Page 2273 of 4647

INFINITI M35 2007 Factory Service Manual EC-744 [VK45DE] EVAPORATIVE EMISSION SYSTEM Revision: 2007 April2007 M35/M45 Component InspectionNBS0059S EVAP CANISTER Check EVAP canister as follows: 1. Block port (B). 2. Blow air into port (A) and

Page 2274 of 4647

INFINITI M35 2007 Factory Service Manual EVAPORATIVE EMISSION SYSTEM EC-745 [VK45DE] C D E F G H I J K L MA EC Revision: 2007 April2007 M35/M45 EVAP SERVICE PORT Positive pressure is delivered to the EVAP system through the EVAP service port

Page 2275 of 4647

INFINITI M35 2007 Factory Service Manual EC-746 [VK45DE] EVAPORATIVE EMISSION SYSTEM Revision: 2007 April2007 M35/M45 Improper installation of EVAP service port adapter to the EVAP service port may cause a leak. WITH CONSULT-II 1. Attach t

Page 2276 of 4647

INFINITI M35 2007 Factory Service Manual EVAPORATIVE EMISSION SYSTEM EC-747 [VK45DE] C D E F G H I J K L MA EC Revision: 2007 April2007 M35/M45 3. Apply battery voltage between the terminals of EVAP canister vent control valve (1) to make a

Page 2277 of 4647

INFINITI M35 2007 Factory Service Manual EC-748 [VK45DE] ON BOARD REFUELING VAPOR RECOVERY (ORVR) Revision: 2007 April2007 M35/M45 ON BOARD REFUELING VAPOR RECOVERY (ORVR)PFP:00032 System DescriptionNBS0059V From the beginning of refueling,

Page 2278 of 4647

INFINITI M35 2007 Factory Service Manual ON BOARD REFUELING VAPOR RECOVERY (ORVR) EC-749 [VK45DE] C D E F G H I J K L MA EC Revision: 2007 April2007 M35/M45 Diagnostic ProcedureNBS0059W SYMPTOM: FUEL ODOR FROM EVAP CANISTER IS STRONG. 1. CHE

Page 2279 of 4647

INFINITI M35 2007 Factory Service Manual EC-750 [VK45DE] ON BOARD REFUELING VAPOR RECOVERY (ORVR) Revision: 2007 April2007 M35/M45 SYMPTOM: CANNOT REFUEL/FUEL ODOR FROM THE FUEL FILLER OPENING IS STRONG WHILE REFUELING. 1. CHECK EVAP CANIST

Page 2280 of 4647

INFINITI M35 2007 Factory Service Manual ON BOARD REFUELING VAPOR RECOVERY (ORVR) EC-751 [VK45DE] C D E F G H I J K L MA EC Revision: 2007 April2007 M35/M45 7. CHECK REFUELING EVAP VAPOR CUT VALVE Refer to EC-751, " Component Inspection" . O
