INFINITI QX56 2004 Factory Service Manual ATC-52
TROUBLE DIAGNOSIS
Revision: August 20072004 QX56
21 V/R Sensor ground ON - 0 - 5V
22 Y/R Power supply for BAT - - Battery voltage
23 R/L Power supply for illumination ON Park lamps ON Battery v

Page 458 of 3371

INFINITI QX56 2004 Factory Service Manual TROUBLE DIAGNOSIS
ATC-53
C
D
E
F
G
H
I
K
L
MA
B
AT C
Revision: August 20072004 QX56
A/C System Self-diagnosis FunctionEJS002CA
DESCRIPTION
Using Front Air Control Switches
NOTE:
Ambient temperature mu

Page 459 of 3371

INFINITI QX56 2004 Factory Service Manual ATC-54
TROUBLE DIAGNOSIS
Revision: August 20072004 QX56
Using Confirmation/Adjustment Mode (NAVI)
NOTE:
Ambient temperature must be at least 10° C (50° F) to run self-diagnosis.
1. Start engine.
2.

Page 460 of 3371

INFINITI QX56 2004 Factory Service Manual TROUBLE DIAGNOSIS
ATC-55
C
D
E
F
G
H
I
K
L
MA
B
AT C
Revision: August 20072004 QX56
SELF-DIAGNOSIS CODE CHART
Code No. Reference page
02 EE changed by calibrationATC-135, "
FRONT AIR CONTROL"
03 Batte

TROUBLE DIAGNOSIS
ATC-55
C
D
E
F
G
H
I
K
L
MA
B
AT C
Revision: August 20072004 QX56
SELF-DIAGNOSIS CODE CHART
Code No. Reference page
02 EE changed by calibrationATC-135, "
FRONT AIR CONTROL"
03 Battery voltage out of rangeSC-4, "BATTERY"
04 Mode switch circuit open or shortATC-135, "FRONT AIR CONTROL"
05 Blower motor malfunctionAT C - 8 3 , "Front Blower Motor Circuit"
12 Air mix door motor (Passenger) circuit malfunctionAT C - 7 1 , "DIAGNOSTIC PROCEDURE FOR AIR MIX DOOR
MOTOR (PASSENGER)"
20 BCM not responding to A/C requestATC-104, "Magnet Clutch Circuit"
21 BCM not responding to rear defroster requestGW-78, "REAR WINDOW DEFOGGER"
22 Air mix door motor (Driver) circuit malfunctionAT C - 6 9 , "DIAGNOSTIC PROCEDURE FOR AIR MIX DOOR
MOTOR (DRIVER)"
30 In-vehicle sensor circuit out of range (low)
ATC-128, "In-vehicle Sensor Circuit"31 In-vehicle sensor circuit out of range (high)
34 Air mix door motor (Driver) PBR circuit malfunctionAT C - 6 9 , "
DIAGNOSTIC PROCEDURE FOR AIR MIX DOOR
MOTOR (DRIVER)"
36Air mix door motor (Passenger) PBR circuit malfunc-
tionAT C - 7 1 , "DIAGNOSTIC PROCEDURE FOR AIR MIX DOOR
MOTOR (PASSENGER)"
38 Air mix door motor (rear) circuit malfunctionAT C - 7 3 , "DIAGNOSTIC PROCEDURE FOR AIR MIX DOOR
MOTOR (REAR)"
40 Ambient sensor circuit short
ATC-125, "Ambient Sensor Circuit"41 Ambient sensor circuit open
44 In-vehicle sensor motor circuit open
ATC-128, "
In-vehicle Sensor Circuit"46 In-vehicle sensor motor circuit short
50 Optical sensor (Driver) circuit open or short
ATC-131, "
Optical Sensor Circuit"52 Optical sensor (Passenger) circuit open or short
56 Intake sensor circuit short
ATC-133, "
Intake Sensor Circuit"57 Intake sensor circuit open
62 Defroster door motor circuit malfunctionAT C - 7 9 , "
Defroster Door Motor Circuit"
72 Intake door motor circuit malfunctionAT C - 7 6 , "Intake Door Motor Circuit"
80 CAN bus malfunction
LAN-5, "CAN COMMUNICATION"81 CAN BCM message missing
82 Intake door motor circuit malfunctionAT C - 7 6 , "
Intake Door Motor Circuit"
90 Stuck buttonATC-135, "FRONT AIR CONTROL"
92 Mode door motor circuit malfunctionAT C - 6 3 , "Mode Door Motor Circuit"

Page 461 of 3371

INFINITI QX56 2004 Factory Service Manual ATC-56
TROUBLE DIAGNOSIS
Revision: August 20072004 QX56
Operational Check (Front)EJS002CB
The purpose of the operational check is to confirm that the system operates properly.
CHECKING MEMORY FUNCTION

Page 462 of 3371

INFINITI QX56 2004 Factory Service Manual TROUBLE DIAGNOSIS
ATC-57
C
D
E
F
G
H
I
K
L
MA
B
AT C
Revision: August 20072004 QX56
CHECKING DISCHARGE AIR
1. Press MODE switch four times and then rotate the DEF dial
counterclockwise.
2. Each positi

Page 463 of 3371

INFINITI QX56 2004 Factory Service Manual ATC-58
TROUBLE DIAGNOSIS
Revision: August 20072004 QX56
CHECKING TEMPERATURE INCREASE
1. Rotate temperature dial clockwise (driver or passenger) until
32°C (90°F) is displayed.
2. Check for hot air

Page 464 of 3371

INFINITI QX56 2004 Factory Service Manual TROUBLE DIAGNOSIS
ATC-59
C
D
E
F
G
H
I
K
L
MA
B
AT C
Revision: August 20072004 QX56
Operational Check (Rear)EJS002CC
The purpose of the operational check is to confirm that the system operates properl
