Page 2993 of 3371

SE-44
AUTOMATIC DRIVE POSITIONER
Revision: August 20072004 QX56
3. CHECK SLIDING MOTOR CIRCUIT HARNESS CONTINUITY
1. Turn ignition switch OFF.
2. Disconnect driver seat control unit and sliding motor LH.
3. Check continuity between driver seat control unit connector P3
terminals 35, 42 and sliding motor connector P4 terminals 4, 6.
4. Check continuity between driver seat control unit connector P3
terminals 35, 42 and ground.
OK or NG
OK >> GO TO 4.
NG >> Repair or replace harness.
4. CHECK DRIVER SEAT CONTROL UNIT OUTPUT SIGNAL
1. Connect the driver seat control unit and sliding motor LH.
2. Check voltage between driver seat control unit connector and
ground.
OK or NG
OK >> Replace sliding motor.
NG >> Replace driver seat control unit.
Reclining Motor LH Circuit InspectionEIS002YK
1. CHECK SEAT RECLINING MECHANISM
Check the following.
Operation malfunction caused by an interference with the center pillar or center console
Operation malfunction and interference with other parts by poor installation
OK or NG
OK >> GO TO 2.
NG >> Repair the malfunctioning part and check again.35 (V/W) - 6 (V/W) : Continuity should exist.
42 (O/B) - 4 (O/B) : Continuity should exist.
35 (V/W) - Ground : Continuity should not exist.
42 (O/B) - Ground : Continuity should not exist.
LIIA0696E
ConnectorTe r m i n a l s
(Wire color)
ConditionVoltage (V)
(Approx.)
(+) (–)
P335 (V/W)
GroundSliding switch ON
(FORWARD operation)Battery voltage
Other than above 0
42 (O/B)Sliding switch ON
(BACKWARD operation)Battery voltage
Other than above 0
PIIA4801E
Page 2994 of 3371

AUTOMATIC DRIVE POSITIONER
SE-45
C
D
E
F
G
H
J
K
L
MA
B
SE
Revision: August 20072004 QX56
2. CHECK FUNCTION
With CONSULT-II
Check operation with “SEAT RECLINING” in ACTIVE TEST.
Without CONSULT-II
GO TO 3.
OK or NG
OK >> Reclining motor LH circuit is OK.
NG >> GO TO 3.
3. CHECK RECLINING MOTOR CIRCUIT HARNESS CONTINUITY
1. Turn ignition switch OFF.
2. Disconnect driver seat control unit and reclining motor LH.
3. Check continuity between driver seat control unit connector P3 terminals 36, 44 and reclining motor LH
connector P5 terminals 3, 4.
4. Check continuity between driver seat control unit connector P3
terminals 36, 44 and ground.
OK or NG
OK >> GO TO 4.
NG >> Repair or replace harness.
Test item Description
SEAT
RECLININGThe reclining motor LH is activated by receiving the drive signal.
PIIA0268E
36 (Y/G) - 4 (Y/G) : Continuity should exist.
44 (Y/R) - 3 (Y/R) : Continuity should exist.
36 (Y/G) - Ground : Continuity should not exist.
44 (Y/R) - Ground : Continuity should not exist.
LIIA0697E
Page 2995 of 3371

SE-46
AUTOMATIC DRIVE POSITIONER
Revision: August 20072004 QX56
4. CHECK DRIVER SEAT CONTROL UNIT OUTPUT SIGNAL
1. Connect the driver seat control unit and reclining motor LH.
2. Check voltage between driver seat control unit connector and
ground.
OK or NG
OK >> Replace reclining motor LH.
NG >> Replace driver seat control unit.
Lifting Motor (Front) Circuit InspectionEIS002YL
1. CHECK FRONT END SEAT LIFTING MECHANISM
Check the following.
Operation malfunction caused by lifter mechanism deformation, pinched harness or other foreign materi-
als
Operation malfunction caused by foreign materials adhered to the lifting motor (front) or lead screws
Operation malfunction and interference with other parts by installation
OK or NG
OK >> GO TO 2.
NG >> Repair the malfunctioning part and check again.
2. CHECK FUNCTION
With CONSULT-II
Check operation with “SEAT LIFTER FR” in ACTIVE TEST.
Without CONSULT-II
GO TO 3.
OK or NG
OK >> Lifting motor (front) circuit is OK.
NG >> GO TO 3.
ConnectorTerminals
(Wire color)
ConditionVoltage (V)
(Approx.)
(+) (–)
P336 (Y/G)
GroundReclining switch ON
(FORWARD operation)Battery voltage
Other than above 0
44 (Y/R)Reclining switch ON
(BACKWARD operation)Battery voltage
Other than above 0
PIIA4802E
Test item Description
SEAT
LIFTER FRThe lifting motor (front) is activated by receiving the drive signal.
PIIA0271E
Page 2996 of 3371

