Page 2649 of 3051

NISSAN ALMERA TINO 2001 Service Repair Manual 6 CHECK CIRCUIT CONTINUITY BETWEEN BLOWER MOTOR AND RESISTOR Check circuit continuity between blower motor harness terminal No. 2 and fan resistor harness terminal No. 1. NHA414 Continuity should exis

Page 2650 of 3051

NISSAN ALMERA TINO 2001 Service Repair Manual 10 CHECK FAN SWITCH CIRCUIT Do approx. 12 volts exist between each fan switch harness terminal and body ground? NHA416 YesorNo Ye s©GO TO 13. No©GO TO 11. 11 CHECK CIRCUIT CONTINUITY BETWEEN HEATER

Page 2651 of 3051

NISSAN ALMERA TINO 2001 Service Repair Manual 12 CHECK CIRCUIT CONTINUITY BETWEEN HEATER CONTROL PANEL AND BLOWER MOTOR Check circuit continuity between heater control panel harness terminal No. 17 and blower motor harness terminal No. 2. NHA418

Page 2652 of 3051

NISSAN ALMERA TINO 2001 Service Repair Manual NHA386 ELECTRICAL COMPONENTS INSPECTION=NLHA0146Fan SwitchNLHA0146S01Check continuity between terminals at each switch position. KNOB POSITION Continuity between terminals OFF No continuity 113—14

Page 2653 of 3051

NISSAN ALMERA TINO 2001 Service Repair Manual Magnet Clutch TROUBLE DIAGNOSIS PROCEDURE FOR MAGNET CLUTCH=NLHA0155SYMPTOM: +Magnet clutch does not operate when A/C switch and fan switch are ON. INSPECTION FLOW NHA387 *1: HA-100 *2: HA-63*3: HA-41

Page 2654 of 3051

NISSAN ALMERA TINO 2001 Service Repair Manual MAGNET CLUTCH CIRCUIT (FOR QG AND SR ENGINE)=NLHA0156SYMPTOM: +Magnet clutch does not engage when A/C switch and fan switch are ON. 1 CHECK POWER SUPPLY FOR COMPRESSOR Disconnect compressor harness co

Page 2655 of 3051

NISSAN ALMERA TINO 2001 Service Repair Manual 4 CHECK POWER SUPPLY FOR A/C RELAY Disconnect A/C relay. Do approx. 12 volts exist between A/C relay harness terminal Nos. 1, 5 and body ground? RHA635H YesorNo Ye s©GO TO 5. No©Check power supply c

Page 2656 of 3051

NISSAN ALMERA TINO 2001 Service Repair Manual 7 CHEC KCIRCUI TCONTINUIT YBETWEE NA/C REL AY AN DEC MHARNESS NHA422 8 CHEC KVO LTAG EFO RECM NHA423 9 CHEC KREFRIGERAN TPRESSUR ESENSOR Magne tClutc h(Cont ’d)
