Page 241 of 3371

INFINITI QX56 2004 Factory Service Manual AT-170
DTC P1772 LOW COAST BRAKE SOLENOID VALVE
Revision: August 20072004 QX56
Diagnostic ProcedureUCS002HH
1. CHECK INPUT SIGNAL
With CONSULT-II
1. Turn ignition switch “ON”. (Do not start engin

Page 242 of 3371

INFINITI QX56 2004 Factory Service Manual DTC P1772 LOW COAST BRAKE SOLENOID VALVE
AT-171
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: August 20072004 QX56
6. CHECK DTC
Perform “DTC Confirmation Procedure”.
Refer to AT- 1 6 9 , "DTC Confirmation

Page 243 of 3371

INFINITI QX56 2004 Factory Service Manual AT-172
DTC P1774 LOW COAST BRAKE SOLENOID VALVE FUNCTION
Revision: August 20072004 QX56
DTC P1774 LOW COAST BRAKE SOLENOID VALVE FUNCTIONPFP:31940
DescriptionUCS002HI
Low coast brake solenoid valve i

AT-172
DTC P1774 LOW COAST BRAKE SOLENOID VALVE FUNCTION
Revision: August 20072004 QX56
DTC P1774 LOW COAST BRAKE SOLENOID VALVE FUNCTIONPFP:31940
DescriptionUCS002HI
Low coast brake solenoid valve is turned “ON” or “OFF” by the TCM in response to signals sent from the
PNP switch, vehicle speed sensor and accelerator pedal position sensor (throttle position sensor). Gears
will then be shifted to the optimum position.
This is not only caused by electrical malfunction (circuits open or shorted) but also by mechanical mal-
function such as control valve sticking, improper solenoid valve operation.
CONSULT-II Reference ValueUCS002HJ
On Board Diagnosis LogicUCS002HK
This is an OBD-II self-diagnostic item.
Diagnostic trouble code “LC/B SOLENOID FNCT” with CONSULT-II or P1774 without CONSULT-II is
detected under the following conditions.
–When TCM detects that actual gear ratio is irregular, and relation between gear position and condition of
ATF pressure switch 2 is irregular during depressing accelerator pedal. (Other than during shift change)
–When TCM detects that relation between gear position and condition of ATF pressure switch 2 is irregular
during releasing accelerator pedal. (Other than during shift change)
Possible CauseUCS002HL
Harness or connectors
(The solenoid and switch circuits are open or shorted.)
Low coast brake solenoid valve
ATF pressure switch 2
DTC Confirmation ProcedureUCS002HM
CAUTION:
Always drive vehicle at a safe speed.
NOTE:
If “DTC Confirmation Procedure” has been previously performed, always turn ignition switch “OFF”
and wait at least 10 seconds before performing the next test.
After the repair, perform the following procedure to confirm the malfunction is eliminated.
WITH CONSULT-II
1. Start engine.
2. Accelerate vehicle to maintain the following conditions.
Selector lever: “1” or “2” position
Gear position: “1st” or “2nd” gear (LC/B ON/OFF)
3. Perform step “2” again.
4. Turn ignition switch “OFF”, then perform step “1” to “3” again.
5. Check “SELF-DIAG RESULTS” mode for “A/T” with CONSULT-
II. If DTC (P1774) is detected, refer to AT-173, "
Diagnostic Pro-
cedure" .
If DTC (P1772) is detected, go to AT-170, "
Diagnostic Proce-
dure" .
WITH GST
Follow the procedure “With CONSULT-II”.
Item name Condition Display value (ON-OFF display)
ON OFF SOLLow coast brake engaged. Refer to AT- 2 1
. ON
Low coast brake disengaged. Refer to AT- 2 1
. OFF
ATF PRES SW 2Low coast brake engaged. Refer to AT- 2 1
. ON
Low coast brake disengaged. Refer to AT- 2 1
. OFF
BCIA0030E

Page 244 of 3371

INFINITI QX56 2004 Factory Service Manual DTC P1774 LOW COAST BRAKE SOLENOID VALVE FUNCTION
AT-173
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: August 20072004 QX56
Diagnostic ProcedureUCS002H N
1. CHECK INPUT SIGNALS
With CONSULT-II
1. Turn ignition

Page 245 of 3371

INFINITI QX56 2004 Factory Service Manual AT-174
DTC P1774 LOW COAST BRAKE SOLENOID VALVE FUNCTION
Revision: August 20072004 QX56
5. DETECT MALFUNCTIONING ITEM
Check the following items:
Power supply and ground circuit for TCM.
The A/T asse

Page 246 of 3371

INFINITI QX56 2004 Factory Service Manual DTC P1841 ATF PRESSURE SWITCH 1
AT-175
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: August 20072004 QX56
DTC P1841 ATF PRESSURE SWITCH 1PFP:25240
DescriptionUCS002HO
Fail-safe function to detect front brake cl

Page 247 of 3371

INFINITI QX56 2004 Factory Service Manual AT-176
DTC P1841 ATF PRESSURE SWITCH 1
Revision: August 20072004 QX56
Diagnostic ProcedureUCS002HT
1. CHECK INPUT SIGNAL
With CONSULT-II
1. Start engine.
2. Select “ECU INPUT SIGNALS” or “MAIN

Page 248 of 3371

INFINITI QX56 2004 Factory Service Manual DTC P1841 ATF PRESSURE SWITCH 1
AT-177
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: August 20072004 QX56
6. CHECK DTC
Perform “DTC Confirmation Procedure”.
Refer to AT- 1 7 5 , "DTC Confirmation Procedur
