Page 1113 of 4647

INFINITI M35 2007 Factory Service Manual BL-180 INTELLIGENT KEY SYSTEM/ENGINE START FUNCTION Revision: 2007 April2007 M35/M45 2. CHECK HARNESS CONTINUITY 1. Disconnect Intelligent Key unit connector. 2. Check continuity between Intelligent K

Page 1114 of 4647

INFINITI M35 2007 Factory Service Manual INTELLIGENT KEY SYSTEM/ENGINE START FUNCTION BL-181 C D E F G H J K L MA B BL Revision: 2007 April2007 M35/M45 Check Inside Key AntennaNIS001Z5 1. CHECK INSIDE KEY ANTENNA FUNCTION With CONSULT-II 1.

Page 1115 of 4647

INFINITI M35 2007 Factory Service Manual BL-182 INTELLIGENT KEY SYSTEM/ENGINE START FUNCTION Revision: 2007 April2007 M35/M45 3. CHECK INSIDE KEY ANTENNA CIRCUIT 1. Disconnect Intelligent Key unit and inside key antenna connector. 2. Check c

Page 1116 of 4647

INFINITI M35 2007 Factory Service Manual INTELLIGENT KEY SYSTEM/ENGINE START FUNCTION BL-183 C D E F G H J K L MA B BL Revision: 2007 April2007 M35/M45 4. CHECK INDE KEY ANTENNA INPUT SIGNAL 2 1. Replace inside key antenna. (New antenna or o

Page 1117 of 4647

INFINITI M35 2007 Factory Service Manual BL-184 INTELLIGENT KEY SYSTEM/ENGINE START FUNCTION Revision: 2007 April2007 M35/M45 2. CHECK HARNESS CONITNUITY 1. Disconnect Intelligent Key unit connector. 2. Check continuity between Intelligent K

Page 1118 of 4647

INFINITI M35 2007 Factory Service Manual INTELLIGENT KEY SYSTEM/ENGINE START FUNCTION BL-185 C D E F G H J K L MA B BL Revision: 2007 April2007 M35/M45 2. CHECK POWER SUPPLY 1. Turn ignition switch OFF. 2. Disconnect key slot connector. 3. C

Page 1119 of 4647

INFINITI M35 2007 Factory Service Manual BL-186 INTELLIGENT KEY SYSTEM/ENGINE START FUNCTION Revision: 2007 April2007 M35/M45 5. CHECK HARNESS CONTINUITY 2 1. Disconnect BCM connector. 2. Check continuity between BCM connector and key slot c

Page 1120 of 4647

INFINITI M35 2007 Factory Service Manual INTELLIGENT KEY SYSTEM/ENGINE START FUNCTION BL-187 C D E F G H J K L MA B BL Revision: 2007 April2007 M35/M45 3. CHECK KEY SLOT SIGNAL 1. Connect key slot connector. 2. Check voltage between key slot
