INFINITI QX56 2004 Factory Service Manual BR-6 BRAKE PEDAL Revision: August 20072004 QX56 BRAKE PEDALPFP:46501 Inspection and Adjustment EFS003P7 INSPECTION 1. Inspect the brake pedal free height "H" from the lower dash panel using tool. 2.

Page 986 of 3371

INFINITI QX56 2004 Factory Service Manual BRAKE PEDAL BR-7 C D E G H I J K L MA B BR Revision: August 20072004 QX56 ADJUSTMENT 1. Loosen the stop lamp switch and ASCD switch by turning 45° counterclockwise. 2. Loosen lock nut on the input ro

Page 987 of 3371

INFINITI QX56 2004 Factory Service Manual BR-8 BRAKE PEDAL Revision: August 20072004 QX56 Removal and Installation EFS003P8 REMOVAL WAR NIN G: Do not deform the brake tube. CAUTION: Before removal and installation the accelerator and brake

Page 988 of 3371

INFINITI QX56 2004 Factory Service Manual BRAKE PEDAL BR-9 C D E G H I J K L MA B BR Revision: August 20072004 QX56 3. Disconnect the adjustable brake pedal cable from the adjustable pedal electric motor. Unlock (1) then pull (2) the adjusta

Page 989 of 3371

INFINITI QX56 2004 Factory Service Manual BR-10 BRAKE FLUID Revision: August 20072004 QX56 BRAKE FLUIDPFP:KN100 On-board InspectionEFS003P9 LEVEL CHECK Make sure the fluid level in reservoir tank is within the standard (between MAX and MIN l

Page 990 of 3371

INFINITI QX56 2004 Factory Service Manual BRAKE FLUID BR-11 C D E G H I J K L MA B BR Revision: August 20072004 QX56 Bleeding Brake SystemEFS003PB CAUTION: While bleeding, pay attention to master cylinder fluid level. 1. Turn ignition switch

Page 991 of 3371

INFINITI QX56 2004 Factory Service Manual BR-12 BRAKE PIPING AND HOSE Revision: August 20072004 QX56 BRAKE PIPING AND HOSEPFP:46210 Hydraulic CircuitEFS003PC CAUTION: All hoses and tubes must be free from excessive bending, twisting and pull

Page 992 of 3371

INFINITI QX56 2004 Factory Service Manual BRAKE PIPING AND HOSE BR-13 C D E G H I J K L MA B BR Revision: August 20072004 QX56 INSTALLATION 1. Install brake hose by aligning with the protrusion on caliper assembly, and tighten union bolt. CAU
