INFINITI QX56 2004 Factory Service Manual AT-162
DTC P1764 DIRECT CLUTCH SOLENOID VALVE FUNCTION
Revision: August 20072004 QX56
6. CHECK DTC
Perform “DTC Confirmation Procedure”.
Refer to AT-160, "DTC Confirmation Procedure" .
OK or NG

Page 234 of 3371

INFINITI QX56 2004 Factory Service Manual DTC P1767 HIGH AND LOW REVERSE CLUTCH SOLENOID VALVE
AT-163
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: August 20072004 QX56
DTC P1767 HIGH AND LOW REVERSE CLUTCH SOLENOID VALVEPFP:31940
DescriptionUCS002H0
H

DTC P1767 HIGH AND LOW REVERSE CLUTCH SOLENOID VALVE
AT-163
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: August 20072004 QX56
DTC P1767 HIGH AND LOW REVERSE CLUTCH SOLENOID VALVEPFP:31940
DescriptionUCS002H0
High and low reverse clutch solenoid valve is controlled by the TCM in response to signals sent from the PNP
switch, vehicle speed sensor and accelerator pedal position sensor (throttle position sensor). Gears will then
be shifted to the optimum position.
CONSULT-II Reference ValueUCS002H1
On Board Diagnosis LogicUCS002H2
This is an OBD-II self-diagnostic item.
Diagnostic trouble code “HLR/C SOL/CIRC” with CONSULT-II or P1767 without CONSULT-II is detected
under the following conditions.
–When TCM detects an improper voltage drop when it tries to operate the solenoid valve.
–When TCM detects as irregular by comparing target value with monitor value.
Possible CauseUCS002H3
Harness or connectors
(The solenoid circuit is open or shorted.)
High and low reverse clutch solenoid valve
DTC Confirmation ProcedureUCS002H4
CAUTION:
Always drive vehicle at a safe speed.
NOTE:
If “DTC Confirmation Procedure” has been previously performed, always turn ignition switch “OFF”
and wait at least 10 seconds before performing the next test.
After the repair, perform the following procedure to confirm the malfunction is eliminated.
WITH CONSULT-II
1. Turn ignition switch “ON”. (Do not start engine.)
2. Select “DATA MONITOR” mode for “A/T” with CONSULT-II.
3. Start engine.
4. Drive vehicle and maintain the following conditions for at least 5
consecutive seconds.
ACCELE POS: 1.5/8 - 2.0/8
Selector lever: “D” position
Gear position: 2nd
3rd Gear (HLR/C ON/OFF)
Driving location: Driving the vehicle uphill (increased
engine load) will help maintain the driving conditions
required for this test.
5. If DTC is detected, go to AT - 1 6 4 , "
Diagnostic Procedure" .
WITH GST
Follow the procedure “With CONSULT-II”.
Item name Condition Display value (Approx) (A)
HLR/C SOLHigh and low reverse clutch disengaged. Refer to AT- 2 1
. 0.6 - 0.8
High and low reverse clutch engaged. Refer to AT- 2 1
. 0 - 0.05
BCIA0030E

Page 235 of 3371

INFINITI QX56 2004 Factory Service Manual AT-164
DTC P1767 HIGH AND LOW REVERSE CLUTCH SOLENOID VALVE
Revision: August 20072004 QX56
Diagnostic ProcedureUCS002H5
1. CHECK INPUT SIGNAL
With CONSULT-II
1. Turn ignition switch “ON”. (Do not

Page 236 of 3371

INFINITI QX56 2004 Factory Service Manual DTC P1767 HIGH AND LOW REVERSE CLUTCH SOLENOID VALVE
AT-165
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: August 20072004 QX56
6. CHECK DTC
Perform “DTC Confirmation Procedure”.
Refer to AT- 1 6 3 , "DTC

Page 237 of 3371

INFINITI QX56 2004 Factory Service Manual AT-166
DTC P1769 HIGH AND LOW REVERSE CLUTCH SOLENOID VALVE FUNCTION
Revision: August 20072004 QX56
DTC P1769 HIGH AND LOW REVERSE CLUTCH SOLENOID VALVE FUNCTION
PFP:31940
DescriptionUCS002H6
High an

