Page 3233 of 4647

INFINITI M35 2007 Factory Service Manual GW-34 POWER WINDOW SYSTEM Revision: 2007 April2007 M35/M45 4. CHECK BCM OUTPUT SIGNAL 1. Connect BCM connector. 2. Turn ignition switch ON. 3. Check voltage between BCM connector and ground. OK or N

Page 3234 of 4647

INFINITI M35 2007 Factory Service Manual POWER WINDOW SYSTEM GW-35 C D E F G H J K L MA B GW Revision: 2007 April2007 M35/M45 3. CHECK HARNESS CONTINUITY 1. Disconnect BCM and power window sub-switch (front passenger side) connector. 2. Che

Page 3235 of 4647

INFINITI M35 2007 Factory Service Manual GW-36 POWER WINDOW SYSTEM Revision: 2007 April2007 M35/M45 3. CHECK HARNESS CONTINUITY 1. Disconnect BCM and power window sub-switch (rear LH or RH) connector. 2. Check continuity between BCM connecto

Page 3236 of 4647

INFINITI M35 2007 Factory Service Manual POWER WINDOW SYSTEM GW-37 C D E F G H J K L MA B GW Revision: 2007 April2007 M35/M45 2. CHECK HARNESS CONTINUITY 1. Turn ignition switch OFF. 2. Disconnect power window main switch and power window mo

Page 3237 of 4647

INFINITI M35 2007 Factory Service Manual GW-38 POWER WINDOW SYSTEM Revision: 2007 April2007 M35/M45 2. CHECK HARNESS CONTINUITY 1. Turn ignition switch OFF. 2. Disconnect power window sub-switch (front passenger side) and power window motor

Page 3238 of 4647

INFINITI M35 2007 Factory Service Manual POWER WINDOW SYSTEM GW-39 C D E F G H J K L MA B GW Revision: 2007 April2007 M35/M45 2. CHECK HARNESS CONTINUITY 1. Turn ignition switch OFF. 2. Disconnect power window sub-switch (rear LH or RH) and

Page 3239 of 4647

INFINITI M35 2007 Factory Service Manual GW-40 POWER WINDOW SYSTEM Revision: 2007 April2007 M35/M45 Check encoder Circuit (Driver Side) NIS0021Y 1. CHECK POWER WINDOW MOTOR (FRONT DRIVER SIDE) POWER SUPPLY 1. Turn ignition switch ON. 2. Chec

Page 3240 of 4647

INFINITI M35 2007 Factory Service Manual POWER WINDOW SYSTEM GW-41 C D E F G H J K L MA B GW Revision: 2007 April2007 M35/M45 3. CHECK GROUND CIRCUIT 1. Turn ignition switch OFF. 2. Disconnect power window motor (front driver side) connector
