Page 4425 of 4647

SRS-44
SPIRAL CABLE
Revision: 2007 April2007 M35/M45
SPIRAL CABLEPFP:25554
Removal and InstallationNHS0009D
REMOVAL
CAUTION:
Before servicing, turn ignition switch OFF, disconnect both battery terminal and wait at least 3
minutes.
Do not use air tools or electric tools for servicing.
Do not disassemble the spiral cable.
Do not arrow oil, grease, detergent or water to come in contact with the spiral cable.
Do not make an impact to the spiral cable by dropping etc. Replace the spiral cable if it has been
dropped or sustained an impact.
1. Remove the air bag module. Refer to SRS-42, "
Removal and Installation" .
2. Remove the steering wheel. Refer to PS-12, "
Removal and Installation" .
3. Remove the column cover.
4. Remove the wiper washer switch, then remove light and turn signal switch from the spiral cable.
5. Remove the spiral cable.
Disconnect the horn switch connector (shown as A in the fig-
ure).
Disconnect the spiral cable connector (shown as B in the fig-
ure).
Loosen the spiral cable fixing screws.
Shift the spiral cable forward a bit while pushing the pawl
located above the spiral cable.
Disconnect the steering wheel switch connector (shown as C
in the figure).
NOTE:
Disconnect the spiral cable connector after disconnecting the
horn switch connector.
INSTALLATION
Install in the reverse order of removal.
P H I A 111 2 E
1. Steering wheel 2. Steering column cover (lower) 3. Light and turn signalswitchs
4. Wiper washer switch 5. Spiral cable 6. Steering column cover (upper)
7. Steering column assembly 8. Driver air bag module connector
PHIA0886J
Page 4426 of 4647

SPIRAL CABLE
SRS-45
C
D
E
F
G
I
J
K
L
MA
B
SRS
Revision: 2007 April2007 M35/M45
CAUTION:
The spiral cable may snap by steering operation if the cable
is installed in an improper position.
The neutral position is set as follows.
Turn quietly the spiral cable clockwise to the end position.
Then turn it counterclockwise (about 2 and harf turns) and
stop turning at the point on which the stopper insertion
holes are in the same position.
The service part is installed in the neutral position by the
stopper and can be set without adjusting after the stopper
is removed.
Do not turn the spiral cable rashly and also beyond the limit
number of turns. (These will cause cable snap.)
Adjust the spiral cable locating pin (showed as A inthe fig-
ure) to the steering wheel locating pin hole (showed as C in
the figuer).
Secure the air bag harness with the harness fixing hook.
After the work is completed, make sure no system malfunc-
tion is detected by air bag warning lamp.
In case that malfunction is detected by the air bag warning
lamp, reset by the self-diagnosis function and delete the
memory by CONSULT−II.
In case that malfunction is still detected after the above
operation, perform self-diagnosis to repair malfunctions.
Refer to SRS-20, "
SRS Operation Check" .
PHIA0887J
Page 4427 of 4647

SRS-46
FRONT PASSENGER AIR BAG MODULE
Revision: 2007 April2007 M35/M45
FRONT PASSENGER AIR BAG MODULEPFP:K8515
Removal and InstallationNHS0009E
REMOVAL
CAUTION:
Before servicing, turn ignition switch OFF, disconnect both battery terminal and wait at
least 3 minutes.
Do not use air tools or electric tools for servicing.
Always work from the side of air bag module. Do not work from the front of it.
Always place air bag module with pad side facing upward.
Do not use old fixing bolts after removal; replace with new bolts.
Do not make an impact to the air bag module by dropping etc. Replace the air bag module if it has
been dropped or sustained an impact.
1. Remove the instrument panel & pad assemblies. Refer to IP-10,
"INSTRUMENT PANEL ASSEMBLY" .
NOTE:
The figure shows installed condition of the front passenger air
bag module. (Under view of the module installed without glove
box cover.)
2. Remove the front passenger air bag module from the instrument panel & pad assemblies.
Remove the 2 screws.
Remove the air bag from the rear side hook. ( shows the
backward direction of the vehicle.)
INSTALLATION
Install in the reverse order of removal.
CAUTION:
Be careful not to damage the harness while installing.
After the work is completed, make sure no system malfunction is detected by air bag warning
lamp.
In case that malfunction is detected by the air bag warning lamp, reset by the self-diagnosis func-
tion and delete the memory by CONSOULT−II.
In case that malfunction is still detected after the above operation, peform self-diagnosis to repair
malfunctions. Refer to SRS-20, "
SRS Operation Check" . Passenger air bag module connector-A
Passenger air bag module fixing bolt-B
Fixing bolt
: 24.5 N·m (2.5 kg−m, 18 ft−lb)
PHIA0868J
PHIA0888J
Page 4428 of 4647

