Page 3217 of 3371

TF-92
TROUBLE DIAGNOSES FOR SYMPTOMS
Revision: August 20072004 QX56
Symptom 7. 4WD Shift Indicator Lamp Repeats Flickering (4WD Shift Indicator
Lamp Keeps Flickering)
EDS0018K
1. CHECK 4WD SHIFT INDICATOR LAMP
1. Set 4WD shift switch to 2WD position.
2. Move vehicle forward and backward. Or drive straight increasing
or decreasing speed under 20 km/h (12 MPH).
3. Does 4WD shift indicator lamp keep flickering?
Ye s o r N o
Yes >> GO TO 2.
No >> Inspection End.
2. CHECK TIGHT CORNER BRAKING SYMPTOM
Drive vehicle at speed under 20 km/h (12 MPH), turning steering wheel to the limit. Does tight corner braking
symptom occur?
Ye s o r N o
Yes >> GO TO 3.
No >> GO TO 4.
3. CHECK 4WD SHIFT INDICATOR LAMP
Does the 4WD shift indicator lamp keep flickering when the front wheels are jacked up?
Ye s o r N o
Yes >> Check transfer unit operating system.
No >> Check tires.
4. CHECK 4WD WARNING LAMP
Does 4WD warning lamp flicker? (4WD shift indicator lamp is turned OFF.)
Ye s o r N o
Yes >> Perform self-diagnosis. Refer to TF-27, "Trouble Diagnosis without CONSULT-II" .
No >> GO TO 5.
5. CHECK 4WD SHIFT INDICATOR LAMP
Does 4WD shift indicator lamp keep flickering?
Ye s o r N o
Yes >> Check again.
No >> Inspection End.
WDIA0071E
Page 3218 of 3371

TROUBLE DIAGNOSES FOR SYMPTOMS
TF-93
C
E
F
G
H
I
J
K
L
MA
B
TF
Revision: August 20072004 QX56
Symptom 8. Tight Corner Braking Symptom (Tight Corner Braking Symptom
Occurs-Hydraulic System Failure)
EDS0018L
1. CHECK INPUT SIGNAL
With CONSULT-II
1. Select “ECU INPUT SIGNALS” in Data Monitor.
2. Put A/T selector lever in D.
3. Turn 4WD shift switch to 4H and back to 2WD while reading out
ON/OFF status of "CL PRES SW".
Without CONSULT-II
Check voltage between transfer control unit harness connector E143
terminal 34 (BR) and ground.
Refer to TF-55, "
TRANSFER CONTROL UNIT INSPECTION
TABLE" .
OK or NG
OK >> Disassemble transfer unit and check the following.
Control valve assembly
4WD solenoid valve
2-4WD shift solenoid valve
Clutch piston
Clutch assembly
NG >> GO TO 2.
2. CHECK CLUTCH PRESSURE SWITCH CIRCUIT
Check clutch pressure switch circuit.
Refer to TF-72, "
Diagnostic Procedure" .
OK or NG
OK >> GO TO 3.
NG >> Check, repair or replace faulty parts.
3. CHECK PROCEDURES FROM THE BEGINNING AGAIN
Check again.
OK or NG
OK >> Inspection End.
NG >> Recheck each connector pin terminals for damage or loose connection.
WDIA0087E
Page 3219 of 3371

TF-94
TROUBLE DIAGNOSES FOR SYMPTOMS
Revision: August 20072004 QX56
Symptom 9. 4WD System Does Not Operate (The Vehicle Cannot Be Put Into
4WD Mode-Hydraulic System Failure)
EDS0018M
1. CHECK INPUT SIGNAL
With CONSULT-II
1. Select “ECU INPUT SIGNALS” in Data Monitor.
2. Put A/T selector lever in D.
3. Turn 4WD shift switch to 4H and back to 2WD while reading out
ON/OFF status of "CL PRES SW".
Without CONSULT-II
Check voltage between transfer control unit harness connector E143
terminal 34 (BR) and ground.
Refer to TF-55, "
TRANSFER CONTROL UNIT INSPECTION
TABLE" .
OK or NG
OK >> 1. Check transfer fluid level.
2. Disassemble transfer unit and check the following.
–Transfer motor
–Main oil pump assembly
–Sub-oil pump assembly
–Oil strainer
–Control valve assembly
–2-4WD shift solenoid valve
–Oil filter element
–Lip seal
–Strainer O-ring
–Main oil pump drive gear
–Seal ring
–D-ring
–Clutch piston
–Clutch assembly
NG >> GO TO 2.
2. CHECK CLUTCH PRESSURE CIRCUIT
Check clutch pressure switch circuit.
Refer to TF-72, "
Diagnostic Procedure" .
OK or NG
OK >> GO TO 3.
NG >> Check, repair or replace faulty parts.
3. CHECK PROCEDURES FROM THE BEGINNING
Check again.
OK or NG
OK >> Inspection End.
NG >> Recheck each connector pin terminals for damage or loose connection.
WDIA0087E
Page 3220 of 3371

