Page 2545 of 3371

INFINITI QX56 2004 Factory Service Manual LT-114 PARKING, LICENSE PLATE AND TAIL LAMPS Revision: August 20072004 QX56 Terminals and Reference Values for BCMEKS007CI Terminal No.Wire colorSignal nameMeasuring condition Reference value (Appro

Page 2546 of 3371

INFINITI QX56 2004 Factory Service Manual PARKING, LICENSE PLATE AND TAIL LAMPS LT-115 C D E F G H I J L MA B LT Revision: August 20072004 QX56 Terminals and Reference Values for IPDM E/REKS007CJ How to Proceed With Trouble DiagnosisEKS007CK

Page 2547 of 3371

INFINITI QX56 2004 Factory Service Manual LT-116 PARKING, LICENSE PLATE AND TAIL LAMPS Revision: August 20072004 QX56 Preliminary CheckEKS007CL CHECK POWER SUPPLY AND GROUND CIRCUIT 1. CHECK FUSES OR FUSIBLE LINK Check for blown fuses or fusi

Page 2548 of 3371

INFINITI QX56 2004 Factory Service Manual PARKING, LICENSE PLATE AND TAIL LAMPS LT-117 C D E F G H I J L MA B LT Revision: August 20072004 QX56 CONSULT-II FunctionsEKS007CM Refer to LT- 1 8 , "CONSULT-II Function (BCM)" in HEADLAMP (FOR US

Page 2549 of 3371

INFINITI QX56 2004 Factory Service Manual LT-118 PARKING, LICENSE PLATE AND TAIL LAMPS Revision: August 20072004 QX56 4. CHECK INPUT SIGNAL With CONSULT-II 1. Turn ignition switch OFF. 2. Disconnect front combination lamp, license plate lamp

Page 2550 of 3371

INFINITI QX56 2004 Factory Service Manual PARKING, LICENSE PLATE AND TAIL LAMPS LT-119 C D E F G H I J L MA B LT Revision: August 20072004 QX56 5. CHECK PARKING, LICENSE PLATE AND TAIL LAMP CIRCUIT 1. Turn ignition switch OFF. 2. Disconnect

Page 2551 of 3371

INFINITI QX56 2004 Factory Service Manual LT-120 PARKING, LICENSE PLATE AND TAIL LAMPS Revision: August 20072004 QX56 6. CHECK GROUND 1. Check continuity between front combination lamp harness con- nector and ground. 2. Check continuity betwe

Page 2552 of 3371

INFINITI QX56 2004 Factory Service Manual PARKING, LICENSE PLATE AND TAIL LAMPS LT-121 C D E F G H I J L MA B LT Revision: August 20072004 QX56 Front Parking LampEKS007CP BULB REPLACEMENT For bulb replacement, refer to LT- 3 2 , "FRONT PARKI