SIDE CURTAIN AIR BAG MODULE
SRS-47
C
D
E
F
G
I
J
K
L
MA
B
SRS
Revision: 2007 April2007 M35/M45
SIDE CURTAIN AIR BAG MODULEPFP:985P0
Removal and InstallationNHS0009F
REMOVAL
CAUTION:
Before servicing, turn ignition switch OFF, disconnect both battery terminal and wait at least 3
minutes.
Do not use air tools or electric tools for servicing.
Leave the curtain air bag module with air bag deployment side facing upward.
Do not make an impact to the air bag module by dropping etc. Replace the air bag module if it has
been dropped or sustained an impact.
1. Remove the curtain air bag module.
Remove the headlining. Refer to EI-52, "HEADLINING" .
Remove the side curtain air bag module connector.
NOTE:
For installing / removing side curtain air bag module con-
nector, insert thin screwdriver wrapped in tape into notch,
lift lock and remove connector.
Install connector with lock raised, and push lock into con-
nector.
After installing the connector, make sure that the lock is
pushed securely into it.
Remove the curtain air bag module fixing bolts, then remove the ground bolt.
P H I A 111 5 E
1. Side curtain air bag module A Ground bolt
PHIA0953J
Fixing bolt ( )
: 10.8 N·m (1.1 kg−m, 8 ft−lb)
Ground bolt A
: 10.8 N·m (1.1 kg−m, 8 ft−lb)
Page 4429 of 4647
SRS-48
SIDE CURTAIN AIR BAG MODULE
Revision: 2007 April2007 M35/M45
INSTALLATION
Install in the reverse order of removal.
CAUTION:
Be careful not to damage the air bag harness.
After the work is completed, make sure no system malfunction is detected by air bag warning
lamp.
In case that malfunction is detected by the air bag warning lamp, reset by the self-diagnosis func-
tion and delete the memory by CONSULT-ll.
In case that malfunction is still detected after the avove operation, perform self-diagnosis to repair
malfunctions. Refer to SRS-20, "
SRS Operation Check" .
Page 4430 of 4647

CRASH ZONE SENSOR
SRS-49
C
D
E
F
G
I
J
K
L
MA
B
SRS
Revision: 2007 April2007 M35/M45
CRASH ZONE SENSORPFP:98531
Removal and InstallationNHS0009G
REMOVAL
CAUTION:
Before servicing, turn ignition switch OFF, disconnect both battery terminal and wait at least 3
minutes.
Do not use air tools or electric tools for servicing.
Do not use old fixing nuts after removal; replace with new nuts.
Do not make an impact to the crash zone sensor by dropping etc. Replace the crash zone sensor if
it has been dropped or sustained an impact.
Replace the crash zone sensor of deployed SRS driver air bag and deployed SRS front passenger
air bag.
1. Remove the crash zone sensor.
Remove the front grille. Refer to EI-16, "Removal and Installation" .
Remove the crash zone sensor fixing nuts.
Disconnect the crash zone sensor harness connector.
INSTALLATION
Install in the reverse order of removal.
CAUTION:
Be careful not to damage the crash zone sensor harness.
After the work is completed, make sure no system malfunction is detected by air bag warning
lamp.
In case that malfunction is detected by the air bag warning lamp, reset by the self-diagnosis func-
tion and delete the memory by CONSULT−ll.
In case that malfunction is still detected after the above operation, perform self-diagnosis to repair
malfunctions. Refer to SRS-20, "
SRS Operation Check" . Fixing nut
: 10.8 N·m (1.1 kg−m, 8 ft−lb)
PHIA1116E
Page 4431 of 4647

SRS-50
SIDE AIR BAG (SATELLITE) SENSOR
Revision: 2007 April2007 M35/M45
SIDE AIR BAG (SATELLITE) SENSORPFP:98830
Removal and InstallationNHS0009H
REMOVAL
CAUTION:
Before servicing, turn ignition switch OFF, disconnect both battery terminal and wait at least 3
minutes.
Do not use air tools or electric tools for servicing.
Do not use old fixing nuts after removal; replace with new nuts.
Do not make an impact to the side air bag (satellite) sensor by dropping etc. Replace the side air
bag (satellite) sensor if it has been dropped or sustained an impact.
Replace the satellite sensor of deployed SRS front side air bag and deployed SRS side curtain air
bag.
1. Remove the side air bag (Satellite) sensor.
Remove front seat belt. Refer to SB-29, "Removal and Installation of Front Seat Belt" .
Remove fixing nuts, then remove side air bag (Satellite) sen-
sor.
Disconnect the side air bag (Satellite) sensor harness con-
nector.
INSTALLATION
Install in the reverse order of removal.
CAUTION:
Be careful not to damage the satellite sensor harness.
After the work is completed, make sure no system malfunction is detected by air bag warning
lamp.
In case that malfunction is detected by the air bag warning lamp, reset by the self-diagnosis func-
tion and delete the memory by CONSULT−ll.
In case that malfunction is still detected after the above operation, perform self-diagnosis to repair
malfunctions. Refer to SRS-20, "
SRS Operation Check" . Fixing nut
: 10.8 N·m (1.1 kg−m, 8 ft−lb)
PHIA0902J
Page 4432 of 4647
FRONT SEAT BELT PRE-TENSIONER
SRS-51
C
D
E
F
G
I
J
K
L
MA
B
SRS
Revision: 2007 April2007 M35/M45
FRONT SEAT BELT PRE-TENSIONERPFP:86884
Removal and InstallationNHS0009I
For removal and installation procedures, refer to SB-29, "Removal and Installation of Front Seat Belt" .
