TROUBLE DIAGNOSIS
Revision: 2007 April2007 M35/M45
Circuit DiagramNBS004T4
TBWT1468E
Page 1642 of 4647
TROUBLE DIAGNOSIS
EC-113
[VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: 2007 April2007 M35/M45
TBWT1469E
Page 1643 of 4647
![INFINITI M35 2007 Factory Service Manual EC-114
[VQ35DE]
TROUBLE DIAGNOSIS
Revision: 2007 April2007 M35/M45
ECM Harness Connector Terminal LayoutNBS004T5
ECM Terminals and Reference ValueNBS004T6
PREPARATION
1. ECM (1) is located behind the INFINITI M35 2007 Factory Service Manual EC-114
[VQ35DE]
TROUBLE DIAGNOSIS
Revision: 2007 April2007 M35/M45
ECM Harness Connector Terminal LayoutNBS004T5
ECM Terminals and Reference ValueNBS004T6
PREPARATION
1. ECM (1) is located behind the](/manual-img/42/57024/w960_57024-1642.png)
EC-114
[VQ35DE]
TROUBLE DIAGNOSIS
Revision: 2007 April2007 M35/M45
ECM Harness Connector Terminal LayoutNBS004T5
ECM Terminals and Reference ValueNBS004T6
PREPARATION
1. ECM (1) is located behind the passenger side instrument lower
panel. For this inspection, remove passenger side instrument
lower panel.
2. Remove ECM harness connector.
3. When disconnecting ECM harness connector, loosen (A) it with
levers (2) as far as they will go as shown in the figure.
ECM (1)
Fasten (B)
4. Connect a break-out box (SST) and Y-cable adapter (SST)
between the ECM and ECM harness connector.
Use extreme care not to touch 2 pins at one time.
Data is for comparison and may not be exact.
ECM INSPECTION TABLE
Specification data are reference values and are measured between each terminal and ground.
Pulse signal is measured by CONSULT-II.
CAUTION:
Do not use ECM ground terminals when measuring input/output voltage. Doing so may result in dam-
age to the ECMs transistor. Use a ground other than ECM terminals, such as the ground.
MBIB0045E
PBIB2703E
PBIB2714E
TER-
MINAL
NO.WIRE
COLORITEM CONDITION DATA (DC Voltage)
