ATC-70
TROUBLE DIAGNOSIS
Revision: 2007 April2007 M35/M45
Rear Control Switch CircuitNJS000GM
DIAGNOSIS PROCEDURE FOR REAR CONTROL SWITCH
SYMPTOM: Rear control switch does not operate.
1. CHECK A/C SYSTEM
Check multifunction switch, confirm A/C system operation.
OK or NG
OK >> GO TO 2.
NG >> Go to trouble diagnosis procedure for A/C system. Refer to AT C - 6 7 , "
Power Supply and Ground
Circuit for Auto Amp." .
2. CHECK REAR CONTROL SWITCH
Check rear control switch, except for A/C switch (audio) operation.
OK or NG
OK >> GO TO 5.
NG >> GO TO 3.
3. CHECK POWER SUPPLY FOR REAR CONTROL SWITCH
1. Turn ignition switch OFF.
2. Disconnect rear control switch connector.
3. Turn ignition switch ACC.
4. Check voltage between rear control switch harness connector
B554 terminal 1 and ground.
OK or NG
OK >> GO TO 4.
NG >> Check 10A fuse [No. 6 located in the fuse block (J/B)].
Refer to PG-114, "
FUSE BLOCK - JUNCTION BOX (J/
B)" .
If fuse is OK, check harness for open circuit. Repair or replace if necessary.
If fuse is NG, check harness for short circuit and replace fuse.
4. CHECK GROUND CIRCUIT FOR REAR CONTROL SWITCH
1. Turn ignition switch OFF.
2. Check continuity between rear control switch harness connector
B554 terminal 4 and ground.
OK or NG
OK >> GO TO 5.
NG >> Repair harness or connector.
5. CHECK REAR CONTROL SWITCH, AV CONTROL UNIT OR NAVI CONTROL UNIT
Check circuit between rear control switch and AV control unit or NAVI control unit. Refer to AV- 1 0 8 , "
TROU-
BLE DIAGNOSIS" (Without mobile entertainment system) or AV- 2 4 9 , "TROUBLE DIAGNOSIS" (With mobile
entertainment system).
OK or NG
OK >> Replace rear control switch.
NG >> Replace part or repair for result trouble diagnosis.1 – Ground : Battery voltage
RJIA3996E
4 – Ground : Continuity should exist.
RJIA3997E
Page 522 of 4647
TROUBLE DIAGNOSIS
ATC-71
C
D
E
F
G
H
I
K
L
MA
B
AT C
Revision: 2007 April2007 M35/M45
LAN System CircuitNJS000GN
SYMPTOM: Mode door motors, upper ventilator door motor, air mix door motors and intake door motor does
not operate normally.
DIAGNOSIS PROCEDURE FOR LAN CIRCUIT
1. CHECK POWER SUPPLY FOR UNIFIED METER AND A/C AMP.
1. Turn ignition switch ON.
2. Check voltage between unified meter and A/C amp. harness
connector M65 terminal 70 and ground.
OK or NG
OK >> GO TO 2.
NG >> Replace unified meter and A/C amp.
2. CHECK SIGNAL FOR UNIFIED METER AND A/C AMP.
Confirm A/C LAN signal between unified meter and A/C amp. har-
ness connector M65 terminal 69 and ground using an oscilloscope.
OK or NG
OK >> GO TO 3.
NG >> Replace unified meter and A/C amp.
RJIA4052E
70 – Ground : Battery voltage
RJIA4053E
Terminals
Vo l ta g e (+)
(−)
Unified meter and
A/C amp. connectorTerminal No.
M65 69 Ground
RJIA4054E
SJIA1453J
Page 523 of 4647

ATC-72
TROUBLE DIAGNOSIS
Revision: 2007 April2007 M35/M45
3. CHECK POWER SUPPLY FOR EACH DOOR MOTOR
Check voltage between each door motor harness connector terminal
1 and ground.
OK or NG
OK >> GO TO 4.
NG >> Repair harness or connector.
4. CHECK SIGNAL FOR EACH DOOR MOTOR
Confirm A/C LAN signal between each door motor harness connec-
tor terminal 3 and ground using an oscilloscope.
