Page 3281 of 3371
WT-2
PREPARATION
Revision: August 20072004 QX56
PREPARATIONPFP:00002
Special Service ToolEES00120
The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.
Commercial Service ToolsEES00121
Tool number
(Kent-Moore No.)
Tool nameDescription
(J-45295)
Transmitter activation toolID registration
LEIA0035E
Tool nameDescription
Power toolRemoving wheel nuts
PBIC0190E
Page 3282 of 3371

NOISE, VIBRATION, AND HARSHNESS (NVH) TROUBLESHOOTING
WT-3
C
D
F
G
H
I
J
K
L
MA
B
WT
Revision: August 20072004 QX56
NOISE, VIBRATION, AND HARSHNESS (NVH) TROUBLESHOOTINGPFP:00003
NVH Troubleshooting ChartEES00122
Use the chart below to help you find the cause of the symptom. If necessary, repair or replace these parts.
×: ApplicableReference page
WT-4WT-5WT-33WT-6—
—
WT-33
RFD-5, "
NVH Troubleshooting Chart
" (FFD),
RFD-5, "
NVH Troubleshooting Chart
" (RFD)
FAX -4, "
NVH Troubleshooting Chart
" (FAX),
FSU-4, "
NVH Troubleshooting Chart
" (FSU)
RAX-4, "
NVH Troubleshooting Chart
" (RAX),
RSU-5, "
NVH Troubleshooting Chart
" (RSU)
Refer to TIRES in this chart.
Refer to ROAD WHEEL in this chart.
BR-5, "
NVH Troubleshooting Chart
"
PS-5, "
NVH Troubleshooting Chart
"
Possible cause and SUSPECTED PARTS
Out-of-round
Imbalance
Incorrect tire pressure
Uneven tire wear
Deformation or damage
Non-uniformity
Incorrect tire size
DIFFERENTIAL
FRONT AXLE AND FRONT SUSPENSION
REAR AXLE AND REAR SUSPENSION
TIRES
ROAD WHEEL
BRAKE
STEERING
SymptomTIRESNoise× ××××× × × × × ××
Shake××××× × ××× ××
Vibration××××××
Shimmy× ×××××× × × × ××
Shudder××××× × ××× ××
Poor quality ride or
handling××××× × ×××
ROAD
WHEELNoise×× × ××× ×××
Shake×× × ×× ×××
Shimmy, shudder×× × ×× ×××
Poor quality ride or
handling×× × ×× ×
Page 3283 of 3371
WT-4
WHEEL
Revision: August 20072004 QX56
WHEELPFP:40300
InspectionEES00123
1. Check tires for wear and improper inflation.
2. Check wheels for deformation, cracks and other damage. If
deformed, remove wheel and check wheel runout.
a. Remove tire from wheel and mount wheel on a tire balance
machine.
b. Set dial indicator as shown in the illustration. Refer to WT-33,
"Road Wheel" .
3. Check front wheel bearings for looseness.
4. Check front suspension for looseness.
SFA975B
Page 3284 of 3371

WHEEL AND TIRE ASSEMBLY
WT-5
C
D
F
G
H
I
J
K
L
MA
B
WT
Revision: August 20072004 QX56
WHEEL AND TIRE ASSEMBLYPFP:40300
Balancing WheelsEES00124
REMOVAL
1. Using releasing agent, remove double-faced adhesive tape from the wheel.
CAUTION:
Be careful not to scratch the wheel during removal.
After removing double-faced adhesive tape, wipe clean traces of releasing agent from the
wheel.
WHEEL BALANCE ADJUSTMENT
If a tire balance machine has adhesion balance weight mode settings and drive-in weight mode setting,
select and adjust a drive-in weight mode suitable for wheels.
1. Set wheel on wheel balancer using the center hole as a guide. Start the tire balance machine.
2. When inner and outer imbalance values are shown on the wheel balancer indicator, multiply outer imbal-
ance value by 1.6 to determine balance weight that should be used. Select the outer balance weight with
a value closest to the calculated value and install it to the designated outer position of, or at the desig-
nated angle in relation to the road wheel.
CAUTION:
Do not install the inner balance weight before installing the outer balance weight.
Before installing the balance weight, be sure to clean the mating surface of the wheel.
Indicated imbalance value × 5/3 = balance weight to be installed
Calculation example:
23 g (0.81 oz) × 5/3 = 38.33 g (1.35 oz) = 40 g (1.41 oz) balance
weight (closer to calculated balance weight value)
Note that balance weight value must be closer to the calculated
balance weight value.
Example:
37.4 g = 35 g (1.23 oz)
37.5 g = 40 g (1.41 oz)
a. Install balance weight in the position shown.
b. When installing balance weight to wheels, set it into the grooved
area on the inner wall of the wheel as shown so that the balance
weight center is aligned with the wheel balancer indication posi-
tion (angle).
CAUTION:
Always use Genuine NISSAN adhesion balance weights.
Balance weights are not reusable; always replace with
new ones.
Do not install more than three sheets of balance weights.
SM A05 4D
WDIA0060E
Page 3285 of 3371

