FRONT FENDERPFP:63100
Removal and InstallationNIS001WO
REMOVAL
1. Remove the front bumper. Refer to EI-11, "Removal and Installation" .
2. Remove the headlamp. Refer to LT- 4 0 , "
Removal and Installation" .
3. Remove the turn signal lamp. Refer to LT- 2 2 9 , "
Removal and Installation of Front Turn Signal Lamp" .
4. Remove the front fender protector. Refer to EI-20, "
FENDER PROTECTOR" .
5. Remove the center mud guard. Refer toEI-22, "
Removal and Installation" .
6. Remove the mounting bolt and remove the front fender.
CAUTION:
While removing use a shop cloth to protect body from damaging.
INSTALLATION
Install in the reverse order of removal.
CAUTION:

After installing, apply touch-up paint (the body color) onto the head of the front fender mounting
bolts.

After installing, check front fender adjustment. Refer to BL-15, "Fitting Adjustment" and BL-188,
"Fitting Adjustment" .
