Page 161 of 4647

AT-82
TROUBLE DIAGNOSIS
Revision: 2007 April2007 M35/M45
45
Slips/Will
Not
EngageWith selector lever in
“D” position, driving is
not possible.ON vehicle1. A/T fluid level and stateAT- 5 3
2. Line pressure testAT- 5 5
3. PNP switchAT- 11 3
4. A/T positionAT- 2 2 7
5. Control valve with TCMAT- 2 3 6
OFF vehicle6. Torque converterAT- 3 0 1
7. Oil pump assemblyAT- 3 2 2
8. 1st one-way clutchAT- 3 3 3
9. Gear systemAT- 2 8 1
10. Reverse brakeAT- 3 0 1
11. Forward one-way clutch (Parts behind drum support is
impossible to perform inspection by disassembly. Refer to
AT-17, "
Cross-Sectional View (VQ35DE Models for 2WD)" ,
AT-18, "
Cross-Sectional View (VK45DE Models for 2WD)" or
AT-19, "
Cross-Sectional View (AWD Models)" .)AT- 3 0 1
12. Forward brake (Parts behind drum support is impossible
to perform inspection by disassembly. Refer to AT-17,
"Cross-Sectional View (VQ35DE Models for 2WD)" , AT-18,
"Cross-Sectional View (VK45DE Models for 2WD)" o r AT-19,
"Cross-Sectional View (AWD Models)" .)AT- 3 0 1
46With selector lever in
“R” position, driving is
not possible.ON vehicle1. A/T fluid level and stateAT- 5 3
2. Line pressure testAT- 5 5
3. PNP switchAT- 11 3
4. A/T positionAT- 2 2 7
5. Control valve with TCMAT- 2 3 6
OFF vehicle6. Gear systemAT- 2 8 17. Output shaftAT- 3 0 1
8. Reverse brakeAT- 3 0 1
47Does Not
ChangeDoes not change M5
→ M4.
Refer to AT-214, "A/T
Does Not Shift: 5th
Gear → 4th Gear" .ON vehicle1. PNP switchAT- 11 3
2. A/T fluid level and stateAT- 5 3
3. A/T positionAT- 2 2 7
4. Manual mode switchAT- 1 6 7
5. ATF pressure switch 1AT- 1 7 2
6. CAN communication lineAT- 1 0 5
7. Control valve with TCMAT- 2 3 6
OFF vehicle 8. Front brake (brake band)AT- 3 0 1
No. Item Symptom Condition Diagnostic ItemReference
page
Page 162 of 4647

TROUBLE DIAGNOSIS
AT-83
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: 2007 April2007 M35/M4548
Does Not
ChangeDoes not change M4
→ M3.
Refer to AT-215, "A/T
Does Not Shift: 4th
Gear → 3rd Gear" .ON vehicle1. PNP switchAT- 11 3
2. A/T fluid level and stateAT- 5 3
3. A/T positionAT-227
4. Manual mode switchAT-167
5. ATF pressure switch 1 and ATF pressure switch 3AT-172,
AT-174
6. CAN communication lineAT-105
7. Control valve with TCMAT-236
OFF vehicle8. Front brake (brake band)AT-3019. Input clutchAT-327
49Does not change M3
→ M2.
Refer to AT-217, "A/T
Does Not Shift: 3rd
Gear → 2nd Gear" .ON vehicle1. PNP switchAT- 11 3
2. A/T fluid level and stateAT- 5 3
3. A/T positionAT-227
4. Manual mode switchAT-167
5. ATF pressure switch 6AT-178
6. CAN communication lineAT-105
7. Control valve with TCMAT-236
OFF vehicle8. Front brake (brake band)AT-3019. Input clutchAT-327
10. High and low reverse clutchAT-339
50Does not change M2
→ M1.
Refer to AT-218, "A/T
Does Not Shift: 2nd
Gear → 1st Gear" .ON vehicle1. PNP switchAT- 11 3
2. A/T fluid level and stateAT- 5 3
3. A/T positionAT-227
4. Manual mode switchAT-167
5. ATF pressure switch 5AT-176
6. CAN communication lineAT-105
7. Control valve with TCMAT-236
OFF vehicle8. Input clutchAT-3279. High and low reverse clutchAT-339
10. Direct clutchAT-341
51Cannot be changed to
manual mode.
Refer to AT-213,
"Cannot Be Changed
to Manual Mode" .ON vehicle1. Manual mode switchAT-167
2. Turbine revolution sensorAT- 11 7
3. CAN communication lineAT-105
52 OthersShift point is high in
“D” position.ON vehicle1. Vehicle speed sensor·A/T and vehicle speed sensor·MTRAT- 11 9
,
AT-140
2. Accelerator pedal position sensorAT-132
3. CAN communication lineAT-105
4. A/T fluid temperature sensorAT-135
5. Control valve with TCMAT-236
No. Item Symptom Condition Diagnostic ItemReference
page
Page 163 of 4647

