Page 2457 of 3371

INFINITI QX56 2004 Factory Service Manual LT-26 HEADLAMP (FOR USA) Revision: August 20072004 QX56 4. INSPECTION BETWEEN IPDM E/R AND HEADLAMPS 1. Disconnect IPDM E/R connector and inoperative headlamp connector. 2. Check continuity between ha

Page 2458 of 3371

INFINITI QX56 2004 Factory Service Manual HEADLAMP (FOR USA) LT-27 C D E F G H I J L MA B LT Revision: August 20072004 QX56 3. CHECK IPDM E/R 1. Select “IPDM E/R” on CONSULT-II, and select “DATA MONI- TOR” on “SELECT DIAG MODE” sc

Page 2459 of 3371

INFINITI QX56 2004 Factory Service Manual LT-28 HEADLAMP (FOR USA) Revision: August 20072004 QX56 6. CHECK HEADLAMP GROUND 1. Turn ignition switch OFF. 2. Check continuity between front combination lamp RH harness connector E107 terminal 1 (B

Page 2460 of 3371

INFINITI QX56 2004 Factory Service Manual HEADLAMP (FOR USA) LT-29 C D E F G H I J L MA B LT Revision: August 20072004 QX56 3. CHECK HEADLAMP GROUND 1. Turn the low beam headlamps OFF. 2. Check continuity between inoperative headlamp connecto

Page 2461 of 3371

INFINITI QX56 2004 Factory Service Manual LT-30 HEADLAMP (FOR USA) Revision: August 20072004 QX56 3. CHECKING CAN COMMUNICATIONS BETWEEN BCM AND IPDM E/R Select “BCM” on CONSULT-II and perform self-diagnosis for BCM. Display of self-diagn

Page 2462 of 3371

INFINITI QX56 2004 Factory Service Manual HEADLAMP (FOR USA) LT-31 C D E F G H I J L MA B LT Revision: August 20072004 QX56 Aiming AdjustmentEKS007A6 For details, refer to the regulations in your state. Before performing aiming adjustment, ch

Page 2463 of 3371

INFINITI QX56 2004 Factory Service Manual LT-32 HEADLAMP (FOR USA) Revision: August 20072004 QX56 If the vehicle front body has been repaired and/or the headlamp assembly has been replaced, check aiming. Use the aiming chart shown in the figu

Page 2464 of 3371

INFINITI QX56 2004 Factory Service Manual HEADLAMP (FOR USA) LT-33 C D E F G H I J L MA B LT Revision: August 20072004 QX56 4. Installation is in the reverse order of removal. CAUTION: After installing the bulb, be sure to install the bulb s
