2007 INFINITI M35 Factory Service Manual

wipers manual transmission washer fluid oil capacities ECU oil filter

Page 65 of 4647

INFINITI M35 2007 Factory Service Manual ACS-56
[ICC]
TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS
Revision: 2007 April2007 M35/M45
23. CHECK HARNESS BETWEEN STOP LAMP SWITCH AND ABS ACTUATOR AND ELECTRIC UNIT
(CONTROL UNIT)
1. Turn ignition

ACS-56
[ICC]
TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS
Revision: 2007 April2007 M35/M45
23. CHECK HARNESS BETWEEN STOP LAMP SWITCH AND ABS ACTUATOR AND ELECTRIC UNIT
(CONTROL UNIT)
1. Turn ignition switch OFF.
2. Disconnect ABS actuator and electric unit (control unit) connector.
3. Check continuity between stop lamp switch harness connector
(A) and ABS actuator and electric unit (control unit) harness
connector (B).
4. Check continuity between stop lamp switch harness connector
(A) and ground.
OK or NG
OK >> 1. Perform “ABS” self-diagnosis. Refer to BRC-23, "CONSULT-II Functions (ABS)" .
2. After repairing or replacing applicable item, erase DTC and perform ICC system running test.
Then perform self-diagnosis of ICC system again.
NG >> 1. Repair or replace harness between stop lamp switch and ABS actuator and electric unit (control
unit).
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system
again.
DTC 14 ECM CIRCUITNKS004D8
1. PERFORM ICC SENSOR INTEGRATED UNIT SELF-DIAGNOSIS
1. Perform self-diagnosis.
2. Check if “CAN COMM CIRCUIT [U1000]” (DTC 100) other than “ECM CIRCUIT [C1A14]” (DTC 14) is indi-
cated in self-diagnosis item in the display.
Is it indicated?
YES >> 1. CAN communication inspection. Refer to ACS-61, "DTC 100 CAN COMM CIRCUIT" .
2. After repairing or replacing applicable item, erase DTC and perform ICC system running test.
Then perform self-diagnosis of ICC system again.
NO >> GO TO 2.
2. PERFORM ECM SELF-DIAGNOSIS
With CONSULT-II
1. Perform “ENGINE” self-diagnosis. Refer to EC-123, "
CONSULT-II Function (ENGINE)" (for VQ35DE) or
EC-826, "
CONSULT-II Function (ENGINE)" (for VK45DE).
2. Check if malfunction is indicated.
Is malfunction indicated?
YES >> 1. Repair or replace applicable item.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system
again.
NO >> 1. Replace ICC sensor integrated unit, and adjust laser beam aiming.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system
again.
AB
Continuity
Connector Terminal Connector Terminal
E124 4 E30 30 Yes
A
GroundContinuity
Connector Terminal
E124 4 No
PKIC0834E

Page 66 of 4647

INFINITI M35 2007 Factory Service Manual TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS
ACS-57
[ICC]
C
D
E
F
G
H
I
J
L
MA
B
ACS
Revision: 2007 April2007 M35/M45
DTC 15 GEAR POSITIONNKS004D9
1. PERFORM ICC SENSOR INTEGRATED UNIT SELF-DIAGNOSIS
1

TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS
ACS-57
[ICC]
C
D
E
F
G
H
I
J
L
MA
B
ACS
Revision: 2007 April2007 M35/M45
DTC 15 GEAR POSITIONNKS004D9
1. PERFORM ICC SENSOR INTEGRATED UNIT SELF-DIAGNOSIS
1. Perform self-diagnosis.
2. Check if “VHCL SPEED SE CIRC [C1A03]” (DTC 3), “ABS/TCS/VDC CIRC [C1A04]” (DTC 4) or “CAN
COMM CIRCUIT [U1000]” (DTC100) other than “GEAR POSITION [C1A15]” (DTC 15) is indicated in self-
diagnosis item in the display.
Is any indicated?
YES >> 1. Repair or replace applicable item. Refer to ACS-40, "Diagnostic Trouble Code (DTC) Chart" .
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system
again.
NO >> GO TO 2.
2. CHECK VEHICLE SPEED SIGNAL
With CONSULT-II
With “ICC” “DATA MONITOR”, check if “VHCL SPEED SE” operates normally.
OK or NG
OK >> GO TO 3.
NG >> 1. Replace ICC sensor integrated unit, and adjust laser beam aiming.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system
again.
3. CHECK SHIFT GEAR POSITION
Check if gear positions are correct in A/T.
OK or NG
OK >> GO TO 5.
NG >> GO TO 4.
4. CHECK TCM GEAR POSITION SIGNAL
With CONSULT-II
With “A/T” “DATA MONITOR”, check if gear positions are correct.
OK or NG
OK >> 1. Replace ICC sensor integrated unit, and adjust laser beam aiming.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system
again.
NG >> 1. Perform “A/T” self-diagnosis. Refer to AT- 9 0 , "
CONSULT-II Function (A/T)" .
2. After repairing or replacing applicable item, erase DTC and perform ICC system running test.
Then perform self-diagnosis of ICC system again.
5. CHECK TCM TURBINE REVOLUTION
With CONSULT-II
With TCM diagnosis, check if turbine revolution sensor is normal. Refer to AT- 11 7 , "
DTC P0717 TURBINE
REVOLUTION SENSOR" .
OK or NG
OK >> 1. Replace ICC sensor integrated unit, and adjust laser beam aiming.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system
again.
NG >> 1. Perform “A/T” self-diagnosis. Refer to AT- 9 0 , "
CONSULT-II Function (A/T)" .
2. After repairing or replacing applicable item, erase DTC and perform ICC system running test.
Then perform self-diagnosis of ICC system again.