WT-6
WHEEL AND TIRE ASSEMBLY
Revision: August 20072004 QX56
c. If calculated balance weight value exceeds 50 g (1.76 oz), install
two balance weight sheets in line with each other as shown.
CAUTION:
Do not install one balance weight sheet on top of another.
3. Start wheel balancer again.
4. Install drive-in balance weight on inner side of road wheel in the
wheel balancer indication position (angle).
CAUTION:
Do not install more than two balance weights.
5. Start wheel balancer. Make sure that inner and outer residual
imbalance values are 5 g (0.18 oz) each or below.
If either residual imbalance value exceeds 5 g (0.18 oz), repeat installation procedures.
Wheel balance (Maximum allowable imbalance):
RotationEES00125
Follow the maintenance schedule for tire rotation service intervals. Refer to MA-6, "PERIODIC MAINTE-
NANCE" .
Do not include the spare tire when rotating the tires.
CAUTION:
When installing wheels, tighten them diagonally by dividing
the work two to three times in order to prevent the wheels
from developing any distortion.
Maximum allowable
imbalanceDynamic (At rim flange) 5 g (0.18 oz) (one side)
Static 10 g (0.35 oz)
SM A05 6D
Wheel nut torque: : 133 N·m (14 kg-m, 98 ft-lb)
SM A82 9C
Page 3286 of 3371
LOW TIRE PRESSURE WARNING SYSTEM
WT-7
C
D
F
G
H
I
J
K
L
MA
B
WT
Revision: August 20072004 QX56
LOW TIRE PRESSURE WARNING SYSTEMPFP:40300
System ComponentsEES00126
System DescriptionEES00127
TRANSMITTER
A sensor-transmitter integrated with a valve is installed on a wheel,
and transmits a detected air pressure signal in the form of a radio
wave.
REMOTE KEYLESS ENTRY RECEIVER
Receives the air pressure signal transmitted by the transmitter in
each wheel.
WEIA0081E
WEIA0137E
LEIA0069E
Page 3287 of 3371
WT-8
LOW TIRE PRESSURE WARNING SYSTEM
Revision: August 20072004 QX56
BCM (BODY CONTROL MODULE)
Reads the air pressure signal received by the remote keyless entry
receiver, and controls the low tire pressure warning lamp and the
buzzer operations as shown below. It also has a judgement function
to detect a system malfunction.
LOW TIRE PRESSURE WARNING LAMP AND BUZZER
Indicates low tire pressure or system malfunction.
DISPLAY UNIT
Displays the air pressure of each tire.
After the ignition switch is turned on, the pressure values are not
be displayed until the data of each wheel is received.
LEIA0068E
ConditionLow tire pressure
warning lampBuzzer
Less than 193 kPa (2.0 kg/cm
2 , 28 psi)
[Flat tire]ONSounds for
10 sec.
System malfunction ON OFF
LEIA0055E
WEIA0082E
Page 3288 of 3371
CAN COMMUNICATION
WT-9
C
D
F
G
H
I
J
K
L
MA
B
WT
Revision: August 20072004 QX56
CAN COMMUNICATIONPFP:23710
System DescriptionEES00128
Refer to LAN-5, "CAN COMMUNICATION" .
