2007 INFINITI M35 headlamp

LASER BEAM AIMING ADJUSTMENT
ACS-15
[ICC]
C
D
E
F
G
H
I
J
L
MA
B
ACS
Revision: 2007 April2007 M35/M45
LASER BEAM AIMING ADJUSTMENTPFP:00026
OutlineNKS004CM
Adjust the laser beam aiming every time the ICC sensor integrated unit is removed or installed.
CAUTION:

Adjust laser beam aiming at a horizontal place as far as 12 m (39 ft) forward the vehicle can be
seen.

Adjust laser beam aiming 5 seconds after starting engine.

Never view ICC sensor integrated unit body window directly during laser beam aiming adjustment.

Follow the CONSULT-II when adjusting the laser beam aiming (laser beam aiming adjustment can-
not be operated without CONSULT-II).

Never ride on vehicle during laser beam aiming adjustment.

Idle and turn headlamps OFF during laser beam aiming adjustment.
PreparationNKS004CN

Adjust the tire pressure to the specified value.

See that there is no load in the vehicle.

Coolant, engine oil filled up to correct level and full fuel tank.

Shift the gear into “P” position and release the parking brake.

Clean the ICC sensor integrated unit with a soft cloth.

Remove the front bumper grille. Refer to EI-13, "Removal and
Installation of Front Bumper Grille" .
Outline of Adjustment ProcedureNKS004CO
1. Set up the ICC target board [KV99110100 (J-45718)].
2. Adjust the sensor following the procedure on CONSULT-II. (Turn manually the screw for up-down position
adjustment. ICC sensor integrated unit automatically adjust the right-left position.)
Setting the ICC Target BoardNKS004CP
Accurate ICC target board setting is required for the laser beam aiming adjustment.
CAUTION:
ICC system does not function normally if laser beam aiming is not accurate.
ADJUSTING HEIGHT OF THE TARGET
1. Attach a triangle scale at 28 mm (1.10 in) below the center.
PKIB8350E
PKIB8351E

BCS-4
BCM (BODY CONTROL MODULE)
Revision: 2007 April2007 M35/M45
Operation Table of BCM and Combination Switches
BCM reads operation status of combination switch using combinations shown in table below.
NOTE:
Headlamp system has a dual switch.
Sample Operation:

When lighting switch 1ST position is turned ON, contact in combination switch turns ON. At this time if
OUTPUT 4 transistor is activated, BCM detects that voltage changes in INPUT 5.

When OUTPUT 4 transistor is ON, BCM detects that voltage changes in INPUT 5, and judges that lighting
switch 1ST position is ON. Then BCM sends tail lamp and clearance lamp request signal to IPDM E/R
using CAN communication.

When OUTPUT 4 transistor is activated again, BCM detects that voltage changes in INPUT 5, and recog-
nizes that lighting switch 1ST position is continuously ON.
NOTE:
Each OUTPUT terminal transistor is activated at 10 ms intervals. Therefore after switch is turned ON, electri-
cal loads are activated with time delay. But this time delay is so short that it cannot be detected by human
senses.
PKIC0276E
PKID0471E

BCM (BODY CONTROL MODULE)
BCS-7
C
D
E
F
G
H
I
J
L
MA
B
BCS
Revision: 2007 April2007 M35/M45
SYSTEMS CONTROLLED BY BCM DIRECTLY
NOTE:
Power supply only. No system control.
SYSTEMS CONTROLLED BY BCM AND IPDM E/R
SYSTEMS CONTROLLED BY BCM AND COMBINATION METER
SYSTEMS CONTROLLED BY BCM AND INTELLIGENT KEY UNIT
SYSTEMS CONTROLLED BY BCM, COMBINATION METER AND IPDM E/R
SYSTEMS CONTROLLED BY BCM, LOW TIRE PRESSURE WARNING CONTROL UNIT AND
COMBINATION METER
System Reference
Power door lockBL-24, "
POWER DOOR LOCK SYSTEM"
Power window NOTEGW-14, "POWER WINDOW SYSTEM"
Sunroof NOTERF-10, "SUNROOF"
Automatic drive positioner NOTESE-11, "AUTOMATIC DRIVE POSITIONER"
Room lamp timerLT-266, "INTERIOR ROOM LAMP"
System Reference
Panic alarmBL-217, "
VEHICLE SECURITY (THEFT WARNING) SYSTEM"
Theft warning systemBL-217, "VEHICLE SECURITY (THEFT WARNING) SYSTEM"
IVIS (NATS)BL-244, "IVIS (INFINITI VEHICLE IMMOBILIZER SYSTEM-NATS)"
Headlamp

LT-42, "HEADLAMP (FOR USA) - XENON TYPE -"

LT- 8 , "HEADLAMP (FOR USA) - CONVENTIONAL TYPE -"

