NISSAN ALMERA TINO 2001 Service Repair Manual NLMA0036
Shown below are Pre-delivery Inspection Items required for the new vehicle. It is recommended that
necessary items other than those listed here be added, paying due regard to the conditions i

NLMA0036
Shown below are Pre-delivery Inspection Items required for the new vehicle. It is recommended that
necessary items other than those listed here be added, paying due regard to the conditions in each
country.
Perform applicable items on each model. Consult text of this section for specifications.
UNDER HOOD — engine off
Radiator coolant level and coolant hose connections for leaks
Battery fluid level, specific gravity and conditions of battery terminals
Drive belts tension
Fuel filter for water or dusts (Diesel only), and fuel lines and connections for leaks
Engine oil level and oil leaks
Clutch and brake reservoir fluid level and fluid lines for leaks
Windshield and rear window washer and headlamp cleaner reservoir fluid level
Power steering reservoir fluid level and hose connections for leaks
ON INSIDE AND OUTSIDE
Remove front spring/strut spacer (If applicable)
Operation of all instruments, gauges, lights and accessories
Operation of horn(s), wiper and washer
Steering lock for operation
Check air conditioner for gas leaks
Front and rear seats, and seat belts for operation
All moldings, trims and fittings for fit and alignment
All windows for operation and alignment
Hood, trunk lid, door panels for fit and alignment
Latches, keys and locks for operation
Weatherstrips for adhesion and fit
Headlamp aiming
Tighten wheel nuts (Inc. inner nuts if applicable)
Tire pressure (Inc. spare tire)
Check front wheels for toe-in
Install clock/voltmeter/room lamp fuse (If applicable)
Install deodorizing filter to air conditioner (If applicable)
Remove wiper blade protectors (If applicable)
UNDER BODY
Manual transmission/transaxle, transfer and differential gear oil level
Brake and fuel lines and oil/fluid reservoirs for leaks
Tighten bolts and nuts of steering linkage and gear box, suspension, propeller shafts and drive shafts
Tighten rear body bolts and nuts (Models with wooden bed only)
ROAD TEST
Clutch operation
Parking brake operation
Service brake operation
Automatic transmission/transaxle shift timing and kickdown
Steering control and returnability
Engine performance
Squeaks and rattles
ENGINE OPERATING AND HOT
Adjust idle speed
Automatic transmission/transaxle fluid level
Engine idling and stop knob operation (Diesel only)
FINAL INSPECTION
Install necessary parts (outside mirror, wheel covers, seat belts, mat, carpet or mud flaps)
Inspect for interior and exterior metal and paint damage
Check for spare tire, jack, tools (wheel chock), and literature
Wash, clean interior and exterior
: Not applicable to this model
PRE-DELIVERY INSPECTION ITEMS
MA-2

Page 2770 of 3051

NISSAN ALMERA TINO 2001 Service Repair Manual NLMA0004
General maintenance includes those items which should be checked during the normal day-to-day operation
of the vehicle. They are essential if the vehicle is to continue operating properly. Th

NLMA0004
General maintenance includes those items which should be checked during the normal day-to-day operation
of the vehicle. They are essential if the vehicle is to continue operating properly. The owners can perform the
checks and inspections themselves or they can have their NISSAN dealers do them for a nominal charge.
OUTSIDE THE VEHICLE
The maintenance items listed here should be performed from time to time, unless otherwise specified.
Item Reference page
TiresCheck the pressure with a gauge periodically when at a service station,
including the spare, and adjust to the specified pressure if necessary. Check
carefully for damage, cuts or excessive wear.—
Windshield wiper
bladesCheck for cracks or wear if not functioning correctly. —
Doors and engine
hoodCheck that all doors, the engine hood, the trunk lid and back door operate
properly. Also ensure that all latches lock securely. Lubricate if necessary.
Make sure that the secondary latch keeps the hood from opening when the
primary latch is released.
When driving in areas using road salt or other corrosive materials, check for
lubrication frequently.BT-7
BT-13
Tire rotationTires should be rotated every 10,000 km (6,000 miles). SU-8
INSIDE THE VEHICLE
The maintenance items listed here should be checked on a regular basis, such as when performing periodic maintenance, cleaning the
vehicle, etc.
Item Reference page
LampsMake sure that the headlamps, stop lamps, tail lamps, turn signal lamps,
and other lamps are all operating properly and installed securely. Also check
headlamp aim.—
Warning lamps and
chimesMake sure that all warning lamps and buzzers/chimes are operating prop-
erly.—
Steering wheelCheck that it has the specified play.
Check for changes in the steering conditions, such as excessive free play,
hard steering or strange noises.
Free play: Less than 35 mm (1.38 in)—
Seat beltsCheck that all parts of the seat belt system (e.g. buckles, anchors, adjusters
and retractors) operate properly and smoothly, and are installed securely.
Check the belt webbing for cuts, fraying, wear or damage.RS-3
UNDER THE HOOD AND VEHICLE
The maintenance items listed here should be checked periodically e.g. each time you check the engine oil or refuel.
Item Reference page
Windshield washer
fluidCheck that there is adequate fluid in the tank. —
Engine coolant levelCheck the coolant level when the engine is cold. LC-19, LC-59
Engine oil levelCheck the level after parking the vehicle (on level ground) and turning off
the engine.LC-8, LC-28
Brake and clutch
fluid levelsMake sure that the brake and clutch fluid levels are between the “MAX” and
“MIN” lines on the reservoir.BR-7
BatteryCheck the fluid level in each cell. It should be between the “MAX” and “MIN”
lines.—
GENERAL MAINTENANCE
MA-3