AT-84
TROUBLE DIAGNOSIS
Revision: 2007 April2007 M35/M45
53
OthersShift point is low in “D”
position.ON vehicle1. Vehicle speed sensor·A/T and vehicle speed sensor·MTRAT- 11 9
,
AT- 1 4 0
2. Accelerator pedal position sensorAT- 1 3 2
3. CAN communication lineAT- 1 0 5
4. Control valve with TCMAT- 2 3 6
54Judder occurs during
lock-up.ON vehicle1. A/T fluid level and stateAT- 5 3
2. Engine speed signalAT- 1 2 4
3. Turbine revolution sensorAT- 11 7
4. Vehicle speed sensor·A/T and vehicle speed sensor·MTRAT- 11 9,
AT- 1 4 0
5. Accelerator pedal position sensorAT- 1 3 2
6. CAN communication lineAT- 1 0 5
7. Torque converter clutch solenoid valveAT- 1 2 6
8. Control valve with TCMAT- 2 3 6
OFF vehicle 9. Torque converterAT- 3 0 1
55Strange noise in “R”
position.ON vehicle1. A/T fluid level and stateAT- 5 3
2. Engine speed signalAT- 1 2 4
3. CAN communication lineAT- 1 0 5
4. Control valve with TCMAT- 2 3 6
OFF vehicle5. Torque converterAT- 3 0 1
6. Oil pump assemblyAT- 3 2 2
7. Gear systemAT- 2 8 1
8. High and low reverse clutchAT- 3 3 9
9. Reverse brakeAT- 3 0 1
56Strange noise in “N”
position.ON vehicle1. A/T fluid level and stateAT- 5 3
2. Engine speed signalAT- 1 2 4
3. CAN communication lineAT- 1 0 5
4. Control valve with TCMAT- 2 3 6
OFF vehicle5. Torque converterAT- 3 0 16. Oil pump assemblyAT- 3 2 2
7. Gear systemAT- 2 8 1
No. Item Symptom Condition Diagnostic ItemReference
page
Page 164 of 4647

TROUBLE DIAGNOSIS
AT-85
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: 2007 April2007 M35/M45
57
OthersStrange noise in “D”
position.ON vehicle1. A/T fluid level and stateAT- 5 3
2. Engine speed signalAT-124
3. CAN communication lineAT-105
4. Control valve with TCMAT-236
OFF vehicle5. Torque converterAT-301
6. Oil pump assemblyAT-322
7. Gear systemAT-281
8. Forward brake (Parts behind drum support is impossible
to perform inspection by disassembly. Refer to AT-17,
"Cross-Sectional View (VQ35DE Models for 2WD)" , AT- 1 8 ,
"Cross-Sectional View (VK45DE Models for 2WD)" o r AT- 1 9 ,
"Cross-Sectional View (AWD Models)" .)AT-301
58Vehicle dose not
decelerate by engine
brake.
Refer to AT-220,
"Vehicle Does Not
Decelerate by Engine
Brake" .ON vehicle1. PNP switchAT- 11 3
2. A/T fluid level and stateAT- 5 3
3. A/T positionAT-227
4. Manual mode switchAT-167
5. ATF pressure switch 5AT-176
6. CAN communication lineAT-105
7. Control valve with TCMAT-236
OFF vehicle8. Input clutchAT-3279. High and low reverse clutchAT-339
10. Direct clutchAT-341
59Engine brake does
not work M5 → M4.ON vehicle1. PNP switchAT- 11 3
2. A/T fluid level and stateAT- 5 3
3. A/T positionAT-227
4. Manual mode switchAT-167
5. ATF pressure switch 1AT-172
6. CAN communication lineAT-105
7. Control valve with TCMAT-236
OFF vehicle 8. Front brake (brake band) AT-301
60Engine brake does
not work M4 → M3.ON vehicle1. PNP switchAT- 11 3
2. A/T fluid level and stateAT- 5 3
3. A/T positionAT-227
4. Manual mode switchAT-167
5. ATF pressure switch 1 and ATF pressure switch 3AT-172,
AT-174
6. CAN communication lineAT-105
7. Control valve with TCMAT-236
OFF vehicle8. Front brake (brake band)AT-3019. Input clutchAT-327
No. Item Symptom Condition Diagnostic ItemReference
page
Page 165 of 4647

