QUICK REFERENCE CHART: QX56

Disc Brake - Repair LimitsELS000ZU
Unit: mm (in)
Brake PedalELS000ZV
Unit: mm (in)
Refill CapacitiesELS000YO
Brake model CLZ31VC (Front) AD14VE (Rear)
Brake PadStandard thickness (new) 11.88 (0.468) 12.13 (0.478)
Repair limit thickness 1.0 (0.039) 1.0 (0.039)
Disc rotor Standard thickness (new) 26.0 (1.024) 14.0 (0.551)
Repair limit thickness 24.5 (0.965) 12.0 (0.472)
Maximum uneven wear (measured at 8 positions) 0.015 (0.0006) 0.015 (0.0006)
Runout limit (with it attached to the vehicle) 0.04 (0.0016) 0.05 (0.0020)
Brake pedal height (from dash lower panel top surface) 182.3
− 192.3 (7.18 − 7.57)
Depressed pedal height [under a force of 490 N (50 kg, 110 lb) with engine running] More than 90.3 (3.55)
Clearance between stopper rubber and the threaded end of stop lamp switch 0.74 − 1.96 (0.029 − 0.077)
Pedal play 3 − 11 (0.12 − 0.43)
Description Capacity (Approximate)
Metric US measure Imp measure
Fuel 105.8 28 gal 23 1/4 gal
Engine oil
Drain and refill With oil filter change
6.2 6 1/2 qt 5 1/2 qt
Without oil filter change 5.9 6 1/4 qt 5 1/4 qt
Dry engine (engine overhaul) 7.6 8 qt 6 3/4 qt
Cooling system With reservoir at MAX level 14.4 3 3/4 gal 3 1/8 gal
Automatic transmission fluid (ATF) 10.6 11 1/4 qt 9 3/8 qt
Rear final drive oil 1.75 3 3/4 pt 3 1/8 pt
Transfer fluid 3.0 3 1/8 qt 2 5/8 qt
Front final drive oil 1.6 3 3/8 pt 2 7/8 pt
Power steering fluid (PSF) 1.0 1 1/8 qt 7/8 qt
Windshield washer fluid 4.5 1 1/4 gal 1 gal
Air conditioning system refrigerant 1.08 ± 0.05 kg 2.38 ± 0.11 lb 2.38 ± 0.11 lb
Air conditioning system lubricants 290 m9.8 fl oz 10.2 fl oz

AT-4Revision: August 20072004 QX56 A/T Does Not Shift: 2nd gear → 1st gear .............227