Page 2771 of 3051

NISSAN ALMERA TINO 2001 Service Repair Manual NLMA0046
MAINTENANCEOPER ATION MAINTENANCEINTE RVAL
Engin ean dEmissio nContro lMaintenanc e(QG18DE/SR20D Eengine)

Page 2772 of 3051

NISSAN ALMERA TINO 2001 Service Repair Manual *1: Models without three way catalyst
*2: For models with three way catalyst, periodic maintenance is not required. However, if valve noise increases, check valve clearance.
*3: Models with three way

Page 2773 of 3051

NISSAN ALMERA TINO 2001 Service Repair Manual Engine Maintenance (YD22DDTi engine)=NLMA0046S02Abbreviations: I = Inspect and correct or replace as necessary, R = Replace, A = Adjust, D = Check filter and drain water.
MAINTENANCE OPERATIONMAINTENA

Page 2774 of 3051

NISSAN ALMERA TINO 2001 Service Repair Manual Chassis and Body Maintenance=NLMA0046S03Abbreviations: I = Inspect and correct or replace as necessary, R = Replace, A = Adjust, L = Lubricate
MAINTENANCE OPERATIONMAINTENANCE INTERVAL
Reference
page

Page 2775 of 3051

NISSAN ALMERA TINO 2001 Service Repair Manual Maintenance Under Severe Driving Conditions=NLMA0046S04The maintenance intervals shown on the preceding pages are for normal operating conditions. If the vehicle
is mainly operated under severe drivin

Maintenance Under Severe Driving Conditions=NLMA0046S04The maintenance intervals shown on the preceding pages are for normal operating conditions. If the vehicle
is mainly operated under severe driving conditions as shown below, more frequent maintenance must be per-
formed on the following items as shown in the table.
SEVERE DRIVING CONDITIONSNLMA0046S0401A—Driving under dusty conditions
B—Driving repeatedly short distances
C—Towing a trailer or caravan
D—Extensive idling
E—Driving in extremely adverse weather conditions or in areas where ambient temperatures are either
extremely low or extremely high
F—Driving in high humidity areas or in mountainous areas
G—Driving in areas using salt or other corrosive materials
H—Driving on rough and/or muddy roads or in the desert
I—Driving with frequent use of braking or in mountainous areas
Driving condition Maintenance itemMaintenance
operationMaintenance
intervalRefer-
ence
page
A........Aircleaner filter Viscous paper type Replace More frequentlyEM-18,
EM-88,
EM-169
ABCD.....Engine oil & oil filter (QG18DE/SR20DE
engine)ReplaceEvery 5,000 km
(3,000 miles) or 3
monthsLC-8,
LC-28,
LC-9,
LC-28
ABCD.....Engine oil (YD22DDTi engine)
ReplaceMore frequently LC-47
Engine oil filter (YD22DDTi engine)Every 7,500 km
(4,500 miles) or 6
monthsLC-48
A...E....Fuel filter (YD22DDTi engine) ReplaceEvery 20,000 km
(12,000 miles) or
12 monthsFE-15
.....F...Brake fluid ReplaceEvery 20,000 km
(12,000 miles) or
12 monthsBR-7
..C....H.H·CVT fluid ReplaceEvery 20,000 km
(12,000 miles) or
12 monthsAT-11
......GH.Steering gear & linkage, axle & suspen-
sion parts & drive shaftsCheckEvery 10,000 km
(6,000 miles) or 6
monthsST-7,
SU-5,
SU-18
A.C...GHIBrake pads, rotors & other brake com-
ponentsCheckEvery 5,000 km
(3,000 miles) or 3
monthsBR-24,
BR-28
......G..Lock, hinges & hood latch LubricateEvery 5,000 km
(3,000 miles) or 3
monthsBT-7,
BT-13
A........Ventilation air filter Replace More frequently HA-103
PERIODIC MAINTENANCE (EXCEPT FOR EUROPE)
Maintenance Under Severe Driving Conditions
MA-8

Page 2776 of 3051

NISSAN ALMERA TINO 2001 Service Repair Manual NLMA0043
MAINTENANCEOPER ATION MAINTENANCEINTE RVAL Referencepages
Maintenanc eSchedul eforPetro lEngine s(Annua lMileag e< 30,00 0km/year)
