SRS-20
TROUBLE DIAGNOSIS
Revision: August 20072004 QX56
HOW TO ERASE SELF-DIAGNOSIS RESULTS
After a malfunction is repaired, turn the ignition switch OFF for at least one second, then back ON. Diagnosis
mode returns to the User mode. At that time, the self-diagnostic result is cleared.
SRS Operation CheckEHS000WG
DIAGNOSTIC PROCEDURE 1
Checking SRS Operation Using “AIR BAG” Warning Lamp—User Mode
1. Turn the ignition switch from OFF to ON, and check that the air bag warning lamp blinks.
2. Compare the SRS air bag warning lamp blinking pattern with the
examples.
BF-1845D
Page 3082 of 3371

TROUBLE DIAGNOSIS
SRS-21
C
D
E
F
G
I
J
K
L
MA
B
SRS
Revision: August 20072004 QX56
Warning lamp examples
“AIR BAG” warning lamp operation-User mode- SRS condition Reference item
No malfunction is detected.
No further action is necessary.—
The system is malfunctioning and
needs to be repaired as indicated.Go to SRS-22, "DIAGNOSTIC
PROCEDURE 2" or SRS-37,
"DIAGNOSTIC PROCEDURE 6" .
Air bag is deployed.
Seat belt pre-tensioner is deployed.
Seat belt buckle pre-tensioner
assembly is deployed.Go to SRS-60, "
COLLISION DIAG-
NOSIS" .
Air bag diagnosis sensor unit is mal-
functioning.
Air bag power supply circuit is mal-
functioning.
SRS air bag warning lamp circuit is
malfunctioning.Go to SRS-43, "
Trouble Diagnosis:
“AIR BAG” Warning Lamp Does Not
Tu rn O ff" .
Air bag diagnosis sensor unit is mal-
functioning.
Air bag warning lamp circuit is mal-
functioning.Go to SRS-44, "
Trouble Diagnosis:
“AIR BAG” Warning Lamp Does Not
Tu rn O n" .
SHIA0 011 E
SHIA0012E
SHIA0013E
SHIA0014E
Page 3083 of 3371
SRS-22
TROUBLE DIAGNOSIS
Revision: August 20072004 QX56
Trouble Diagnosis With CONSULT-IIEHS000WH
DIAGNOSTIC PROCEDURE 2
CAUTION:
If CONSULT-II is used with no connection of CONSULT-II CONVERTER, malfunction might be detected
in self-diagnosis depending on control unit which carries out CAN communication.
1. Turn ignition switch OFF.
2. Connect CONSULT-II and CONSULT-II CONVERTER to the
data link connector.
3. Turn ignition switch ON.
4. Touch “START (NISSAN BASED VHCL)”.
5. Touch “AIR BAG”.
If "AIR BAG" is not indicated, refer to GI-39, "
CONSULT-II Data
Link Connector (DLC) Circuit" .
6. Touch "SELF-DIAG [CURRENT]".
BBIA0369E
BCIA0029E
BCIA0030E
BCIA0031E
Page 3084 of 3371
![INFINITI QX56 2004 Factory Service Manual TROUBLE DIAGNOSIS
SRS-23
C
D
E
F
G
I
J
K
L
MA
B
SRS
Revision: August 20072004 QX56
7. Diagnostic code is displayed on "SELF-DIAG [CURRENT]".
If no malfunction is detected on "SELF-DIAG [CURRENT]" even INFINITI QX56 2004 Factory Service Manual TROUBLE DIAGNOSIS
SRS-23
C
D
E
F
G
I
J
K
L
MA
B
SRS
Revision: August 20072004 QX56
7. Diagnostic code is displayed on "SELF-DIAG [CURRENT]".
