Page 97 of 4647

INFINITI M35 2007 Factory Service Manual AT-18 A/T CONTROL SYSTEM Revision: 2007 April2007 M35/M45 Cross-Sectional View (VK45DE Models for 2WD)NCS001JM 1. Front planetary gear 2. Mid planetary gear 3. Rear planetary gear 4. Direct clutch 5.

Page 98 of 4647

INFINITI M35 2007 Factory Service Manual A/T CONTROL SYSTEM AT-19 D E F G H I J K L MA B AT Revision: 2007 April2007 M35/M45 Cross-Sectional View (AWD Models)NCS001JN 1. Front planetary gear 2. Mid planetary gear 3. Rear planetary gear 4. Di

Page 99 of 4647

INFINITI M35 2007 Factory Service Manual AT-20 A/T CONTROL SYSTEM Revision: 2007 April2007 M35/M45 Shift MechanismNCS001JO The A/T uses compact triple planetary gear systems to improve power transmission efficiency, simplify con- struction a

Page 100 of 4647

INFINITI M35 2007 Factory Service Manual A/T CONTROL SYSTEM AT-21 D E F G H I J K L MA B AT Revision: 2007 April2007 M35/M45 CLUTCH AND BAND CHART SCIA6962E

Page 101 of 4647

INFINITI M35 2007 Factory Service Manual AT-22 A/T CONTROL SYSTEM Revision: 2007 April2007 M35/M45 POWER TRANSMISSION “N” Position Since both the forward brake and the reverse brake are released, torque from the input shaft drive is not

Page 102 of 4647

INFINITI M35 2007 Factory Service Manual A/T CONTROL SYSTEM AT-23 D E F G H I J K L MA B AT Revision: 2007 April2007 M35/M45 “D1 ” Position The forward brake and the forward one-way clutch regulate reverse rotation of the mid sun gear.

Page 103 of 4647

INFINITI M35 2007 Factory Service Manual AT-24 A/T CONTROL SYSTEM Revision: 2007 April2007 M35/M45 “M1” Position The front brake fastens the front sun gear. The forward brake and the forward one-way clutch regulate reverse rotation of

Page 104 of 4647

INFINITI M35 2007 Factory Service Manual A/T CONTROL SYSTEM AT-25 D E F G H I J K L MA B AT Revision: 2007 April2007 M35/M45 “D2 ” Position The forward brake and the forward one-way clutch regulate reverse rotation of the mid sun gear.
