INFINITI QX56 2004 Factory Service Manual EC-178Revision: August 2007
DTC P0125 ECT SENSOR
2004 QX56
DTC P0125 ECT SENSORPFP:22630
Component DescriptionUBS00H1Y
NOTE:
If DTC P0125 is displayed with P0117 or P0118, first perform the trouble di

Page 1370 of 3371

INFINITI QX56 2004 Factory Service Manual DTC P0125 ECT SENSOR
EC-179
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: August 20072004 QX56
DTC Confirmation ProcedureUBS00H20
CAUTION:
Be careful not to overheat engine.
NOTE:
If DTC Confirmation Procedure

Page 1371 of 3371

INFINITI QX56 2004 Factory Service Manual EC-180Revision: August 2007
DTC P0125 ECT SENSOR
2004 QX56
3. CHECK THERMOSTAT OPERATION
When the engine is cold [lower than 70°C (158°F)] condition, grasp lower radiator hose and confirm the engine

Page 1372 of 3371

INFINITI QX56 2004 Factory Service Manual DTC P0127 IAT SENSOR
EC-181
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: August 20072004 QX56
DTC P0127 IAT SENSORPFP:22630
Component DescriptionUBS00H24
The intake air temperature sensor is built into mass ai

Page 1373 of 3371

INFINITI QX56 2004 Factory Service Manual EC-182Revision: August 2007
DTC P0127 IAT SENSOR
2004 QX56
b. Select “DATA MONITOR” mode with CONSULT-II.
c. Check the engine coolant temperature.
d. If the engine coolant temperature is not les

Page 1374 of 3371

INFINITI QX56 2004 Factory Service Manual DTC P0127 IAT SENSOR
EC-183
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: August 20072004 QX56
Component InspectionUBS00H28
INTAKE AIR TEMPERATURE SENSOR
1. Check resistance between intake air temperature senso

Page 1375 of 3371

INFINITI QX56 2004 Factory Service Manual EC-184Revision: August 2007
DTC P0128 THERMOSTAT FUNCTION
2004 QX56
DTC P0128 THERMOSTAT FUNCTIONPFP:21200
On Board Diagnosis LogicUBS00H2A
Engine coolant temperature has not risen enough to open the

EC-184Revision: August 2007
DTC P0128 THERMOSTAT FUNCTION
2004 QX56
DTC P0128 THERMOSTAT FUNCTIONPFP:21200
On Board Diagnosis LogicUBS00H2A
Engine coolant temperature has not risen enough to open the thermostat even though the engine has run long
enough.
This is due to a leak in the seal or the thermostat stuck open.
DTC Confirmation ProcedureUBS00H2B
NOTE:
If DTC Confirmation Procedure has been previously conducted, always turn ignition switch OFF and wait at
least 10 seconds before conducting the next test.
TESTING CONDITION:
For best results, perform at ambient temperature of –10°C (14°F) or higher.
For best results, perform at engine coolant temperature of –10°C (14°F) to 60°C (140°F).
WITH CONSULT-II
1. Replace thermostat with new one. Refer to CO-17, "THERMOSTAT AND WATER PIPING" . Use only a
genuine NISSAN thermostat as a replacement. If an incorrect thermostat is used, the MIL may come on.
2. Turn ignition switch ON.
3. Select “COOLAN TEMP/S” in “DATA MONITOR” mode with CONSULT-II.
4. Check that the “COOLAN TEMP/S” is above 60°C (140°F).
If it is below 60°C (140°F), go to following step.
If it is above 60°C (140°F), cool down the engine to less than 60°C (140°F), then retry from step 1.
5. Drive vehicle for 10 consecutive minutes under the following conditions.
If 1st trip DTC is detected, go to EC-184, "
Diagnostic Procedure" .
WITH GST
1. Follow the procedure “WITH CONSULT-II” above.
Diagnostic ProcedureUBS00H2C
1. CHECK ENGINE COOLANT TEMPERATURE SENSOR
Refer to EC-184, "
Component Inspection" .
OK or NG
OK >>INSPECTION END
NG >> Replace engine coolant temperature sensor.
Component InspectionUBS00H2D
ENGINE COOLANT TEMPERATURE SENSOR
Check resistance as shown in the figure.
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
P0128
0128Thermostat functionThe engine coolant temperature does not
reach to specified temperature even though
the engine has run long enough.
Thermostat
Leakage from sealing portion of thermostat
Engine coolant temperature sensor
VHCL SPEED SE 80 - 120 km/h (50 - 75 MPH)
PBIB2064E

Page 1376 of 3371

INFINITI QX56 2004 Factory Service Manual DTC P0128 THERMOSTAT FUNCTION
EC-185
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: August 20072004 QX56
<Reference data>
If NG, replace engine coolant temperature sensor.
Removal and InstallationUBS00H2E