TROUBLE DIAGNOSES FOR SYMPTOMS
TF-95
C
E
F
G
H
I
J
K
L
MA
B
TF
Revision: August 20072004 QX56
Component InspectionEDS0018N
4WD SHIFT SWITCH
Check continuity between each terminal.
2-4WD SHIFT SOLENOID VALVE AND TRANSFER FLUID TEMPERATURE SENSOR
Measure resistance between terminals of transfer terminal cord
assembly harness connector F56.
4WD SOLENOID VALVE, CLUTCH PRESSURE SWITCH AND LINE PRESSURE SWITCH
Measure resistance between terminals of transfer terminal cord
assembly harness connector F56.
Terminals Switch position Continuity
1 - 22WD Yes
Except 2WD No
1 - 3, 1 - 4AUTO Yes
Except AUTO No
1 - 4, 1 - 54H Yes
Except 4H No
1 - 4, 1 - 64LO Yes
Except 4LO No
WDIA0090E
Component parts TerminalsResistance
(Approx.)
2-4WD shift solenoid valve 4 - 520°C (68°F):
22.8 - 25.2Ω
Transfer fluid temperature
sensor2 - 320°C (68°F): 2.5 kΩ
80°C (176°F): 0.3 kΩ
LDIA0093E
Component
partsTerminals Remarks
4WD sole-
noid valve6
Ground
terminalApprox. 20°C (68°F): Approx. 3.0 - 3.4Ω
Clutch pres-
sure switch7In room temperature
2-4WD shift solenoid valve “OFF”: No conti-
nuity
2-4WD shift solenoid valve and transfer
motor “ON”: Continuity exists
Line pressure
switch1In room temperature
Turn ignition switch to “OFF” position and
leave vehicle for more than 5 minutes.
(OFF): No continuity
Transfer motor “ON”: Continuity exists
LDIA0094E
Page 3221 of 3371
TF-96
TROUBLE DIAGNOSES FOR SYMPTOMS
Revision: August 20072004 QX56
TRANSFER DROPPING RESISTOR
Check resistance between terminals.
ATP SWITCH, NEUTRAL-4LO SWITCH AND WAIT DETECTION SWITCH
1. Remove the ATP switch, neutral-4LO switch and the wait detection switch.
2. Measure the resistance between terminals of ATP switch F55, neutral-4LO switch F60 , and wait detection
switch F59.
TRANSFER MOTOR
Apply battery voltage directly to transfer motor harness connector
F57. (Positive: Terminal 14, Negative: Terminal 15)
Transfer motor should operate.
WDIA0091E
Resistance : 11.2 - 12.8 Ω
Switch released state : Continuity should not
exist
Switch pushed state : Continuity should exist
WDIA0082E
LDIA0097E
Page 3222 of 3371

TROUBLE DIAGNOSES FOR SYMPTOMS
TF-97
C
E
F
G
H
I
J
K
L
MA
B
TF
Revision: August 20072004 QX56
TRANSFER MOTOR RELAY
1. Apply battery voltage and ground directly to transfer motor relay
E154 terminals 1 and 2.
2. Check continuity between transfer motor relay E153 terminals 3
and 5.
TRANSFER SHIFT RELAY (HIGH & LOW)
Check continuity between transfer shift high relay E46 and low relay
E47 terminals 3 and 4.
ACTUATOR AND ACTUATOR POSITION SWITCH
Actuator
Operation and resistance check
Apply battery voltage directly to actuator assembly.
Actuator Position Switch
Continuity check
Condition Continuity (3-5)
Battery voltage is applied Yes
No voltage is applied No
LDIA0098E
Condition Continuity
12V direct current supply
between terminals 1 and 2No
No current supply Yes
LDIA0099E
Operating check Battery positive terminal Battery negative terminal
121 24
224 21
Check Approx. 0.2Ω (When the motor is not operated.)
LDIA0100E
Continuity checkBattery positive
terminalBattery negative
terminalContinuity
121 24 20 - 22
224 21 23 - 22
LDIA0101E
Page 3223 of 3371

TF-98
TRANSFER CONTROL UNIT
Revision: August 20072004 QX56
TRANSFER CONTROL UNITPFP:33084
Removal and InstallationEDS00314
REMOVAL
1. Set transfer state as 2WD when 4WD shift switch is at 2WD, or as AUTO when 4WD shift switch is at
AUTO.
CAUTION:
When removing transfer control unit, transfer state must be at 2WD or AUTO.
2. Turn the ignition switch OFF and disconnect negative battery terminal.
3. Remove the glove box assembly. Refer to IP-14, "
Instrument Lower Cover RH and Glove Box" .
4. Disconnect the two transfer control unit connectors.
5. Remove the transfer control unit bolts.
6. Remove the transfer control unit.
INSTALLATION
Installation is in the reverse order of removal.
When installing the transfer control unit, tighten bolts to the specified torque.
CAUTION:
Do not connect harness connector to transfer control unit when 4WD shift switch is at 4LO.
After the installation, check perform self-diagnosis. Refer to TF-28, "SELF-DIAGNOSTIC PROCEDURE"
. If NG, adjust position between transfer assembly and transfer control unit.
BDIA0014E
Transfer control unit bolts : 5.1 N·m (0.52 kg-m, 45 in-lb)
Page 3224 of 3371
FRONT OIL SEAL
TF-99
C
E
F
G
H
I
J
K
L
MA
B
TF
Revision: August 20072004 QX56
FRONT OIL SEALPFP:38189
Removal and InstallationEDS00315
REMOVAL
1. Partially drain the transfer fluid. Refer to MA-24, "Changing Transfer Fluid" .
2. Remove the front propeller shaft. Refer to PR-4, "
Removal and Installation" .
3. Remove the companion flange self-lock nut, using Tool.
4. Put a matching mark on top of the front drive shaft in line with
the mark on the companion flange.
CAUTION:
Use paint to make the matching mark on the front drive
shaft. Do not damage the front drive shaft.
5. Remove the companion flange, using suitable tool.
6. Remove the oil seal from the front case, using Tool.
CAUTION:
Do not damage front case.Tool number : KV40104000 ( — )
SDIA2657E
SDIA2658E
WDIA0193E
Tool number : ST33290001 (J-34286)
LDIA0144E
