Page 305 of 3051

NISSAN ALMERA TINO 2001 Service Repair Manual SBR045EH
Ground Circuit CheckNLBR0096ABS ACTUATOR AND ELECTRIC UNIT GROUNDNLBR0096S04+Check continuity between ABS actuator and electric unit con-
nector terminals and ground.
Continuity should exist.

Page 306 of 3051

NISSAN ALMERA TINO 2001 Service Repair Manual Malfunction Code/Symptom ChartNLBR0097MODELS WITH SELF-DIAGNOSIS FUNCTION (DATA LINK CONNECTOR TERMINAL NO. 9)NLBR0097S01
Code No. (No. of LED flashes) Malfunctioning part Reference page
12 Self-diagn

Malfunction Code/Symptom ChartNLBR0097MODELS WITH SELF-DIAGNOSIS FUNCTION (DATA LINK CONNECTOR TERMINAL NO. 9)NLBR0097S01
Code No. (No. of LED flashes) Malfunctioning part Reference page
12 Self-diagnosis could not detect any malfunctions.—
18 Sensor rotor BR-71
21 Front right sensor (open-circuit) BR-71
22 Front right sensor (short-circuit) BR-71
25 Front left sensor (open-circuit) BR-71
26 Front left sensor (short-circuit) BR-71
31 Rear right sensor (open-circuit) BR-71
32 Rear right sensor (short-circuit) BR-71
35 Rear left sensor (open-circuit) BR-71
36 Rear left sensor (short-circuit) BR-71
41 Actuator front right outlet solenoid valve BR-74
42 Actuator front right inlet solenoid valve BR-74
45 Actuator front left outlet solenoid valve BR-74
46 Actuator front left inlet solenoid valve BR-74
51 Actuator rear right outlet solenoid valve BR-74
52 Actuator rear right inlet solenoid valve BR-74
55 Actuator rear left outlet solenoid valve BR-74
56 Actuator rear left inlet solenoid valve BR-74
57* Power supply (Low voltage) BR-79
61 Actuator motor or motor relay BR-77
63 Solenoid valve relay BR-74
71 Control unit BR-81
ABS warning lamp stays on when
ignition switch is turned on.Control unit power supply circuit
Warning lamp bulb circuit
Control unit or control unit connector
Solenoid valve relay stuck
Power supply for solenoid valve relay coilBR-88
ABS warning lamp stays on, during
self-diagnosis.Control unit—
ABS warning lamp does not come on
when ignition switch is turned on.Fuse, warning lamp bulb or warning lamp circuit
Control unitBR-86
ABS warning lamp does not come on
during self-diagnosis.Control unit—
Pedal vibration and noise—BR-85
Long stopping distance—BR-83
Unexpected pedal action—BR-82
ABS does not work.—BR-84
ABS works frequently.—BR-82
*: Under voltage that is too low, the control unit disable the ABS. It does not set the ABS in fail-safe condition. Instead, the ABS becomes
TROUBLE DIAGNOSIS—GENERAL DESCRIPTIONABS
Malfunction Code/Symptom Chart
BR-69

Page 307 of 3051

NISSAN ALMERA TINO 2001 Service Repair Manual a conventional brake system. After the power supply has resumed, the warning lamp goes off, making it possible for the ABS to be re-
engaged.
TROUBLE DIAGNOSIS—GENERAL DESCRIPTIONABS
Malfunction Cod

Page 308 of 3051

NISSAN ALMERA TINO 2001 Service Repair Manual Wheel Sensor or RotorNLBR0098DIAGNOSTIC PROCEDURENLBR0098S01(Malfunction code No. 21, 22, 25, 26, 31, 32, 35, 36 or 18 for
models with self-diagnosis function)
NOTE:
Wheel position should be identifie

Page 309 of 3051

NISSAN ALMERA TINO 2001 Service Repair Manual 3 CHECK WHEEL SENSOR CIRCUIT
1. Disconnect control unit connector.
2. Check resistance between control unit connector terminals.
Code No. 21 or 22 (Front RH wheel)
Terminals 4 and 5
Code No. 25 or 26

Page 310 of 3051

NISSAN ALMERA TINO 2001 Service Repair Manual 6 CHECK WHEEL BEARING
Check wheel bearing axial end play.
Check clearance between sensor and rotor.
Clearance:
Front
0.175 - 0.875 mm (0.007 - 0.034 in)
Rear
0.308 - 0.966 mm (0.012 - 0.0380 in)
SBR33

Page 311 of 3051

NISSAN ALMERA TINO 2001 Service Repair Manual ABS Actuator Solenoid Valve or Solenoid Valve
Relay
=NLBR0100DIAGNOSTIC PROCEDURENLBR0100S01(Malfunction code No. 41, 42, 45, 46, 51, 52, 55, 56, 63 for
models with self-diagnosis function)
1 INSPECTI

Page 312 of 3051

NISSAN ALMERA TINO 2001 Service Repair Manual 4 CHECK CONNECTOR
1. Disconnect ABS actuator and electric unit connector. Check terminals for damage or loose connection. Then reconnect
connector.
2. Carry out self-diagnosis again.
Does warning lamp