LT-78, "HEADLAMP (FOR CANADA) - DAYTIME LIGHT SYSTEM -"
Auto light systemLT-115, "AUTO LIGHT SYSTEM"
Parking, license plate and tail lampsLT-248, "PARKING, LICENSE PLATE AND TAIL LAMPS"
Front fog lampLT-194, "FRONT FOG LAMP"
Front wiper and washer systemWW-4, "FRONT WIPER AND WASHER SYSTEM"
Rear window defoggerGW-71, "REAR WINDOW DEFOGGER"
System Reference
Turn signal and hazard warning lampsLT-212, "
TURN SIGNAL AND HAZARD WARNING LAMPS"
Warning chimeDI-59, "WARNING CHIME"
System Reference
Intelligent KeyBL-43, "
INTELLIGENT KEY SYSTEM"
System Reference
Oil pressure warning lampDI-39, "
WARNING LAMPS"
System Reference
Low tire pressure warning lamp and buzzerWT-9, "
TIRE PRESSURE MONITORING SYSTEM"

BCS-8
BCM (BODY CONTROL MODULE)
Revision: 2007 April2007 M35/M45
MAJOR COMPONENTS AND CONTROL SYSTEM
System Input Output
Intelligent Key system Intelligent Key unit

All door locking actuator

Trunk lid opener actuator

Turn signal lamp (LH, RH)

Combination meter
Power door lock system

Power window main switch (door lock and unlock switch)

Power window sub switch (passenger side)
(door lock and unlock switch)All-door locking actuator
Power supply (IGN) to power win-
dow, sunroofIgnition power supply Power window and sunroof system
Power supply (BAT) to power win-
dow, sunroof and power seatBattery power supplyPower window, sunroof system
and power seat
Panic alarm

Key slot

Intelligent KeyIPDM E/R
Theft warning system

All-door switch

Hood switch

Intelligent Key

Power window main switch (door lock and unlock switch)

IPDM E/R

Security indicator lamp
Auto light system

Optical sensor

Combination switchIPDM E/R
Exterior lamp battery saver control

Ignition switch

Combination switchIPDM E/R

Headlamp

Tail lampCombination switch

IPDM E/R

Combination meter
Front fog lamp Combination switch

IPDM E/R

Combination meter
Turn signal lamp Combination switch

Turn signal lamp

Combination meter
Hazard lamp Hazard switch

Turn signal lamp

Combination meter
Interior room lamp timer

Key switch

Power window main switch (door lock and unlock switch)

Front door switch driver side

All-door switchInterior room lamp
Key warning chime*
1
Key switch

Front door switch driver sideCombination meter
(warning buzzer)
Light warning chime

Combination switch

Front door switch driver sideCombination meter
(warning buzzer)
Tire pressure monitoring system Low tire pressure warning control unitCombination meter
(warning buzzer)
(warning lamp)
Seat belt warning chime

Combination meter [Seat belt buckle (driver side) switch]

Ignition switchCombination meter
(warning buzzer)
Vehicle-speed-sensing intermittent
wiper

Combination switch

Unified meter and A/C amp.IPDM E/R
Rear window defogger

Multifunction switch

NAVI control unit*2

AV control unit*3
IPDM E/R

BCS-12
BCM (BODY CONTROL MODULE)
Revision: 2007 April2007 M35/M45
CONSULT-II Function (BCM)NKS003XK
CONSULT-II can display each diagnostic item using the diagnostic test modes shown following.
CONSULT-II BASIC OPERATION
Refer to GI-38, "CONSULT-II Start Procedure" .
ITEMS OF EACH PART
×: Applicable
NOTE:
CONSULT-II displays systems equipped in the vehicle.BCM diagnostic test item Check item, diagnostic test mode Content
Inspection by partWORK SUPPORT Changes setting of each function.
SELF- DIAG RESULTS BCM performs self-diagnosis of CAN communication.
DATA MONITOR Displays the input data of BCM in real time.
CAN DIAG SUPPORT MNTRThe result of transmit/receive diagnosis of CAN communication can
be read.
ACTIVE TEST Gives a drive signal to a load to check the operation.
ECU PART NUMBER BCM part number can be read.
System and item CONSULT-II displayDiagnostic test mode (Inspection by part)
WORK
SUPPORTSELF−DIAG
RESULTSDATA
MONITORCAN DIAG
SUPPORT
MNTRACTIVE
TESTECU
PA R T
NUMBER
BCM BCM×× × ×
Power door lock system DOOR LOCK××
Rear window defogger REAR DEFOGGER××
Warning chime BUZZER××
Room lamp timer INT LAMP×××
Headlamp HEAD LAMP×××
Wiper WIPER×××
Turn signal lamp
Hazard lampFLASHER××
Intelligent Key system INTELLIGENT KEY××
Combination switch COMB SW×
IVIS IMMU××
Room lamp battery saver BATTERY SAVER×× ×
Trunk lid TRUNK××
Vehicle security system THEFT ALM×××
Retained power control RETAINED PWR××
Oil pressure switch SIGNAL BUFFER××
Panic system PANIC ALARM×