OK or NG
OK >> GO TO 5.
NG >> Repair harness or connector.
5. CHECK MOTOR GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect each door motor connector.
3. Check continuity between each door motor harness connector
terminal 2 and ground.
OK or NG
OK >> GO TO 6.
NG >> Repair harness or connector.1 – Ground : Battery voltage
RJIA1988E
Door motorTerminals
Vo l ta g e (+)
(−)
Con-
nectorTerminal
No.
Mode (Driver
side)M252 3
Ground Mode (Pas-
senger side)M255 3
Upper venti-
latorM254 3
Air mix
(Driver side)M253 3
Air mix (Pas-
senger side)M256 3
Intake M257 3
RJIA1989E
SJIA1453J
2 – Ground : Continuity should exist.
RJIA1990E
Page 524 of 4647

TROUBLE DIAGNOSIS
ATC-73
C
D
E
F
G
H
I
K
L
MA
B
AT C
Revision: 2007 April2007 M35/M45
6. CHECK MOTOR OPERATION
1. Reconnect each door motor connector.
2. Turn ignition switch ON.
3. Confirm operation of each door motor.
OK or NG
OK >> (Return to operate normally.)
Poor contact in motor connector.
NG >> (Does not operate normally.)
GO TO 7.
7. CHECK UPPER VENTILATOR DOOR MOTOR, AIR MIX DOOR MOTOR AND INTAKE DOOR MOTOR
OPERATION
1. Turn ignition switch OFF.
2. Disconnect mode (driver side, passenger side), upper ventilator, air mix (driver side, passenger side), and
intake door motor connectors.
3. Reconnect upper ventilator, air mix (driver side, passenger side) and intake door motor connectors.
4. Turn ignition switch ON.
5. Confirm operation of upper ventilator, air mix door motor (driver side, passenger side) and intake door
motor.
OK or NG
OK >> [Upper ventilator, air mix (driver side, passenger side) and intake door motors operate normally.]
GO TO 11.
NG >> [Upper ventilator, air mix (driver side, passenger side) and intake door motors does not operate
normally.]
GO TO 8.
8. CHECK MODE DOOR MOTOR, AIR MIX DOOR MOTOR AND INTAKE DOOR MOTOR OPERATION
1. Turn ignition switch OFF.
2. Disconnect upper ventilator door motor connector.
3. Reconnect mode door motor (driver side, passenger side) connectors.
4. Turn ignition switch ON.
5. Confirm operation of mode door motor (driver side, passenger side), air mix door motor (driver side, pas-
senger side) and intake door motor.
OK or NG
OK >> [Mode (driver side, passenger side), air mix (driver side, passenger side) and intake door motors
operate normally.]
Replace upper ventilator door motor.
NG >> [Mode (driver side, passenger side), air mix (driver side, passenger side) and intake door motors
does not operate normally.]
GO TO 9.
Page 525 of 4647

ATC-74
TROUBLE DIAGNOSIS
Revision: 2007 April2007 M35/M45
9. CHECK MODE DOOR MOTOR, UPPER VENTILATOR DOOR MOTOR AND INTAKE DOOR MOTOR
OPERATION
1. Turn ignition switch OFF.
2. Disconnect air mix door motor (driver side, passenger side) connectors.
3. Reconnect upper ventilator door motor connector.
4. Turn ignition switch ON.
5. Confirm operation of mode door motor (driver side, passenger side), upper ventilator door motor and
intake door motor.
OK or NG
OK >> [Mode (driver side, passenger side), upper ventilator and intake door motors operate normally.]
GO TO 12.
NG >> [Mode (driver side, passenger side), upper ventilator and intake door motors does not operate
normally.]
GO TO 10.
10. CHECK MODE DOOR MOTOR, UPPER VENTILATOR DOOR MOTOR AND AIR MIX DOOR MOTOR
OPERATION
1. Turn ignition switch OFF.
2. Disconnect intake door motor connector.
3. Reconnect air mix door motor (driver side, passenger side) connectors.
4. Turn ignition switch ON.
5. Confirm operation of mode door motor (driver side, passenger side), upper ventilator door motor and air
mix door motor (driver side, passenger side).