AT-86
TROUBLE DIAGNOSIS
Revision: 2007 April2007 M35/M45
61
OthersEngine brake does
not work M3 → M2.ON vehicle1. PNP switchAT- 11 3
2. A/T fluid level and stateAT- 5 3
3. A/T positionAT- 2 2 7
4. Manual mode switchAT- 1 6 7
5. ATF pressure switch 6AT- 1 7 8
6. CAN communication lineAT- 1 0 5
7. Control valve with TCMAT- 2 3 6
OFF vehicle8. Front brake (brake band)AT- 3 0 19. Input clutchAT- 3 2 7
10. High and low reverse clutchAT- 3 3 9
62Engine brake does
not work M2 → M1.ON vehicle1. PNP switchAT- 11 3
2. A/T fluid level and stateAT- 5 3
3. A/T positionAT- 2 2 7
4. Manual mode switchAT- 1 6 7
5. ATF pressure switch 5AT- 1 7 6
6. CAN communication lineAT- 1 0 5
7. Control valve with TCMAT- 2 3 6
OFF vehicle8. Input clutchAT- 3 2 79. High and low reverse clutchAT- 3 3 9
10. Direct clutchAT- 3 4 1
63 Maximum speed low.ON vehicle1. A/T fluid level and stateAT- 5 3
2. Line pressure testAT- 5 5
3. Accelerator pedal position sensorAT- 1 3 2
4. CAN communication lineAT- 1 0 5
5. Direct clutch solenoid valveAT- 1 5 5
6. Control valve with TCMAT- 2 3 6
OFF vehicle7. Torque converter AT- 3 0 1
8. Oil pump assemblyAT- 3 2 2
9. Input clutchAT- 3 2 7
10. Gear systemAT- 2 8 1
11. High and low reverse clutchAT- 3 3 9
12. Direct clutchAT- 3 4 1
13. Forward one-way clutch (Parts behind drum support is
impossible to perform inspection by disassembly. Refer to
AT-17, "
Cross-Sectional View (VQ35DE Models for 2WD)" ,
AT-18, "
Cross-Sectional View (VK45DE Models for 2WD)" or
AT-19, "
Cross-Sectional View (AWD Models)" .)AT- 3 0 1
14. Forward brake (Parts behind drum support is impossible
to perform inspection by disassembly. Refer to AT-17,
"Cross-Sectional View (VQ35DE Models for 2WD)" , AT-18,
"Cross-Sectional View (VK45DE Models for 2WD)" o r AT-19,
"Cross-Sectional View (AWD Models)" .)AT- 3 0 1
No. Item Symptom Condition Diagnostic ItemReference
page
Page 166 of 4647

TROUBLE DIAGNOSIS
AT-87
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: 2007 April2007 M35/M4564
OthersExtremely large
creep.ON vehicle1. Engine idle speed EC-83
(for
VQ35DE
engine),
EC-785
(for
VK45DE
engine)
2. CAN communication lineAT-105
3. ATF pressure switch 5AT-176
OFF vehicle 4. Torque converterAT-301
65With selector lever in
“P” position, vehicle
does not enter parking
condition or, with
selector lever in
another position, park-
ing condition is not
cancelled.
Refer to AT-191, "
In
“P” Position, Vehicle
Moves When Pushed"
.ON vehicle1. PNP switchAT- 11 3
2. A/T positionAT-227
OFF vehicle 3. Parking componentsAT-250
(2WD
models) or
AT-301
(AWD
models)
66Vehicle runs with A/T
in “P” position.ON vehicle1. PNP switchAT- 11 3
2. A/T fluid level and stateAT- 5 3
3. A/T positionAT-227
4. Control valve with TCMAT-236
OFF vehicle5. Parking componentsAT-250
(2WD
models) or
AT-301
(AWD
models)
6. Gear systemAT-281
67Vehicle runs with A/T
in “N” position.
Refer to AT-192, "In
“N” Position, Vehicle
Moves" .ON vehicle1. PNP switchAT- 11 3
2. A/T fluid level and stateAT- 5 3
3. A/T positionAT-227
4. Control valve with TCMAT-236
OFF vehicle5. Input clutchAT-327
6. Gear systemAT-281
7. Direct clutchAT-341
8. Reverse brakeAT-301
9. Forward one-way clutch (Parts behind drum support is
impossible to perform inspection by disassembly. Refer to
AT- 1 7 , "
Cross-Sectional View (VQ35DE Models for 2WD)" ,
AT- 1 8 , "
Cross-Sectional View (VK45DE Models for 2WD)" or
AT- 1 9 , "
Cross-Sectional View (AWD Models)" .)AT-301
10. Forward brake (Parts behind drum support is impossible
to perform inspection by disassembly. Refer to AT-17,
"Cross-Sectional View (VQ35DE Models for 2WD)" , AT- 1 8 ,
"Cross-Sectional View (VK45DE Models for 2WD)" o r AT- 1 9 ,
"Cross-Sectional View (AWD Models)" .)AT-301
No. Item Symptom Condition Diagnostic ItemReference
page
Page 167 of 4647