BL-4Revision: 2007 April2007 M35/M45 Terminals and Reference Value for BCM ..............211
CONSULT-II Function (BCM) ................................212
CONSULT-II START PROCEDURE ..................212
DATA MONITOR ................................................212
ACTIVE TEST ...................................................212
Trouble Diagnosis .................................................213
TRUNK DOSE NOT OPEN WITH TRUNK LID
OPENER SWITCH / WITH INTELLIGENT KEY .213
VEHICLE SECURITY (THEFT WARNING) SYSTEM .217
Component Parts and Harness Connector Location .217
System Description ...............................................219
DESCRIPTION ..................................................219
POWER SUPPLY AND GROUND CIRCUIT .....220
INITIAL CONDITION TO ACTIVATE THE SYS-
TEM ...................................................................220
VEHICLE SECURITY SYSTEM ALARM OPER-
ATION ................................................................221
VEHICLE SECURITY SYSTEM DEACTIVATION .221
PANIC ALARM OPERATION .............................221
CAN Communication System Description ............221
CAN Communication Unit .....................................221
Schematic .............................................................222
Wiring Diagram — VEHSEC — ............................223
Terminals and Reference Value of BCM ...............229
Terminals and Reference Value of IPDM E/R .......229
CONSULT-II Function (BCM) ................................230
BASIC OPERATION ..........................................230
CONSULT-II APPLICATION ITEM .....................230
Trouble Diagnosis Work Flow ...............................231
Preliminary Check ................................................231
Trouble Diagnosis Symptom Chart .......................233
Diagnostic Procedure 1 ........................................234
DOOR SWITCH CHECK ...................................234
HOOD SWITCH CHECK ...................................237
TRUNK ROOM LAMP SWITCH CHECK ..........239
Diagnostic Procedure 2 ........................................241
SECURITY INDICATOR LAMP CHECK ............241
Diagnostic Procedure 3 ........................................242
FRONT DOOR KEY CYLINDER SWITCH
CHECK ..............................................................242
Diagnostic Procedure 4 ........................................242
VEHICLE SECURITY HORN ALARM CHECK . 242
Diagnostic Procedure 5 ........................................243
VEHICLE SECURITY HEADLAMP ALARM
CHECK ..............................................................243
Diagnostic Procedure 6 ........................................243
DOOR LOCK AND UNLOCK SWITCH CHECK .243
Diagnostic Procedure 7 ........................................243
VEHCLE SECURITY HAZARD LAMP ALARM
CHECK ..............................................................243
IVIS (INFINITI VEHICLE IMMOBILIZER SYSTEM-
NATS) ......................................................................244
Component Parts and Harness Connector Location .244
System Description ...............................................246
DESCRIPTION ..................................................246
PRECAUTIONS FOR KEY REGISTRATION ....246
SECURITY INDICATOR ....................................246
Operation Description ...........................................247
SYSTEM DIAGRAM ..........................................247OPERATION WHEN INSERTING TO KEY SLOT .247
OPERATION WHEN INTELLIGENT KEY IS
CARRIED ...........................................................247
PUSH-BUTTON IGNITION SWITCH OPERA-
TION PROCEDURE ..........................................247
ECM Re-Communicating Function .......................248
Schematic .............................................................250
Wiring Diagram — NATS — ..................................252
Terminals and Reference Value for Intelligent Key
Unit ........................................................................260
Terminals and Reference Value for Steering Lock
Unit ........................................................................262
Terminals and Reference Value for BCM ..............263
Terminals and Reference Value for IPDM E/R ......263
Terminals and Reference Value for PDU ..............264
CONSULT-II ..........................................................265
CONSULT-II INSPECTION PROCEDURE ........265
CONSULT-II DIAGNOSTIC TEST MODE FUNC-
TION ..................................................................266
HOW TO READ SELF-DIAGNOSTIC RESULTS .267
“NATS V5.0” SELF-DIAGNOSTIC RESULTS
ITEM CHART .....................................................268
“NATS BCM OR S/ENT” SELF-DIAGNOSTIC
RESULTS ITEM CHART ....................................268
“NATS I-KEY” SELF-DIAGNOSTIC RESULTS
ITEM CHART .....................................................269
Work Flow .............................................................269
Trouble Diagnoses Flow Chart for IVIS (NATS) ....272
Symptom Chart for Security Indicator ...................274
CONDITIONS OF VEHICLE (OPERATING CON-
DITIONS) ...........................................................274
Check Security Indicator Harness .........................274
DTC P1612 CHAIN of ECM-IMMU .......................275
DTC P1611 ID DISCORD, IMM-ECM ...................277
Removal and Installation of Key Slot ....................277
REMOVAL ..........................................................277
INSTALLATION ..................................................277
INTEGRATED HOMELINK TRANSMITTER ...........278
Wiring Diagram —TRNSCV— ..............................278
Trouble Diagnoses ................................................279
DIAGNOSTIC PROCEDURE .............................279
BODY REPAIR ........................................................281
Body Exterior Paint Color ......................................281
Body Component Parts .........................................282
UNDERBODY COMPONENT PARTS ...............282
BODY COMPONENT PARTS ............................284
Corrosion Protection .............................................286
DESCRIPTION ..................................................286
UNDERCOATING ..............................................287
Body Sealing .........................................................288
DESCRIPTION ..................................................288
Body Construction .................................................291
BODY CONSTRUCTION ...................................291
Body Alignment .....................................................292
BODY CENTER MARKS ...................................292
PANEL PARTS MATCHING MARKS .................293
DESCRIPTION ..................................................294
ENGINE COMPARTMENT ................................295
UNDERBODY ....................................................297

