AUTOMATIC BACK DOOR SYSTEM
Revision: August 20072004 QX56
Half-Latch Switch System InspectionEIS002T8
1. HALF-LATCH SWITCH SIGNAL INSPECTION
1. Turn ignition switch OFF.
2. While fully opening and closing the back door, check voltage
between back door control unit connector B55 terminal 22 and
ground.
OK or NG
OK >> Half-latch switch is OK.
NG >> GO TO 2.
2. HALF-LATCH SWITCH CIRCUIT INSPECTION
1. Disconnect back door latch and back door control unit connector.
2. Check continuity between back door control unit connector (A)
B55 terminal 22 and back door latch (half-latch switch) connec-
tor (B) D503 terminal 6.
3. Check continuity between back door latch (half-latch switch)
connector (B) D503 terminal 6 and ground.
OK or NG
OK >> GO TO 3.
NG >> Repair or replace harness.
3. HALF-LATCH SWITCH GROUND INSPECTION
Check continuity between back door latch (half-latch switch) connec-
tor D503 terminal 8 and ground.
OK or NG
OK >> Replace the back door latch.
NG >> Repair or replace harness.
22 (BR) - Ground
LIIA0826EPIIA2169E
6 (BR) - 22 (BR) : Continuity should exist.
6 (BR) - 22 (BR) : Continuity should not exist.
LIIA2259E
8 (B) - Ground : Continuity should exist.
LIIA0828E
Page 890 of 3371

AUTOMATIC BACK DOOR SYSTEM
BL-125
C
D
E
F
G
H
J
K
L
MA
B
BL
Revision: August 20072004 QX56
Open Switch System InspectionEIS002T9
1. OPEN SWITCH SIGNAL INSPECTION
1. Turn ignition switch OFF.
2. While fully closing and opening the back door, check voltage
between back door control unit connector B55 terminal 15 and
ground.
OK or NG
OK >> Open switch is OK.
NG >> GO TO 2.
2. OPEN SWITCH CIRCUIT INSPECTION
1. Disconnect back door latch and back door control unit connector.
2. Check continuity between back door control unit connector (A)
B55 terminal 15 and back door latch (open switch) connector (B)
D503 terminal 4.
3. Check continuity between back door latch (open switch) connec-
tor (B) D503 terminal 4 and ground.
OK or NG
OK >> GO TO 3.
NG >> Repair or replace harness.
3. OPEN SWITCH GROUND INSPECTION
Check continuity between back door latch (open switch) connector
D503 terminal 8 and ground.
OK or NG
OK >> Replace the back door latch.
NG >> Repair or replace harness.
15 (O/L) - Ground
LIIA0829EPIIA2171E
4 (O/L) - 15 (O/L) : Continuity should exist.
4 (O/L) - ground : Continuity should not exist.
LIIA2260E
8 (B) - Ground : Continuity should exist.
LIIA0828E
Page 891 of 3371

BL-126
AUTOMATIC BACK DOOR SYSTEM
Revision: August 20072004 QX56
Close Switch System InspectionEIS002TA
1. CLOSE SWITCH SIGNAL INSPECTION
1. Turn ignition switch OFF.
2. While fully opening and closing the back door, check voltage
between back door control unit connector B55 terminal 14 and-
ground.
OK or NG
OK >> Close switch is OK.
NG >> GO TO 2.
2. CLOSE SWITCH CIRCUIT INSPECTION
1. Disconnect back door latch and back door control unit.
2. Check continuity between back door control unit connector (A)
B55 terminal 14 and back door latch (close switch) connector
(B) D503 terminal 5.
3. Check continuity between back door latch (close switch) con-
nector (B) D503 terminal 5 and ground.
OK or NG
OK >> GO TO 3.
NG >> Repair or replace harness.
3. CLOSE SWITCH GROUND INSPECTION
Check continuity between back door latch (close switch) connector
D503 terminal 8 and ground.
OK or NG
OK >> Replace the back door latch.
NG >> Repair or replace harness.
14 (P) - Ground
LIIA0831EPIIA2172E
5 (P) - 14 (P) : Continuity should exist.
5 (P) - ground : Continuity should not exist.
LIIA2261E
8 (B) - Ground : Continuity should exist.
LIIA0828E
Page 892 of 3371

AUTOMATIC BACK DOOR SYSTEM
BL-127
C
D
E
F
G
H
J
K
L
MA
B
BL
Revision: August 20072004 QX56
Back Door Handle Switch System InspectionEIS002TB
1. BACK DOOR HANDLE SWITCH SIGNAL INSPECTION
1. Turn ignition switch OFF.
2. While operating the back door handle switch, check voltage
between back door control unit connector B55 terminal 26 and
ground.
OK or NG
OK >> Switch is OK.
NG >> GO TO 2.
2. BACK DOOR HANDLE SWITCH CIRCUIT INSPECTION
1. Disconnect back door handle switch and back door control unit.
2. Check continuity between back door control unit connector (A)
B55 terminal 26 and back door handle switch connector (B)
D706 terminal 3.
3. Check continuity between back door handle switch connector
(B) D706 terminal 3 and ground.
OK or NG
OK >> GO TO 4.
NG >> Repair or replace harness.
3. BACK DOOR HANDLE SWITCH GROUND INSPECTION
Check continuity between back door handle switch connector D706
terminal 4 and ground.
OK or NG
OK >> Replace the back door handle switch.
NG >> Repair or replace harness.
Connector terminal
(Wire color)
ConditionVoltage (V)
(Approx.)
( + ) ( - )
26 (V) GroundBack door handle switch (ON) 0
Other (OFF) 5
LIIA0833E
3 (V) - 26 (V) : Continuity should exist.
3 (V) - 26 (V) : Continuity should not exist.
LIIA2262E
4 (B) - Ground : Continuity should exist.
WIIA0605E
Page 893 of 3371

BL-128
AUTOMATIC BACK DOOR SYSTEM
Revision: August 20072004 QX56
Cinch Latch Motor System InspectionEIS002TC
1. CINCH LATCH MOTOR CIRCUIT INSPECTION
1. Turn ignition switch OFF.
2. Disconnect back door latch and back door control unit.
3. Check continuity between back door control unit connector (A)
B55 terminals 11, 12 and back door latch (cinch latch motor)
connector (B) D503 terminals 1, 2.
4. Check continuity between back door latch (cinch latch motor)
connector (B) D503 terminals 1, 2 and ground.
OK or NG
OK >> GO TO 2.
NG >> Repair or replace harness.
2. CINCH LATCH MOTOR OPERATION INSPECTION
Connect battery power to terminals 1 and 2 on the back door latch
and check motor operation.
OK or NG
OK >> GO TO 3.
NG >> Replace the back door latch.
3. CINCH LATCH MOTOR SIGNAL INSPECTION
1. Reconnect back door latch and back door control unit.
2. While fully opening and closing the back door, check voltage
between back door control unit connector B55 terminals 11, 12
and ground.
OK or NG
OK >> Cinch latch motor circuit is OK.
NG >> Replace the back door control unit.1 (L) - 12 (L) : Continuity should exist.
2 (Y) - 11 (Y) : Continuity should exist.
1 (L) - ground : Continuity should not exist.
2 (Y) - ground : Continuity should not exist.
LIIA2263E
1 (+) - 2 (-) : It operates.
1 (-) - 2 (+) : It operates. (Reverse rotation)
LIIA1937E
11 (Y) - Ground
12 (L) - Ground
LIIA0836ESIIA1480E
