Page 2833 of 3051

NISSAN ALMERA TINO 2001 Service Repair Manual SMT710DB 8. Install 2nd needle bearing, 2nd double cone assembly, and 2nd main gear onto mainshaft. 9. Position 3rd main gear as shown in the figure, and install it. CAUTION: Do not reuse 3rd main gea

Page 2834 of 3051

NISSAN ALMERA TINO 2001 Service Repair Manual SMT714DB 14. Install 5th gear bushing with its flange surface facing the 4th main gear side. SMT761D 15. Install 5th needle bearing, 5th main gear, and 5th gear baulk ring onto mainshaft. SMT694D 16.

Page 2835 of 3051

NISSAN ALMERA TINO 2001 Service Repair Manual SMT715DB 17. Install 5th & reverse synchronizer hub assembly. SMT717DB 18. Install reverse gear baulk ring. 19. Install reverse gear busing. 20. Install reverse gear needle bearing. SMT718D 21. Instal

Page 2836 of 3051

NISSAN ALMERA TINO 2001 Service Repair Manual SMT720DB 24. Install mainshaft rear bearing. SMT721D 25. Install mainshaft C-ring. 26. Using feeler gauge, measure the end play of mainshaft rear bearing, and check if it satisfies the following speci

Page 2837 of 3051

NISSAN ALMERA TINO 2001 Service Repair Manual SMT685DC 2. Upright the differential case so that the side gear to be mea- sured faces upward. 3. Place final drive adapter and dial gauge onto side gear. Move side gear up and down, and measure the c

Page 2838 of 3051

NISSAN ALMERA TINO 2001 Service Repair Manual SMT083A INSPECTIONNLMT0064Gear, Washer, Shaft and CaseNLMT0064S01+Check mating surfaces of differential case, side gears and pinion mate gears. +Check washers for wear. SPD715 BearingNLMT0064S03+Make

Page 2839 of 3051

NISSAN ALMERA TINO 2001 Service Repair Manual SMT699BB 8. Install retaining pin. +Make sure that retaining pin is flush with case. SMT842D 9. Align and install speedometer drive gear into differential case. 10. Install speedometer stopper. SMT751

Page 2840 of 3051

NISSAN ALMERA TINO 2001 Service Repair Manual SMT801D Shift Control Components INSPECTION=NLMT0066+Check if the width of shift fork hook (sliding area with coupling sleeve) is within allowable specification below. ItemOne-side wear specifi- catio