BL-16
HOOD
Revision: 2007 April2007 M35/M45
1. Check the clearance and the surface height between the hood and each part by visual and tactile feeling.
(Fitting standard dimension in the table below should be satisfied.)
* Unit: mm (in)
2. In case out of specification, adjust them according to the procedures shown below.
3. Remove the hood lock and adjust the height by rotating the
bumper rubber until the hood becomes 1 to1.5 mm (0.04 to
0.059 in) lower than the fender.
4. Temporarily tighten the hood lock, and position by engaging it with the hood striker. Check the lock and
striker for looseness and adjust the clearance and evenness by the striker to satisfy the specification.
5. Adjust A and B shown in the figure to the following value with hood's own weight by dropping it from
approx. 200 mm (7.87 in) height or the hood pressed lightly (approx. 29 N (3 kg)).
6. After adjustment tighten lock bolts to the specified torque.
1. Hood hinge 2. Hood lock assembly 3. Hood assembly
4. Hood top molding 5. Bumper fascia assembly 6. Headlamp
7. Front fender
Parts Standard Right/left clearance (MAX)
A – Aa Clearance 0.5 - 1.2 (0.02 -0.05) —
e Surface height 0.5 - 2.5 (0.02 - 0.10) —
B – Bb Clearance 1.5 - 5.5 (0.06 - 0.22) 2.5 (0.01)
f Surface height -1.0 - 3.0 (-0.04 - 0.12) 2.0 (0.08)
C – Cc Clearance 1.5 - 5.5 (0.06 - 0.22) 2.0 (0.08)
g Surface height -1.0 - 3.0 (-0.40 - 0.12) 2.0 (0.08)
D – Dd Clearance 2.0 - 5.0 (0.08 - 0.20) 1.5 (0.06)
h Surface height -1.0 - 1.0 (-0.04 - 0.04) 1.5 (0.06)
PIIB3872J
1. Hood striker 2. Primary latch 3. Secondary striker
4. Secondary latch
A : 20 mm (0.79 in)
B : 6.8 mm (0.27 in)
PIIB5794E

RADIATOR CORE SUPPORT
BL-21
C
D
E
F
G
H
J
K
L
MA
B
BL
Revision: 2007 April2007 M35/M45
RADIATOR CORE SUPPORTPFP:62500
Removal and InstallationNIS001WN
REMOVAL
1. Remove front bumper, bumper reinforcement. Refer toEI-14, "Removal and Installation" .
2. Remove headlamp (LH/RH). Refer to LT- 4 0 , "
Removal and Installation" .
3. Remove air duct. Refer to EM-19, "
Removal and Installation" (VQ35DE models),EM-177, "Removal and
Installation" (VK45DE models).
4. Remove hood lock assembly, then remove hood lock cable. Refer to BL-18, "
Removal and Installation of
Hood Lock Control" .
5. Remove washer tank. Refer to WW-48, "
Removal and Installation of Washer Tank" .
6. Remove ambient sensor. Refer to ATC-125, "
Removal and Installation" .
7. Remove crash zone sensor. Refer to SRS-49, "
Removal and Installation" .
1. Headlamp (RH) 2. Radiator core support side (RH) 3. Washer tank
4. Air guide (RH) 5. Horn (High) 6. Air guide (LH)
7. Radiator core support side (LH) 8. Horn (Low) 9. Headlamp (LH)
10. Radiator core support center 11. Upper radiator bracket (LH) 12. Upper radiator bracket (RH)
13. Power steering tube assembly
PIIB5804E
