INFINITI QX56 2004 Factory Service Manual LAN-74 [CAN] CAN SYSTEM (TYPE 2) Revision: August 20072004 QX56 Case 16 Check front air control circuit. Refer to LAN-87, "Front Air Control Circuit Check" . PKIA8104E PKIA8815E

Page 2338 of 3371

INFINITI QX56 2004 Factory Service Manual CAN SYSTEM (TYPE 2) LAN-75 [CAN] C D E F G H I J L MA B LAN Revision: August 20072004 QX56 Case 17 Check ABS actuator and electric unit (control unit) circuit. Refer to LAN-87, "ABS Actuator and Elect

Page 2339 of 3371

INFINITI QX56 2004 Factory Service Manual LAN-76 [CAN] CAN SYSTEM (TYPE 2) Revision: August 20072004 QX56 Case 18 Check IPDM E/R circuit. Refer to LAN-88, "IPDM E/R Circuit Check" . PKIA8106E PKIA8817E

Page 2340 of 3371

INFINITI QX56 2004 Factory Service Manual CAN SYSTEM (TYPE 2) LAN-77 [CAN] C D E F G H I J L MA B LAN Revision: August 20072004 QX56 Case 19 Check CAN communication circuit. Refer to LAN-88, "CAN Communication Circuit Check" . Case 20 Check

Page 2341 of 3371

INFINITI QX56 2004 Factory Service Manual LAN-78 [CAN] CAN SYSTEM (TYPE 2) Revision: August 20072004 QX56 Case 21 Check IPDM E/R ignition relay circuit continuously sticks “ON”. Refer to LAN-89, "IPDM E/R Ignition Relay Cir- cuit Check"

Page 2342 of 3371

INFINITI QX56 2004 Factory Service Manual CAN SYSTEM (TYPE 2) LAN-79 [CAN] C D E F G H I J L MA B LAN Revision: August 20072004 QX56 3. CHECK HARNESS FOR OPEN CIRCUIT 1. Disconnect ICC sensor connector. 2. Check continuity between harness con

Page 2343 of 3371

INFINITI QX56 2004 Factory Service Manual LAN-80 [CAN] CAN SYSTEM (TYPE 2) Revision: August 20072004 QX56 Circuit Check Between ICC Unit and Driver Seat Control UnitUKS001PP 1. CHECK CONNECTOR 1. Turn ignition switch OFF. 2. Disconnect the ne

Page 2344 of 3371

INFINITI QX56 2004 Factory Service Manual CAN SYSTEM (TYPE 2) LAN-81 [CAN] C D E F G H I J L MA B LAN Revision: August 20072004 QX56 3. CHECK HARNESS FOR OPEN CIRCUIT Check continuity between harness connector M40 terminals 51J (W), 52J (R) a