AUTOMATIC DRIVE POSITIONER
SE-47
C
D
E
F
G
H
J
K
L
MA
B
SE
Revision: August 20072004 QX56
3. CHECK LIFTING MOTOR (FRONT) CIRCUIT HARNESS CONTINUITY
1. Turn ignition switch OFF.
2. Disconnect driver seat control unit and lifting motor (front).
3. Check continuity between driver seat control unit connector P3 terminals 37, 45 and lifting motor (front)
connector P6 terminals 4, 6.
4. Check continuity between driver seat control unit connector P3
terminals 37, 45 and ground.
OK or NG
OK >> GO TO 4.
NG >> Repair or replace harness.
4. CHECK DRIVER SEAT CONTROL UNIT OUTPUT SIGNAL
1. Connect the driver seat control unit and lifting motor (front).
2. Check voltage between driver seat control unit connector and
ground.
OK or NG
OK >> Replace lifting motor (front).
NG >> Replace driver seat control unit.
Lifting Motor (Rear) Circuit InspectionEIS002YM
1. CHECK REAR SEAT LIFTING MECHANISM
Check the following.
Operation malfunction caused by lifter mechanism deformation or pinched harness or other foreign mate-
rials
Operation malfunction caused by foreign materials adhered to the lifting motor (rear) or lead screws
Operation malfunction and interference with other parts by poor installation
OK or NG
OK >> GO TO 2.
NG >> Repair the malfunctioning part and check again.37 (BR) - 6 (BR) : Continuity should exist.
45 (GR) - 4 (GR) : Continuity should exist.
37 (BR) - Ground : Continuity should not exist.
45 (GR) - Ground : Continuity should not exist.
LIIA0698E
ConnectorTe r m i n a l s
(Wire color)
ConditionVoltage (V)
(Approx.)
(+) (–)
P337 (BR)
GroundLifting switch (front) ON
(DOWN operation)Battery voltage
Other than above 0
45 (GR)Llifting switch (front) ON
(UP operation)Battery voltage
Other than above 0
PIIA4805E
Page 2997 of 3371

SE-48
AUTOMATIC DRIVE POSITIONER
Revision: August 20072004 QX56
2. CHECK FUNCTION
With CONSULT-II
Check operation with “SEAT LIFTER RR” in ACTIVE TEST.
Without CONSULT-II
GO TO 3.
OK or NG
OK >> Lifting motor (rear) circuit is OK.
NG >> GO TO 3.
3. CHECK LIFTING MOTOR (REAR) CIRCUIT HARNESS CONTINUITY
1. Turn ignition switch OFF.
2. Disconnect driver seat control unit and lifting motor (rear).
3. Check continuity between driver seat control unit connector P3 terminals 38, 39 and lifting motor (rear)
connector P7 terminals 4, 6.
4. Check continuity between driver seat control unit P3 terminals
38, 39 and ground.
OK or NG
OK >> GO TO 4.
NG >> Repair or replace harness.
Test item Description
SEAT LIFTER
RRThe lifting motor (rear) is activated by receiving the drive signal.
PIIA0274E
38 (B/W) - 6 (B/W) : Continuity should exist.
39 (Y) - 4 (Y) : Continuity should exist.
38 (B/W) - Ground : Continuity should not exist.
39 (Y) - Ground : Continuity should not exist.
LIIA0699E
Page 2998 of 3371

