INFINITI M35 2007 Factory Service Manual BRC-60
[VDC/TCS/ABS]
STEERING ANGLE SENSOR
Revision: 2007 April2007 M35/M45
STEERING ANGLE SENSORPFP:25554
Removal and InstallationNFS000RE
REMOVAL
1. Remove spiral cable assembly. Refer to SRS-44, "S

Page 1362 of 4647

INFINITI M35 2007 Factory Service Manual CO-1
ENGINE COOLING SYSTEM
B ENGINE
CONTENTS
C
D
E
F
G
H
I
J
K
L
M
SECTION CO
A
CO
Revision: 2007 April2007 M35/M45
ENGINE COOLING SYSTEM
VQ35DE
PRECAUTIONS ..........................................

CO-1
ENGINE COOLING SYSTEM
B ENGINE
CONTENTS
C
D
E
F
G
H
I
J
K
L
M
SECTION CO
A
CO
Revision: 2007 April2007 M35/M45
ENGINE COOLING SYSTEM
VQ35DE
PRECAUTIONS .......................................................... 3
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” .................................................................. 3
Precautions for Liquid Gasket .................................. 3
REMOVAL OF LIQUID GASKET SEALING .......... 3
LIQUID GASKET APPLICATION PROCEDURE ..... 3
PREPARATION ........................................................... 5
Special Service Tools ............................................... 5
Commercial Service Tools ........................................ 6
OVERHEATING CAUSE ANALYSIS .......................... 7
Troubleshooting Chart .............................................. 7
COOLING SYSTEM .................................................... 9
Cooling Circuit .......................................................... 9
System Chart ......................................................... 10
ENGINE COOLANT ...................................................11
Inspection ................................................................ 11
LEVEL CHECK .................................................... 11
LEAK CHECK ...................................................... 11
Changing Engine Coolant ....................................... 11
DRAINING ENGINE COOLANT .......................... 11
REFILLING ENGINE COOLANT ........................ 12
FLUSHING COOLING SYSTEM ......................... 13
RADIATOR ................................................................ 14
Components ........................................................... 14
Removal and Installation ........................................ 14
REMOVAL ........................................................... 14
INSTALLATION ................................................... 16
INSPECTION AFTER INSTALLATION ............... 16
Checking Radiator Cap .......................................... 16
Checking Radiator .................................................. 16
RADIATOR (ALUMINUM TYPE) .............................. 18
Components ........................................................... 18
Disassembly and Assembly ................................... 18
PREPARATION ................................................... 18
DISASSEMBLY ................................................... 18
ASSEMBLY ......................................................... 19
INSPECTION ...................................................... 21COOLING FAN .......................................................... 22
Components ........................................................... 22
Removal and Installation ........................................ 22
REMOVAL ........................................................... 22
INSTALLATION ................................................... 22
INSPECTION AFTER INSTALLATION ................ 22
Disassembly and Assembly .................................... 23
DISASSEMBLY ................................................... 23
INSPECTION AFTER DISASSEMBLY ................ 23
ASSEMBLY ......................................................... 23
WATER PUMP .......................................................... 24
Components ........................................................... 24
Removal and Installation ........................................ 24
REMOVAL ........................................................... 24
INSPECTION AFTER REMOVAL ....................... 26
INSTALLATION ................................................... 26
INSPECTION AFTER INSTALLATION ................ 28
WATER INLET AND THERMOSTAT ASSEMBLY .... 29
Components ........................................................... 29
Removal and Installation ........................................ 29
REMOVAL ........................................................... 29
INSPECTION AFTER REMOVAL ....................... 30
INSTALLATION ................................................... 30
INSPECTION AFTER INSTALLATION ................ 30
WATER OUTLET AND WATER PIPING ................... 31
Components ........................................................... 31
Removal and Installation ........................................ 31
REMOVAL ........................................................... 31
INSTALLATION ................................................... 32
INSPECTION AFTER INSTALLATION ................ 32
SERVICE DATA AND SPECIFICATIONS (SDS) ...... 33
Standard and Limit .................................................. 33
ENGINE COOLANT CAPACITY (APPROXI-
MATE) .................................................................. 33
RADIATOR .......................................................... 33
THERMOSTAT .................................................... 33

Page 1363 of 4647

INFINITI M35 2007 Factory Service Manual CO-2Revision: 2007 April2007 M35/M45
VK45DE
PRECAUTIONS ......................................................... 34
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT

CO-2Revision: 2007 April2007 M35/M45
VK45DE
PRECAUTIONS ......................................................... 34
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” ................................................................. 34
PREPARATION ......................................................... 35
Special Service Tools ............................................. 35
Commercial Service Tools ...................................... 35
OVERHEATING CAUSE ANALYSIS ........................ 36
Troubleshooting Chart ............................................ 36
COOLING SYSTEM .................................................. 38
Cooling Circuit ........................................................ 38
System Chart .......................................................... 39
ENGINE COOLANT .................................................. 40
Inspection ............................................................... 40
LEVEL CHECK .................................................... 40
LEAK CHECK ...................................................... 40
Changing Engine Coolant ....................................... 40
DRAINING ENGINE COOLANT .......................... 40
REFILLING ENGINE COOLANT ......................... 40
FLUSHING COOLING SYSTEM ......................... 42
RADIATOR ................................................................ 43
Components ........................................................... 43
Removal and Installation ........................................ 43
REMOVAL ........................................................... 43
INSTALLATION .................................................... 44
INSPECTION AFTER INSTALLATION ................ 45
Checking Radiator Cap .......................................... 45
Checking Radiator .................................................. 45
RADIATOR (ALUMINUM TYPE) ............................... 47
Components ........................................................... 47
Disassembly and Assembly .................................... 47
PREPARATION ................................................... 47
DISASSEMBLY ................................................... 47
ASSEMBLY ......................................................... 48
INSPECTION ....................................................... 50COOLING FAN .......................................................... 51
Components ............................................................ 51
Removal and Installation ......................................... 51
REMOVAL ............................................................ 51
INSTALLATION .................................................... 51
INSPECTION AFTER INSTALLATION ................ 51
Disassembly and Assembly .................................... 52
DISASSEMBLY .................................................... 52
INSPECTION AFTER DISASSEMBLY ................ 52
ASSEMBLY .......................................................... 52
WATER PUMP ........................................................... 53
Components ............................................................ 53
Removal and Installation ......................................... 53
REMOVAL ............................................................ 53
INSPECTION AFTER REMOVAL ........................ 54
INSTALLATION .................................................... 54
INSPECTION AFTER INSTALLATION ................ 54
THERMOSTAT AND WATER CONTROL VALVE ..... 55
Components ............................................................ 55
Removal and Installation ......................................... 55
REMOVAL ............................................................ 55
INSPECTION AFTER REMOVAL ........................ 56
INSTALLATION .................................................... 56
INSPECTION AFTER INSTALLATION ................ 57
SERVICE DATA AND SPECIFICATIONS (SDS) ...... 58
Standard and Limit .................................................. 58
ENGINE COOLANT CAPACITY (APPROXI-
MATE) .................................................................. 58
RADIATOR ........................................................... 58
THERMOSTAT ..................................................... 58
WATER CONTROL VALVE .................................. 58

Page 1364 of 4647

INFINITI M35 2007 Factory Service Manual PRECAUTIONS
CO-3
[VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
CO
Revision: 2007 April2007 M35/M45
[VQ35DE]PRECAUTIONSPFP:00001
Precautions for Supplemental Restraint System (SRS) “AIR BAG” and “SEAT
BELT PR

PRECAUTIONS
CO-3
[VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
CO
Revision: 2007 April2007 M35/M45
[VQ35DE]PRECAUTIONSPFP:00001
Precautions for Supplemental Restraint System (SRS) “AIR BAG” and “SEAT
BELT PRE-TENSIONER”
NBS005RT
The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the SRS and SB section of this Service Man-
ual.
WARNING:
To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death
in the event of a collision which would result in air bag inflation, all maintenance must be per-
formed by an authorized NISSAN/INFINITI dealer.
Improper maintenance, including incorrect removal and installation of the SRS, can lead to per-
sonal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air
Bag Module, see the SRS section.
Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or
harness connectors.
Precautions for Liquid GasketNBS004QK
REMOVAL OF LIQUID GASKET SEALING
After removing mounting nuts and bolts, separate the mating
surface using the seal cutter (SST) and remove old liquid gasket
sealing.
CAUTION:
Be careful not to damage the mating surfaces.
Tap the seal cutter to insert it, and then slide it by tapping on the
side as shown in the figure.
In areas where seal cutter is difficult to use, use a plastic ham-
mer to lightly tap the parts, to remove it.
CAUTION:
If for some unavoidable reason tool such as a screwdriver
is used, be careful not to damage the mating surfaces.
LIQUID GASKET APPLICATION PROCEDURE
1. Using a scraper, remove old liquid gasket adhering to the liquid
gasket application surface and the mating surface.
Remove liquid gasket completely from the groove of the liquid
gasket application surface, mounting bolts, and bolt holes.
2. Wipe the liquid gasket application surface and the mating sur-
face with white gasoline (lighting and heating use) to remove
adhering moisture, grease and foreign materials.
PBIC0002E
PBIC0003E

Page 1365 of 4647

INFINITI M35 2007 Factory Service Manual CO-4
[VQ35DE]
PRECAUTIONS
Revision: 2007 April2007 M35/M45
3. Attach liquid gasket tube to the tube presser (commercial ser-
vice tool).
Use Genuine RTV Silicone Sealant or equivalent. Refer to
GI-47,

Page 1366 of 4647

INFINITI M35 2007 Factory Service Manual PREPARATION
CO-5
[VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
CO
Revision: 2007 April2007 M35/M45
PREPARATIONPFP:00002
Special Service ToolsNBS004QL
The actual shapes of Kent-Moore tools may differ from those of s

Page 1367 of 4647

INFINITI M35 2007 Factory Service Manual CO-6
[VQ35DE]
PREPARATION
Revision: 2007 April2007 M35/M45
Commercial Service ToolsNBS004QM
Tool nameDescription
Tube presserPressing the tube of liquid gasket
Power toolLoosening nuts and bolts
Radia

Page 1368 of 4647

INFINITI M35 2007 Factory Service Manual OVERHEATING CAUSE ANALYSIS
CO-7
[VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
CO
Revision: 2007 April2007 M35/M45
OVERHEATING CAUSE ANALYSISPFP:00012
Troubleshooting ChartNBS004QN
Symptom Check items
Cooling sys-
t

Load next 8 pages
