Page 3009 of 4647

INFINITI M35 2007 Factory Service Manual EI-38 BODY SIDE TRIM Revision: 2007 April2007 M35/M45 FRONT PILLAR GARNISH Removal Remove pillar garnish mounting clips using a clip clamp remover, and then remove pillar garnish. Installation Install

Page 3010 of 4647

INFINITI M35 2007 Factory Service Manual BODY SIDE TRIM EI-39 C D E F G H J K L MA B EI Revision: 2007 April2007 M35/M45 FRONT BODY SIDE WELT Removal 1. Remove center pillar lower garnish. 2. Remove center kicking plate inner. 3. Remove fron

Page 3011 of 4647

INFINITI M35 2007 Factory Service Manual EI-40 BODY SIDE TRIM Revision: 2007 April2007 M35/M45 REAR KICKING PLATE OUTER Removal Remove rear kicking plate outer mounting clips using a clip clamp remover, and then remove kicking plate outer. I

Page 3012 of 4647

INFINITI M35 2007 Factory Service Manual BODY SIDE TRIM EI-41 C D E F G H J K L MA B EI Revision: 2007 April2007 M35/M45 REAR WHEEL HOUSE GARNISH Removal 1. Remove rear seat cushion and rear seatback. Refer to SE-177, "Removal and Installati

Page 3013 of 4647

INFINITI M35 2007 Factory Service Manual EI-42 REAR PARCEL SHELF FINISHER Revision: 2007 April2007 M35/M45 REAR PARCEL SHELF FINISHERPFP:79910 Removal and InstallationNIS0024W REMOVAL 1. Remove rear seatback and rear seat cushion. Refer to S

Page 3014 of 4647

INFINITI M35 2007 Factory Service Manual REAR PARCEL SHELF FINISHER EI-43 C D E F G H J K L MA B EI Revision: 2007 April2007 M35/M45 4. Remove rear kicking plate inner, rear wheelhouse garnish, rear pillar finisher. Refer to EI-37, "BODY SID

Page 3015 of 4647

INFINITI M35 2007 Factory Service Manual EI-44 SUNSHADE Revision: 2007 April2007 M35/M45 SUNSHADEPFP:97580 Component Parts and Harness Connector LocationNIS0024Y PIIB5864E 1. Fuse block (J/B) 2. Back-up lamp relay E19 3.Rear sunshade cancel

Page 3016 of 4647

INFINITI M35 2007 Factory Service Manual SUNSHADE EI-45 C D E F G H J K L MA B EI Revision: 2007 April2007 M35/M45 SchematicNIS0024Z TIWT1338E
