Page 2065 of 3051

NISSAN ALMERA TINO 2001 Service Repair Manual Component Parts and Harness Connector
Location
=NLEL0406For details, refer to ªELECTRICAL UNIT LOCATIONº (EL-442) and ªHARNESS LAYOUTº (EL-452).
System DescriptionNLEL0407NATS (Nissan Anti-Theft S

Component Parts and Harness Connector
Location
=NLEL0406For details, refer to ªELECTRICAL UNIT LOCATIONº (EL-442) and ªHARNESS LAYOUTº (EL-452).
System DescriptionNLEL0407NATS (Nissan Anti-Theft System) has the following immobilizer functions:
+Since only NATS ignition keys, whose ID nos. have been registered into the ECM and IMMU of NATS,
allow the engine to run, operation of a stolen vehicle without a NATS registered key is prevented by NATS.
That is to say, NATS will immobilize the engine if someone tries to start it without the registered key of
NATS.
+This version of NATS has dongle unit to improve its anti-theft performance (RHD models only). Dongle
unit has its own ID which is registered into NATS IMMU. So if dongle unit is replaced, initialization must
be carried out.
+When malfunction of dongle unit is detected:
The security indicator lamp illuminates for about 15 minutes after ignition switch is turned to ON.
þ When dongle unit has a malfunction and the indicator lamp is illuminated, engine can not be started.
However engine can be started only one time when security indicator lamp turns off in about 15 minutes
after ignition switch is turned to ON.
+All of the originally supplied ignition key IDs have been NATS registered.
If requested by the vehicle owner, a maximum of five key IDs can be registered into the NATS compo-
nents.
+The security indicator blinks when the ignition switch is in ªOFFº or ªACCº position. Therefore, NATS warns
outsiders that the vehicle is equipped with the anti-theft system.
+When NATS detects trouble, the security indicator lamp lights up as follows.
Condition IGN ON andWith dongle Without dongle
MIL Security indicator MIL Security indicator
NATS malfunction
(except dongle unit) is
detectedÐ1. 6 times blinking
2. Staying ON after igni-
tion switch is turned
ONÐ Staying ON
Only malfunction of
dongle unit is detected.ÐStaying ON for about 15
minutes after ignition
switch is turned ONÐÐ
Malfunction of NATS
and engine related parts
are detected.Staying ON1. 6 times blinking
2. Staying ON after igni-
tion switch is turned
ONStaying ON Staying ON
Only engine related part
malfunction is detected.Staying ON Ð Staying ON Ð
Just after initialization of
NATSÐ 6 times blinking Ð Ð
+NATS trouble diagnoses, system initialization and additional registration of other NATS ignition key IDs
must be carried out using CONSULT-II hardware and CONSULT-II NATS software.
Regarding the procedures of NATS initialization and NATS ignition key ID registration, refer to CONSULT-II
operation manual, NATS.
+When servicing a malfunction of the NATS (indicated by lighting up of Security Indicator Lamp) or
registering another NATS ignition key ID no., it may be necessary to re-register original key iden-
tification. Therefore, be sure to receive ALL KEYS from vehicle owner.
NATS (NISSAN ANTI-THEFT SYSTEM)
Component Parts and Harness Connector Location
EL-334

Page 2066 of 3051

NISSAN ALMERA TINO 2001 Service Repair Manual System Composition=NLEL0408The immobilizer function of the NATS consists of the following:
+NATS ignition key
+NATS immobilizer control unit (IMMU) located in the ignition key cylinder
+Engine control

Page 2067 of 3051

NISSAN ALMERA TINO 2001 Service Repair Manual SchematicNLEL0509MODELS WITH NATS SECURITY INDICATOR ON DASH
BOARD
NLEL0509S02
YEL951B
NATS (NISSAN ANTI-THEFT SYSTEM)
Schematic
EL-336

Page 2068 of 3051

NISSAN ALMERA TINO 2001 Service Repair Manual MODELS WITH NATS SECURITY INDICATOR IN
COMBINATION METER
NLEL0509S01
YEL468C
NATS (NISSAN ANTI-THEFT SYSTEM)
Schematic (Contd)
EL-337

Page 2069 of 3051

NISSAN ALMERA TINO 2001 Service Repair Manual Wiring Diagram Ð NATS ÐNLEL0409MODELS WITH NATS SECURITY INDICATOR ON DASH BOARDNLEL0409S04LHD ModelsNLEL0409S0401
YEL952B
NATS (NISSAN ANTI-THEFT SYSTEM)
Wiring Diagram Ð NATS Ð
EL-338

Page 2070 of 3051

NISSAN ALMERA TINO 2001 Service Repair Manual YEL953B
NATS (NISSAN ANTI-THEFT SYSTEM)
Wiring Diagram Ð NATS Ð (Contd)
EL-339

Page 2071 of 3051

NISSAN ALMERA TINO 2001 Service Repair Manual RHD ModelsNLEL0409S0402
YEL954B
NATS (NISSAN ANTI-THEFT SYSTEM)
Wiring Diagram Ð NATS Ð (Contd)
EL-340

Page 2072 of 3051

NISSAN ALMERA TINO 2001 Service Repair Manual YEL955B
NATS (NISSAN ANTI-THEFT SYSTEM)
Wiring Diagram Ð NATS Ð (Contd)
EL-341
