Page 2105 of 3051

NISSAN ALMERA TINO 2001 Service Repair Manual SEL691V DescriptionNLEL0512S0206+Display area: Trapezoidal representation showing approximate distances (Wn, D, and Wd). +Ten horizontal grid lines indicate display width while six verti- cal grid lin

Page 2106 of 3051

NISSAN ALMERA TINO 2001 Service Repair Manual MAP DISPLAY=NLEL0512S03 SEL525X Function of each icon is as follows: 1) Azimuth indication 2) Position marker The tip of the arrow shows the current position. The shaft of the arrow indicates the dire

Page 2107 of 3051

NISSAN ALMERA TINO 2001 Service Repair Manual FUNCTION OF PANEL SWITCH=NLEL0512S04Display with Pushed ªDESTº SwitchNLEL0512S0401 SEL615X The function of each icon is as follows: Icon Description Address Book Favorite areas can be saved to memor

Page 2108 of 3051

NISSAN ALMERA TINO 2001 Service Repair Manual Display with Pushed ªROUTEº Switch=NLEL0512S0402 SEL526X The function of each icon is as follows: Icon Description Quick StopSelect facility is set as destination or waypoint. (Route guidance has be

Page 2109 of 3051

NISSAN ALMERA TINO 2001 Service Repair Manual Display with Pushed ªSETTINGº Switch=NLEL0512S0403 SEL614X The function of each icon is as follows: Icon Description Save Current LocationThe current location can be stored in the Address Book. Syst

Page 2110 of 3051

NISSAN ALMERA TINO 2001 Service Repair Manual SchematicNLEL0513MODELS WITH FUSE AND FUSIBLE LINK BOX E43NLEL0513S01 YEL956B NAVIGATION SYSTEM Schematic EL-379

Page 2111 of 3051

NISSAN ALMERA TINO 2001 Service Repair Manual MODELS WITH FUSE AND FUSIBLE LINK BOX E90NLEL0513S02 YEL473C NAVIGATION SYSTEM Schematic (Contd) EL-380

Page 2112 of 3051

NISSAN ALMERA TINO 2001 Service Repair Manual Wiring Diagram Ð NAVI ÐNLEL0514MODELS WITH FUSE AND FUSIBLE LINK BOX E43NLEL0514S05LHD ModelsNLEL0514S0501 YEL957B NAVIGATION SYSTEM Wiring Diagram Ð NAVI Ð EL-381