AUTOMATIC DRIVE POSITIONER
SE-49
C
D
E
F
G
H
J
K
L
MA
B
SE
Revision: August 20072004 QX56
4. CHECK DRIVER SEAT CONTROL UNIT OUTPUT SIGNAL
1. Connect the driver seat control unit and lifting motor (rear).
2. Check voltage between driver seat control unit connector and
ground.
OK or NG
OK >> Replace lifting motor (rear).
NG >> Replace driver seat control unit.
Pedal Adjusting Motor Circuit InspectionEIS002YN
1. CHECK PEDAL ADJUSTING MECHANISM
Check the following.
Operation malfunction caused by pedal adjusting mechanism deformation or pinched harness or other
foreign materials
Operation malfunction and interference with other parts by poor installation
OK or NG
OK >> GO TO 2.
NG >> Repair the malfunctioning part and check again.
2. CHECK FUNCTION
With CONSULT-II
Check operation with “PEDAL” in ACTIVE TEST.
Without CONSULT-II
GO TO 3.
OK or NG
OK >> Pedal adjusting motor circuit is OK.
NG >> GO TO 3.
ConnectorTe r m i n a l s
(Wire color)
ConditionVoltage (V)
(Approx.)
(+) (–)
P338 (B/W)
GroundLifting switch (rear) ON
(UP operation)Battery voltage
Other than above 0
39 (Y)Lifting switch (rear) ON
(DOWN operation)Battery voltage
Other than above 0
PIIA4804E
Test item Description
ADJ PEDAL MOTORThe pedal adjusting motor is activated by receiving the
drive signal.
PIIA4555E
Page 2999 of 3371

SE-50
AUTOMATIC DRIVE POSITIONER
Revision: August 20072004 QX56
3. CHECK PEDAL ADJUSTING MOTOR CIRCUIT HARNESS CONTINUITY
1. Turn ignition switch OFF.
2. Disconnect automatic drive positioner control unit and pedal adjusting motor.
3. Check continuity between automatic drive positioner control unit connector M34 terminals 37, 45 and
pedal adjusting motor connector E109 terminals 1, 2.
4. Check continuity between automatic drive positioner control unit
connector M34 terminals 37, 45 and ground.
OK or NG
OK >> GO TO 4.
NG >> Repair or replace harness.
4. CHECK AUTOMATIC DRIVE POSITIONER CONTROL UNIT OUTPUT SIGNAL
1. Connect the automatic drive positioner control unit and pedal adjusting motor.
2. Check voltage between automatic drive positioner control unit
connector and ground.
OK or NG
OK >> Replace pedal adjusting motor.
NG >> Replace automatic drive positioner control unit.
Mirror Motor LH Circuit CheckEIS002YO
1. CHECK DOOR MIRROR LH MECHANISM
Check the following items.
Operation malfunction caused by a foreign object caught in door mirror face edge.
OK or NG
OK >> GO TO 2.
NG >> Repair the malfunctioning parts, and check the symptom again.37 (G) - 1 (G) : Continuity should exist.
45 (R) - 2 (R) : Continuity should exist.
37 (G) - Ground : Continuity should not exist.
45 (R) - Ground : Continuity should not exist.
LIIA1481E
ConnectorTerminals
(Wire color)
ConditionVoltage (V)
(Approx.)
(+) (–)
M3437 (G)
GroundPedal adjusting switch
ON
(FORWARD operation)Battery voltage
Other than above 0
45 (R)Pedal adjusting switch
ON
(BACKWARD opera-
tion)Battery voltage
Other than above 0
PIIA4806E
Page 3000 of 3371

AUTOMATIC DRIVE POSITIONER
SE-51
C
D
E
F
G
H
J
K
L
MA
B
SE
Revision: August 20072004 QX56
2. CHECK FUNCTION
With CONSULT–II
Check the operation with “MIRROR MOTOR LH” in the ACTIVE
TEST.
Without CONSULT–II
GO TO 3.
OK or NG
OK >> Mirror motor LH circuit is OK.
NG >> GO TO 3.
3. CHECK DOOR MIRROR MOTOR LH CIRCUIT HARNESS CONTINUITY
1. Turn ignition switch OFF.
2. Disconnect automatic drive positioner control unit and door mirror LH.
3. Check continuity between automatic drive positioner control unit connector M33 terminals 16, 31, 32 and
door mirror LH connector D4 terminals 1, 2, 3.
4. Check continuity between automatic drive positioner control unit
connector M41 terminal 16, 31, 32 and ground.
OK or NG
OK >> GO TO 4.
NG >> Repair or replace harness.
Test item Description
MIRROR MOTOR
LHThe mirror motor LH moves the mirror UP/DOWN and LEFT/
RIGHT by receiving the drive signal.
PIIA4784E
16 (O) - 3 (O) : Continuity should exist.
31 (R) - 1 (R) : Continuity should exist.
32 (BR) - 2 (BR) : Continuity should exist.
16 (O) - Ground : Continuity should not exist.
31 (R) - Ground : Continuity should not exist.
32 (BR) - Ground : Continuity should not exist.
LIIA1880E
