Page 225 of 3051

SFA693
3. Press support bearing assembly off of drive shaft.
SFA617
4. Separate support bearing from retainer.
INSPECTIONNLAX0018Thoroughly clean all parts in cleaning solvent, and dry with
compressed air. Check parts for evidence of deformation or
other damage.
Drive ShaftNLAX0018S01Replace drive shaft if it is twisted or cracked.
BootNLAX0018S02Check boot for fatigue, cracks or wear. Replace boot with new boot
bands.
Joint Assembly (Transaxle side)NLAX0018S03+Check spider assembly for needle bearing and washer dam-
age. Replace if necessary. (Tripod type)
+Check roller surfaces for scratches, wear or other damage.
Replace if necessary. (Tripod type)
+Replace any parts of double offset joint which show signs of
scorching, rust, wear or excessive play. (Double offset type)
+Check serration for deformation. Replace if necessary.
+Check slide joint housing for any damage. Replace if neces-
sary.
Joint Assembly (Wheel side)NLAX0018S04Replace joint assembly if it is deformed or damaged.
Support BearingNLAX0018S05Make sure wheel bearing rolls freely and is free from noise, cracks,
pitting or wear.
Support Bearing BracketNLAX0018S06Check support bearing bracket for cracks with a magnetic explora-
tion or dyeing test.
ASSEMBLYNLAX0019+After drive shaft has been assembled, ensure that it
moves smoothly over its entire range without binding.
FRONT AXLE
Drive Shaft (Cont’d)
AX-14
Page 226 of 3051
+Use grease according to AX-19, SDS.
SFA800
Wheel Side (B83, B90 & AC2300I)NLAX0019S011. Install boot and new small boot band on drive shaft.
Cover drive shaft serration with tape so as not to damage boot
during installation.
SFA942A
2. Set joint assembly onto drive shaft by lightly tapping it.
Install joint assembly securely, ensuring marks which were
made during disassembly are properly aligned.
SFA592B
3. Pack drive shaft with specified amount of grease.
Specified amount of grease:
Refer to AX-19, SDS
4. Make sure that boot is properly installed on the drive shaft
groove.
Set boot so that it does not swell and deform when its length
is“L
1”.
Length“L
1”:
Refer to AX-19, SDS
SFA443B
5. Lock new larger and smaller boot bands securely with a suit-
able tool.
FRONT AXLE
Drive Shaft (Cont’d)
AX-15
Page 227 of 3051

SFA313B
Dynamic Damper (where fitted)NLAX0019S021. Use new damper bands when installing.
2. Install dynamic damper from stationary-joint side while holding
it securely.
Length:
Refer to AX-20, SDS.
SFA800
Transaxle Side (D90)NLAX0019S031. Install boot and new small boot band on drive shaft.
Cover drive shaft serration with tape so as not to damage boot
during installation.
SFA514A
2. Install ball cage, inner race and balls or spider assembly as a
unit, making sure the marks which were made during disas-
sembly are properly aligned.
3. Install new snap ring.
SFA149A
4. Pack drive shaft with specified amount of grease.
Specified amount of grease:
Refer to AX-19, SDS
5. Install slide joint housing, then install new snap ring.
6. Make sure that boot is properly installed on the drive shaft
groove.
Set boot so that it does not swell and deform when its length
is“L
2”.
Length“L
2”:
Refer to AX-19, SDS
SFA395
7. Lock new larger and smaller boot bands securely with a suit-
able tool.
FRONT AXLE
Drive Shaft (Cont’d)
AX-16
Page 228 of 3051
SFA800
Transaxle side (T83, T86C & GI2300I)NLAX0019S051. Install boot and new small boot band on drive shaft.
Cover drive shaft serration with tape so as not to damage boot
during installation.
SFA612
2. Install spider assembly securely, making sure the marks which
were made during disassembly are properly aligned.
3. Install new snap ring.
NAX005
4. Pack drive shaft with specified amount of grease.
Specified amount of grease:
Refer to AX-19, SDS
5. Install slide joint housing.
6. Set boot so that it does not swell and deform when its lenght
is“L
2”:
Refer to AX-19, SDS
SFA395
Make sure that the boot is properly installed on the drive shaft
groove.
7. Lock new larger and smaller boot bands securely with a suit-
able tool.
SFA618
Support BearingNLAX0019S04+Press bearing into retainer.
FRONT AXLE
Drive Shaft (Cont’d)
AX-17
Page 229 of 3051
SFA694
+Press drive shaft into bearing.
SFA444B
+Install snap ring.
+Install new dust shield.
FRONT AXLE
Drive Shaft (Cont’d)
AX-18
Page 230 of 3051