AT-88
TROUBLE DIAGNOSIS
Revision: 2007 April2007 M35/M45
68
OthersEngine does not start
in “N” or “P” position.
Refer to AT-190, "Engine Cannot Be
Started in “P” or “N”
Position" .ON vehicle1. Push-button ignition switch and starterPG-3
, SC-
8
2. A/T positionAT- 2 2 7
3. PNP switchAT- 11 3
69Engine starts in posi-
tions other than “N” or
“P”.ON vehicle1. Push-button ignition switch and starterPG-3
, SC-
8
2. A/T positionAT- 2 2 7
3. PNP switchAT- 11 3
70 Engine stall.ON vehicle1. A/T fluid level and stateAT- 5 3
2. Engine speed signalAT- 1 2 4
3. Turbine revolution sensorAT- 11 7
4. Torque converter clutch solenoid valveAT- 1 2 6
5. CAN communication lineAT- 1 0 5
6. Control valve with TCMAT- 2 3 6
OFF vehicle 7. Torque converterAT- 3 0 1
71Engine stalls when
selector lever shifted
“N” → “D”or “R”.ON vehicle1. A/T fluid level and stateAT- 5 3
2. Engine speed signalAT- 1 2 4
3. Turbine revolution sensorAT- 11 7
4. Torque converter clutch solenoid valveAT- 1 2 6
5. CAN communication lineAT- 1 0 5
6. Control valve with TCMAT- 2 3 6
OFF vehicle 7. Torque converterAT- 3 0 1
72Engine speed does
not return to idle.
Refer to AT-212,
"Engine Speed Does
Not Return to Idle" .ON vehicle1. A/T fluid level and stateAT- 5 3
2. ATF pressure switch 5 and direct clutch solenoid valveAT- 1 7 6,
AT- 1 5 5
3. ATF pressure switch 1 and front brake solenoid valveAT- 1 7 2
,
AT- 1 5 1
4. Accelerator pedal position sensorAT- 1 3 2
5. Vehicle speed sensor·A/T and vehicle speed sensor·MTRAT- 11 9,
AT- 1 4 0
6. CAN communication lineAT- 1 0 5
7. Control valve with TCMAT- 2 3 6
OFF vehicle8. Front brake (brake band)AT- 3 0 19. Direct clutchAT- 3 4 1
No. Item Symptom Condition Diagnostic ItemReference
page
Page 168 of 4647
TROUBLE DIAGNOSIS
AT-89
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: 2007 April2007 M35/M45
TCM Input/Output Signal Reference ValuesNCS001KG
A/T ASSEMBLY HARNESS CONNECTOR TERMINAL LAYOUT
TCM INSPECTION TABLE
Data are reference value and are measured between each terminal and ground.
SCIA1658E
TerminalWire
colorItem Condition Data (Approx.)
1R/WPower supply
(Memory back-up)Always Battery voltage
2R/WPower supply
(Memory back-up)Always Battery voltage
3 L CAN-H – –
4VK-line (CONSULT-
II signal)The terminal is connected to the data link connector for CONSULT-II. –
5 B Ground Always 0 V
6 Y/R Power supply– Battery voltage
–0 V
7R/LBack-up lamp
relaySelector lever in “R” position. 0 V
Selector lever in other positions. Battery voltage
8 P CAN-L – –
9GR/RStarter relaySelector lever in “N”, “P” positions. Battery voltage
Selector lever in “R”, “D” positions. 0 V
10 B Ground Always 0 V