Page 67 of 4647

INFINITI M35 2007 Factory Service Manual ACS-58
[ICC]
TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS
Revision: 2007 April2007 M35/M45
DTC 16 RADAR STAINNKS004DA
1. VISUAL INSPECTION 1
Check ICC sensor integrated unit body window for contaminati

ACS-58
[ICC]
TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS
Revision: 2007 April2007 M35/M45
DTC 16 RADAR STAINNKS004DA
1. VISUAL INSPECTION 1
Check ICC sensor integrated unit body window for contamination and foreign materials.
Is it found?
YES >> 1. If any, remove them.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system
again.
NO >> GO TO 2.
2. VISUAL INSPECTION 2
Check ICC sensor integrated unit body window for cracks and scratches.
Is it found?
YES >> 1. Replace ICC sensor integrated unit, and adjust laser beam aiming.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system
again.
NO >> GO TO 3.
3. ASKING COMPLAINTS
1. Ask if there is any trace of contamination or foreign material on ICC sensor integrated unit.
2. Ask if vehicle was driven in snow or ICC sensor integrated unit was frosted.
3. Ask if ICC sensor integrated unit was fogged temporarily. (Front window glass may have also tended to be
fogged.)
Is there any symptom?
YES >> Explain difference in displays between contamination detection result and current indication to
customer, and tell them “This is not malfunction”.
NO >> 1. Replace ICC sensor integrated unit, and adjust laser beam aiming.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system
again.
DTC 18 LASER AIMING INCMPNKS004DB
1. ADJUST LASER BEAM AIMING
1. Adjust laser beam aiming. Refer to ACS-15, "
LASER BEAM AIMING ADJUSTMENT" .
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
3. Check if “LASER AIMING INCMP [C1A18]” (DTC 18) is indicated in self-diagnosis item in the display.
Is it indicated?
YES >> 1. Replace ICC sensor integrated unit, and adjust laser beam aiming.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system
again.
NO >> INSPECTION END
DTC 21 UNIT HIGH TEMPNKS004DC
1. CHECK SYMPTOM
Check if cooling system malfunctions.
Does it malfunction?
YES >> 1. Repair cooling system.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system
again.
NO >> 1. Replace ICC sensor integrated unit, and adjust laser beam aiming.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system
again.

Page 68 of 4647

INFINITI M35 2007 Factory Service Manual TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS
ACS-59
[ICC]
C
D
E
F
G
H
I
J
L
MA
B
ACS
Revision: 2007 April2007 M35/M45
DTC 24 NP RANGENKS004DD
1. PERFORM ICC SENSOR INTEGRATED UNIT SELF-DIAGNOSIS
1. Per

TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS
ACS-59
[ICC]
C
D
E
F
G
H
I
J
L
MA
B
ACS
Revision: 2007 April2007 M35/M45
DTC 24 NP RANGENKS004DD
1. PERFORM ICC SENSOR INTEGRATED UNIT SELF-DIAGNOSIS
1. Perform self-diagnosis.
2. Check if “CAN COMM CIRCUIT [U1000]” (DTC100) other than “NP RANGE [C1A24]” (DTC 24) is indi-
cated in self-diagnosis item in the display.
Is it indicated?
YES >> 1. CAN communication inspection. Refer to ACS-61, "DTC 100 CAN COMM CIRCUIT" .
2. After repairing or replacing applicable item, erase DTC and perform ICC system running test.
Then perform self-diagnosis of ICC system again.
NO >> GO TO 2.
2. CHECK TCM DATA MONITOR
With CONSULT-II
With “A/T” “DATA MONITOR” check if gear positions are correct.
OK or NG
OK >> 1. Replace ICC sensor integrated unit, and adjust laser beam aiming.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system
again.
NG >> 1. Perform “A/T” self-diagnosis. Refer to AT- 9 0 , "
CONSULT-II Function (A/T)" .
2. After repairing or replacing applicable item, erase DTC and perform ICC system running test.
Then perform self-diagnosis of ICC system again.
DTC 25 SHIFT RANGE INDNKS004DE
1. PERFORM ICC SENSOR INTEGRATED UNIT SELF-DIAGNOSIS
1. Perform self-diagnosis.
2. Check if “CAN COMM CIRCUIT [U1000]” (DTC 100) other than “SHIFT RANGE IND [C1A25]” (DTC 25) is
indicated in self-diagnosis item in the display.
Is it indicated?
YES >> 1. CAN communication inspection. Refer to ACS-61, "DTC 100 CAN COMM CIRCUIT" .
2. After repairing or replacing applicable item, erase DTC and perform ICC system running test.
Then perform self-diagnosis of ICC system again.
NO >> GO TO 2.
2. CHECK TCM DATA MONITOR
With CONSULT-II
With “A/T” “DATA MONITOR”, check if gear positions are correct.
OK or NG
OK >> 1. Replace ICC sensor integrated unit, and adjust laser beam aiming.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system
again.
NG >> 1. Perform “A/T” self-diagnosis. Refer to AT- 9 0 , "
CONSULT-II Function (A/T)" .
2. After repairing or replacing applicable item, erase DTC and perform ICC system running test.
Then perform self-diagnosis of ICC system again.