Service Data and Specifications (SDS)
DRIVE SHAFT=NLAX0020
NLAX0020S02
QG SR YD
LH RH
Joint type Transaxle side T83 GI2300I D90 T86C D90
Grease Quality 39709-55E00
Joint type Wheel side B83 AC2300I Z100 B90
Grease Quality Nissan genuine grease or equivalent 39209-01A00Nissan genuine
grease or equiva-
lent
Grease
Capacity
g (oz)Transaxle side125 - 145
(4.41 - 5.11)125.5 - 135.5
(4.42 - 4.77)165 - 175
(5.82 - 6.17)145 - 155
(5.11 - 5.47)145 - 165
(5.11 - 5.82)
Wheel side80 - 100
(2.82 - 3.53)40-50
(1.41 - 1.76)Cannot be disassembled *2120 - 140
(4.41 - 4.94)
Boot length
mm (in)Transaxle side“L
2”98 - 100
(3.86 - 3.94)*197 - 99 (3.82 - 3.90)*1 98 (3.86) *1
Wheel side“L
1”94-96
(3.70 - 3.78)*1Cannot be disassembled *2 110 (4.33)
SFA961AA
SFA962A
*1: Fit boot to boot groove in bar shaft
*2: Z100 type joint assembly cannot be disassembled because a plastic boot and special boot band are used. Do not use other drive
shaft boots. If the boot or joint is damaged, replace the drive shaft assembly.
FRONT AXLE
Service Data and Specifications (SDS)
AX-19
Page 231 of 3051
DYNAMIC DAMPER (WHERE FITTED)=NLAX0033
NLAX0033S01
Unit: mm (in)
QG YD SR
LH RH LH RH LH RH
Distance“A”178 - 184
(7.01 - 7.24)375 - 381
(14.76 - 15.00)172 - 178
(6.77 - 7.01)190 -196
(7.48 - 7.72)205 -215
(8.07 - 8.46)205 - 215
(8.07 - 8.46)
“B”70 (2.76) 64 (2.52) 70 (2.76) 70 (2.76) 70 (2.76) 70 (2.76)
SAX015
WHEEL BEARING (FRONT)NLAX0021
Wheel bearing axial end play limit mm (in) 0.05 (0.0020)
Wheel bearing lock nut tightening torque
N·m (kg-m, ft-lb)255 - 333 (26 - 34, 188 - 245)
FRONT AXLE
Service Data and Specifications (SDS) (Cont’d)
AX-20
Page 232 of 3051
SBR686C
Precautions
PRECAUTIONSNLAX0022+When installing each rubber part, final tightening must be
carried out under unladen condition* with tires on ground.
*: Fuel, radiator coolant and engine oil full. Spare tire, jack,
hand tools and mats in designated positions.
+Use flare nut wrench when removing or installing brake
tubes.
+After installing removed suspension parts, check wheel
alignment.
+Do not jack up at the trailing arm and lateral link.
+Always torque brake lines when installing.
Preparation
SPECIAL SERVICE TOOLSNLAX0032
Tool number
Tool nameDescription
KV40104710
Drift
NT474
Install ABS sensor rotor
a: 76.3 mm (3.004 in) dia.
b: 67.9 mm (2.673 in) dia.
ST3072000
Drift
NT115
Install ABS sensor rotor
a: 77 mm (3.03 in) dia.
b: 55.5 mm (2.185 in) dia.
COMMERCIAL SERVICE TOOLSNLAX0024
Tool name Description
1 Flare nut crowfoot
2 Torque wrench
NT360
Removing and installing brake piping
a: 10 mm (0.39 in)
REAR AXLE
Precautions
AX-21
