and then remove upper link from steering knuckle.
4. Remove mounting nuts and bolts, and then remove upper link and stopper rubber from vehicle.
INSPECTION AFTER REMOVAL
Visual Inspection
Check the following:
Upper link and bushing for deformation, cracks or damage. Replace it if a malfunction is detected.
Ball joint boot for cracks or other damage, and also for grease leakage. Replace it if a malfunction is
detected.
Ball Joint Inspection
Manually move ball stud to confirm it moves smoothly with no binding.
Swing Torque Inspection
NOTE:
Before measurement, move ball stud at least ten times by hand to check for smooth movement.
Hook a spring balance at cutout on ball stud. Confirm spring bal-
ance measurement value is within specifications when ball stud
begins moving.
If it is outside the specified range, replace upper link assembly.
Rotating Torque Inspection
Attach mounting nut to ball stud. Make sure that rotating torque
is within specifications with a preload gauge [SST].
If it is outside the specified range, replace upper link assembly.
Axial End Play Inspection
Move tip of ball stud in axial direction to check for looseness.
If it is outside the specified range, replace upper link assembly.
INSTALLATION
Installation is the reverse order of removal. For tightening torque, refer to FSU-8, "Components" .
Perform final tightening of bolts and nuts at the vehicle installation position (rubber bushing) under
unladen conditions with tires on level ground. Check wheel alignment. Refer to FSU-6, "
Wheel Alignment
Inspection" . Swing torque
: 0 - 2.0 N·m (0 - 0.2 kg-m, 0 - 17 in-lb)
Spring balance measurement
: 0 - 61.5 N (0 - 6.2 kg, 0 - 13.6 lb)
SEIA0523E
Rotating torque
: 0 - 2.0 N·m (0 - 0.2 kg-m, 0 - 17 in-lb)
SDIA1150E
Axial end play : 0 mm (0 in)
Page 3122 of 4647
UPPER LINK
FSU-17
[2WD]
C
D
F
G
H
I
J
K
L
MA
B
FSU
Revision: 2007 April2007 M35/M45
Adjust neutral position of steering angle sensor after checking wheel alignment. Refer to BRC-6, "Adjust-
ment of Steering Angle Sensor Neutral Position" .
Page 3123 of 4647
![INFINITI M35 2007 Factory Service Manual FSU-18
[2WD]
STABILIZER BAR
Revision: 2007 April2007 M35/M45
STABILIZER BARPFP:54611
Removal and InstallationNES000II
REMOVAL
1. Remove tires from vehicle with a power tool.
2. Remove undercover with INFINITI M35 2007 Factory Service Manual FSU-18
[2WD]
STABILIZER BAR
Revision: 2007 April2007 M35/M45
STABILIZER BARPFP:54611
Removal and InstallationNES000II
REMOVAL
1. Remove tires from vehicle with a power tool.
2. Remove undercover with](/manual-img/42/57024/w960_57024-3122.png)
FSU-18
[2WD]
STABILIZER BAR
Revision: 2007 April2007 M35/M45
STABILIZER BARPFP:54611
Removal and InstallationNES000II
REMOVAL
1. Remove tires from vehicle with a power tool.
2. Remove undercover with a power tool.
3. Remove the mounting nut on the lower side of stabilizer connecting rod with a power tool, and then
remove stabilizer connecting rod from stabilizer bar.
4. If necessary remove the mounting nut on the upper side of stabilizer connecting rod with a power tool, and
then remove stabilizer connecting rod from transverse link.
5. Remove the mounting nuts of stabilizer clamp, and then remove stabilizer clamp and stabilizer bushing.
6. Remove stabilizer bar from vehicle.
INSPECTION AFTER REMOVAL
Check stabilizer bar, stabilizer connecting rod, stabilizer bushing and stabilizer clamp for deformation, cracks
or damage. Replace it if a malfunction is detected.
INSTALLATION
Installation is the reverse order of removal. For tightening torque, refer to FSU-8, "Components" .