AT-166
DTC P1769 HIGH AND LOW REVERSE CLUTCH SOLENOID VALVE FUNCTION
Revision: August 20072004 QX56
DTC P1769 HIGH AND LOW REVERSE CLUTCH SOLENOID VALVE FUNCTION
PFP:31940
DescriptionUCS002H6
High and low reverse clutch solenoid valve is controlled by the TCM in response to signals sent from the
PNP switch, vehicle speed sensor and accelerator pedal position sensor (throttle position sensor). Gears
will then be shifted to the optimum position.
This is not only caused by electrical malfunction (circuits open or shorted) but also by mechanical mal-
function such as control valve sticking, improper solenoid valve operation.
CONSULT-II Reference ValueUCS002H7
On Board Diagnosis LogicUCS002H8
This is an OBD-II self-diagnostic item.
Diagnostic trouble code “HLR/C SOL FNCTN” with CONSULT-II or P1769 without CONSULT-II is
detected under the following conditions.
–When TCM detects that actual gear ratio is irregular, and relation between gear position and condition of
ATF pressure switch 6 is irregular during depressing accelerator pedal. (Other than during shift change)
–When TCM detects that relation between gear position and condition of ATF pressure switch 6 is irregular
during releasing accelerator pedal. (Other than during shift change)
Possible CauseUCS002H9
Harness or connectors
(The solenoid and switch circuits are open or shorted.)
High and low reverse clutch solenoid valve
ATF pressure switch 6
DTC Confirmation ProcedureUCS002HA
CAUTION:
Always drive vehicle at a safe speed.
NOTE:
If “DTC Confirmation Procedure” has been previously performed, always turn ignition switch “OFF”
and wait at least 10 seconds before performing the next test.
After the repair, perform the following procedure to confirm the malfunction is eliminated.
WITH CONSULT-II
1. Start engine.
2. Accelerate vehicle to maintain the following conditions.
ACCELE POS: 1.5/8 - 2.0/8
Selector lever: “D” position
Gear position: 2nd
3rd Gear (HLR/C ON/OFF)
Driving location: Driving the vehicle uphill (increased
engine load) will help maintain the driving conditions
required for this test.
3. Perform step “2” again.
4. Turn ignition switch “OFF”, then perform step “1” to “3” again.
5. Check “SELF-DIAG RESULTS” mode for “A/T” with CONSULT-
II. If DTC (P1769) is detected, refer to AT-167, "
Diagnostic Procedure" .
If DTC (P1767) is detected, go to AT- 1 6 4 , "
Diagnostic Procedure" .
If DTC (P1846) is detected, go to AT- 1 8 5 , "
Diagnostic Procedure" .
Item name Condition Display value (Approx)
HLR/C SOL High and low reverse clutch disengaged. Refer to AT- 2 1
. 0.6 - 0.8 A
High and low reverse clutch engaged. Refer to AT- 2 1
. 0 - 0.05 A
ATF PRES SW 6High and low reverse clutch engaged. Refer to AT- 2 1
.ON
High and low reverse clutch disengaged. Refer to AT- 2 1
. OFF
BCIA0030E

Page 238 of 3371

INFINITI QX56 2004 Factory Service Manual DTC P1769 HIGH AND LOW REVERSE CLUTCH SOLENOID VALVE FUNCTION
AT-167
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: August 20072004 QX56
WITH GST
Follow the procedure “With CONSULT-II”.
Diagnostic Procedure

Page 239 of 3371

INFINITI QX56 2004 Factory Service Manual AT-168
DTC P1769 HIGH AND LOW REVERSE CLUTCH SOLENOID VALVE FUNCTION
Revision: August 20072004 QX56
5. DETECT MALFUNCTIONING ITEM
Check the following items:
Power supply and ground circuit for TCM.

Page 240 of 3371

INFINITI QX56 2004 Factory Service Manual DTC P1772 LOW COAST BRAKE SOLENOID VALVE
AT-169
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: August 20072004 QX56
DTC P1772 LOW COAST BRAKE SOLENOID VALVEPFP:31940
DescriptionUCS002H C
Low coast brake solenoid