OK or NG
OK >> [Mode (driver side, passenger side), upper ventilator and air mix door motor (driver side, passen-
ger side) operate normally.]
Replace intake door motor.
NG >> [Mode (driver side, passenger side), upper ventilator and air mix door motor (driver side, passen-
ger side) does not operate normally.]
Replace unified meter and A/C amp.
11 . CHECK MODE DOOR MOTOR OPERATION
1. Turn ignition switch OFF.
2. Reconnect mode door motor (passenger side) connector.
3. Turn ignition switch ON.
4. Confirm operation of mode door motor (passenger side).
OK or NG
OK >> [Mode door motor (passenger side) operates normally.]
Replace mode door motor (driver side).
NG >> [Mode door motor (passenger side) does not operate normally.]
Replace mode door motor (passenger side).
Page 526 of 4647
TROUBLE DIAGNOSIS
ATC-75
C
D
E
F
G
H
I
K
L
MA
B
AT C
Revision: 2007 April2007 M35/M45
12. CHECK AIR MIX DOOR MOTOR OPERATION
1. Turn ignition switch OFF.
2. Reconnect air mix door motor (passenger side) connector.
3. Turn ignition switch ON.
4. Confirm operation of air mix door motor (passenger side).
OK or NG
OK >> [Air mix door motor (passenger side) operates normally.]
Replace air mix door motor (driver side).
NG >> [Air mix door motor (passenger side) does not operate normally.]
Replace air mix door motor (passenger side).
Page 527 of 4647
ATC-76
TROUBLE DIAGNOSIS
Revision: 2007 April2007 M35/M45
Mode Door Motor CircuitNJS000GO
SYMPTOM
Air outlet does not change.
Mode door motor does not operate normally.
INSPECTION FLOW
SJIA1761E
Page 528 of 4647

TROUBLE DIAGNOSIS
ATC-77
C
D
E
F
G
H
I
K
L
MA
B
AT C
Revision: 2007 April2007 M35/M45
SYSTEM DESCRIPTION
Component Parts
Mode door control system components are:
Unified meter and A/C amp.
Mode door motor (LCU)
A/C LAN system (PBR built-in mode door motor, upper ventilator door motor, air mix door motor and
intake door motor)
In-vehicle sensor
Ambient sensor
Sunload sensor
Intake sensor
System Operation
The unified meter and A/C amp. receives data from each of the sensors. The unified meter and A/C amp.
sends air mix door, mode door, upper ventilator door and intake door opening angle data to the air mix door
motor LCUs, mode door motor LCUs, upper ventilator door motor LCU and intake door motor LCU.
The air mix door motors, mode door motors, upper ventilator door motor and intake door motor read their
respective signals according to the address signal. Opening angle indication signals received from the unified
meter and A/C amp. and each of the motor position sensors are compared by the LCUs in each door motor
with the existing decision and opening angles. Subsequently, HOT/COLD, DEF/VENT, OPEN/SHUT and FRE/
REC operation is selected. The new selection data are returned to the unified meter and A/C amp.
*1ATC-37, "Discharge Air Flow"*2AT C - 6 5 , "Operational Check"*3ATC-121, "Intake Sensor Circuit"
*4ATC-57, "FUNCTION CONFIRMA-
TION PROCEDURE", see No. 2 to 6.*5AT C - 11 2 , "
Ambient Sensor Circuit"*6AT C - 11 5 , "In-vehicle Sensor Circuit"
*7ATC-118, "Sunload Sensor Circuit"*8AT C - 8 2 , "Air Mix Door Motor Cir-
cuit"
*9AT C - 5 7 , "FUNCTION CONFIRMA-
TION PROCEDURE", see No. 13.
*10ATC-71, "
DIAGNOSIS PROCE-
DURE FOR LAN CIRCUIT"
*11ATC-139, "MODE DOOR MOTOR"*12AT C - 4 1 , "SYMPTOM TABLE"
RJIA4056E