Page 69 of 4647

INFINITI M35 2007 Factory Service Manual ACS-60
[ICC]
TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS
Revision: 2007 April2007 M35/M45
DTC 26 ECD MODE MALFNKS004DF
1. PERFORM ICC SENSOR INTEGRATED UNIT SELF-DIAGNOSIS
1. Perform self-diagnosis.
2

ACS-60
[ICC]
TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS
Revision: 2007 April2007 M35/M45
DTC 26 ECD MODE MALFNKS004DF
1. PERFORM ICC SENSOR INTEGRATED UNIT SELF-DIAGNOSIS
1. Perform self-diagnosis.
2. Check if “CAN COMM CIRCUIT [U1000]” (DTC 100) other than “ECD MODE MALF [C1A26]” (DTC 26) is
indicated in self-diagnosis item in the display.
Is it indicated?
YES >> 1. CAN communication inspection. Refer to ACS-61, "DTC 100 CAN COMM CIRCUIT" .
2. After repairing or replacing applicable item, erase DTC and perform ICC system running test.
Then perform self-diagnosis of ICC system again.
NO >> GO TO 2.
2. PERFORM ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) SELF-DIAGNOSIS
With CONSULT-II
1. Perform “ABS” self-diagnosis. Refer to BRC-23, "
CONSULT-II Functions (ABS)" .
2. Check if malfunction is indicated.
Is malfunction indicated?
YES >> 1. Repair or replace applicable item.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system
again.
NO >> 1. Replace ICC sensor integrated unit, and adjust laser beam aiming.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system
again.
DTC 27 ECD PWR SUPLY CIRNKS004DG
1. PERFORM ICC SENSOR INTEGRATED UNIT SELF-DIAGNOSIS
1. Perform self-diagnosis.
2. Check if “CAN COMM CIRCUIT [U1000]” (DTC 100) other than “ECD PWR SUPLY CIR [C1A27]” (DTC
27) is indicated in self-diagnosis item in the display.
Is it indicated?
YES >> 1. CAN communication inspection. Refer to ACS-61, "DTC 100 CAN COMM CIRCUIT" .
2. After repairing or replacing applicable item, erase DTC and perform ICC system running test.
Then perform self-diagnosis of ICC system again.
NO >> GO TO 2.
2. CHECK ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) POWER SUPPLY CIRCUIT
With CONSULT-II
Check ABS actuator and electric unit (control unit) power supply circuit. Refer to BRC-37, "
ABS Actuator and
Electric Unit (Control Unit) Power Supply and Ground Circuit" .
OK or NG
OK >> 1. Perform “ABS” self-diagnosis. Refer to BRC-23, "CONSULT-II Functions (ABS)" .
2. After repairing or replacing applicable item, erase DTC and perform ICC system running test.
Then perform self-diagnosis of ICC system again.
NG >> 1. Repair or replace applicable item.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system
again.

Page 70 of 4647

INFINITI M35 2007 Factory Service Manual TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS
ACS-61
[ICC]
C
D
E
F
G
H
I
J
L
MA
B
ACS
Revision: 2007 April2007 M35/M45
DTC 100 CAN COMM CIRCUITNKS004DH
1. PERFORM ICC SENSOR INTEGRATED UNIT SELF-DIAGNOS

Page 71 of 4647

INFINITI M35 2007 Factory Service Manual ACS-62
[ICC]
TROUBLE DIAGNOSIS FOR SYMPTOMS
Revision: 2007 April2007 M35/M45
TROUBLE DIAGNOSIS FOR SYMPTOMSPFP:00007
Symptom ChartNKS004DJ
Symptoms Reference page
OperationMAIN switch does not switch

Page 72 of 4647

INFINITI M35 2007 Factory Service Manual TROUBLE DIAGNOSIS FOR SYMPTOMS
ACS-63
[ICC]
C
D
E
F
G
H
I
J
L
MA
B
ACS
Revision: 2007 April2007 M35/M45
Symptom 1: MAIN Switch Does Not Turn ON*1 , MAIN Switch Does Not Turn
OFF
*2NKS004DK
NOTE:
*1:

Load next 8 pages

Page: < prev 1-10 ... 33-40 41-48 49-56 57-64 65-72 73-80 81-88 89-96 97-104 ... 4648 next >

transmission transmission fluid keyless spare tire location diagram CD changer