Page 3124 of 4647
![INFINITI M35 2007 Factory Service Manual SERVICE DATA AND SPECIFICATIONS (SDS)
FSU-19
[2WD]
C
D
F
G
H
I
J
K
L
MA
B
FSU
Revision: 2007 April2007 M35/M45
SERVICE DATA AND SPECIFICATIONS (SDS)PFP:00030
Wheel Alignment (Unladen *)NES000IJ
*: Fue INFINITI M35 2007 Factory Service Manual SERVICE DATA AND SPECIFICATIONS (SDS)
FSU-19
[2WD]
C
D
F
G
H
I
J
K
L
MA
B
FSU
Revision: 2007 April2007 M35/M45
SERVICE DATA AND SPECIFICATIONS (SDS)PFP:00030
Wheel Alignment (Unladen *)NES000IJ
*: Fue](/manual-img/42/57024/w960_57024-3123.png)
SERVICE DATA AND SPECIFICATIONS (SDS)
FSU-19
[2WD]
C
D
F
G
H
I
J
K
L
MA
B
FSU
Revision: 2007 April2007 M35/M45
SERVICE DATA AND SPECIFICATIONS (SDS)PFP:00030
Wheel Alignment (Unladen *)NES000IJ
*: Fuel, engine coolant and lubricant are full. Spare tire, jack, hand tools and mats are in designated positions.
Ball JointNES000IK
Tire size245/45R18 245/40R19
Camber
Degree minute (Decimal degree)Minimum –1° 00′ (–1.00°)
Nominal –0° 15′ (–0.25°)
Maximum 0° 30′ (0.50°)
Left and right difference 33′ (0.55°) or less
Caster
Degree minute (Decimal degree)Minimum 3° 45′ (3.75°)3° 50′ (3.83°)
Nominal 4° 30′ (4.50°)4° 35′ (4.58°)
Maximum 5° 15′ (5.25°)5° 20′ (5.33°)
Left and right difference 39′ (0.65°) or less
Kingpin inclination
Degree minute (Decimal degree)Minimum 6° 30′ (6.50°)
Nominal 7° 15′ (7.25°)
Maximum 8° 00′ (8.00°)
Total toe-inDistanceMinimum 0 mm (0 in)
Nominal In 1 mm (0.04 in)
Maximum In 2 mm (0.08 in)
Angle (left wheel or right wheel)
Degree minute (Decimal degree)Minimum 0′ (0°)
Nominal In 3′ (0.05°)
Maximum In 6′ (0.10°)
Swing torqueTransverse link 0.5 - 3.6 N·m (0.06 - 0.36 kg-m, 5 - 31 in-lb)
Upper link 0 - 2.0 N·m (0 - 0.2 kg-m, 0 - 17 in-lb)
Measurement on spring balanceTransverse link 7.8 - 56.3 N (0.8 - 5.7 kg, 1.8 - 12.5 lb)
Upper link 0 - 61.5 N (0 - 6.2 kg, 0 - 13.6 lb)
Rotating torqueTransverse link 0.5 - 3.9 N·m (0.06 - 0.39 kg-m, 5 - 34 in-lb)
Upper link 0 - 2.0 N·m (0 - 0.2 kg-m, 0 - 17 in-lb)
Axial end play0 mm (0 in)
Page 3125 of 4647
FSU-20
[2WD]
SERVICE DATA AND SPECIFICATIONS (SDS)
Revision: 2007 April2007 M35/M45
Wheelarch Height (Unladen*)NES000IL
*: Fuel, engine coolant and lubricant are full. Spare tire, jack, hand tools and mats are in designated positions.Tire size 245/45R18 245/40R19
Front (Hf)USA 717 mm (28.23 in)
721 mm (28.39 in)
CANADA 718 mm (28.27 in)
Rear (Hr)USA 710 mm (27.95 in)
711 mm (27.99 in)
CANADA 711 mm (27.99 in)
SFA818A
