NISSAN ALMERA TINO 2001 Service Repair Manual SMT747D a. Using dial gauge as shown in the figure, measure dimension “P1”between transaxle case end face and mainshaft rear bearing. SMT748D b. Using dial gauge as shown in the figure, measure di

Page 2850 of 3051

NISSAN ALMERA TINO 2001 Service Repair Manual SMT644D 21. Install selected snap ring. CAUTION: Do not reuse snap ring. 22. Apply gear oil to rear cover O-ring, and install rear cover, side cover gasket, and side cover. Then tighten mounting bolts

Page 2851 of 3051

NISSAN ALMERA TINO 2001 Service Repair Manual NLMT0009 Case ComponentsNLMT0009S02 SMT943D 1. Speedometer pinion 2. Differential oil seal 3. Drain plug 4. Boot 5. Striking rod oil seal 6. Magnet 7. Clutch housing8. Input shaft oil seal 9. Oil chan

Page 2852 of 3051

NISSAN ALMERA TINO 2001 Service Repair Manual Gear ComponentsNLMT0009S03 SMT937D 1. Input shaft 2. Input shaft front bearing 3. 3rd input gear 4. 3rd & 4th synchronizer hub 5. Snap ring 6. Coupling sleeve 7. 4th baulk ring 8. 4th input gear 9. Re

Page 2853 of 3051

NISSAN ALMERA TINO 2001 Service Repair Manual Shift Control ComponentsNLMT0009S04 SMT862CA 1. Retaining pin 2. 1st & 2nd shift fork 3. 1st & 2nd check plug 4. Return spring 5. Check ball 6. 1st & 2nd fork rod 7. 1st & 2nd bracket 8. Interlock plu

Page 2854 of 3051

NISSAN ALMERA TINO 2001 Service Repair Manual NLMT0010 SMT626D 1. Before removing transmission case, remove bolts, check plugs, springs and check balls as shown left. +Be careful not to lose check balls. 2. Remove transmission case. SMT017AA 3. R

Page 2855 of 3051

NISSAN ALMERA TINO 2001 Service Repair Manual SMT662C 7. Remove reverse arm shaft while rotating it. SMT663C 8. Remove reverse lever assembly and check ball. +Be careful not to lose check ball. SMT018B 9. Remove 5th & reverse check plug, spring a

Page 2856 of 3051

NISSAN ALMERA TINO 2001 Service Repair Manual SMT138A 14. Remove reverse check assembly and check ball. +Be careful not to lose check ball. SMT618AA SMT027A 15. Remove retaining pin and detach the selector. SMT028A 16. Remove drain plug for conve
