SRA702A
3. Place lateral link and control rod horizontally against torsion
beam, and tighten to the specified torque.
4. Install torsion beam assembly. Refer to“Removal and
Installation”,“REAR SUSPENSION”, SU-23.
REAR SUSPENSION
Torsion Beam, Lateral Link and Control Rod (Cont’d)
SU-26
Page 3050 of 3051
Service Data and Specifications (SDS)
GENERAL SPECIFICATIONS (REAR)=NLSU0039
Suspension type Multi-link beam suspension
Shock absorber type Double-acting hydraulic
REAR WHEEL ALIGNMENT (UNLADEN*)NLSU0040
Body
Camber
Degree minute (Decimal degree)Minimum 1°45′( 1.75°)
Nominal 1°00′( 1.00°)
Maximum 0°15′( 0.25°)
Total toe-in Distance (A B)
mm (in)Minimum 3( 0.12)
Nominal 1 (0.04)
Maximum 5 (0.20)
Angle (left plus right)
Degree minute (Decimal degree)Minimum 16′( 0.27°)
Nominal 5′30″(0.09°)
Maximum 26′(0.43°)
*: Fuel, radiator coolant and engine oil full. Spare tire, jack, hand tools and mats in designated positions.
REAR SUSPENSION
Service Data and Specifications (SDS)
SU-27
Page 3051 of 3051
REAR SUSPENSION
Service Data and Specifications (SDS) (Cont’d)
SU-28
