Page 2305 of 3371

INFINITI QX56 2004 Factory Service Manual LAN-42 [CAN] CAN SYSTEM (TYPE 1) Revision: August 20072004 QX56 3. CHECK HARNESS FOR OPEN CIRCUIT Check continuity between harness connector M40 terminals 51J (W), 52J (R) and data link connector M22

Page 2306 of 3371

INFINITI QX56 2004 Factory Service Manual CAN SYSTEM (TYPE 1) LAN-43 [CAN] C D E F G H I J L MA B LAN Revision: August 20072004 QX56 ECM Circuit CheckUKS0018L 1. CHECK CONNECTOR 1. Turn ignition switch OFF. 2. Disconnect the negative battery

Page 2307 of 3371

INFINITI QX56 2004 Factory Service Manual LAN-44 [CAN] CAN SYSTEM (TYPE 1) Revision: August 20072004 QX56 Driver Seat Control Unit Circuit CheckUKS0018N 1. CHECK CONNECTOR 1. Turn ignition switch OFF. 2. Disconnect the negative battery termin

Page 2308 of 3371

INFINITI QX56 2004 Factory Service Manual CAN SYSTEM (TYPE 1) LAN-45 [CAN] C D E F G H I J L MA B LAN Revision: August 20072004 QX56 Display Control Unit Circuit CheckUKS0018P 1. CHECK CONNECTOR 1. Turn ignition switch OFF. 2. Disconnect the

Page 2309 of 3371

INFINITI QX56 2004 Factory Service Manual LAN-46 [CAN] CAN SYSTEM (TYPE 1) Revision: August 20072004 QX56 Data Link Connector Circuit CheckUKS0018R 1. CHECK CONNECTOR 1. Turn ignition switch OFF. 2. Disconnect the negative battery terminal. 3

Page 2310 of 3371

INFINITI QX56 2004 Factory Service Manual CAN SYSTEM (TYPE 1) LAN-47 [CAN] C D E F G H I J L MA B LAN Revision: August 20072004 QX56 Front Air Control Circuit CheckUKS0018T 1. CHECK CONNECTOR 1. Turn ignition switch OFF. 2. Disconnect the neg

Page 2311 of 3371

INFINITI QX56 2004 Factory Service Manual LAN-48 [CAN] CAN SYSTEM (TYPE 1) Revision: August 20072004 QX56 IPDM E/R Circuit CheckUKS0018V 1. CHECK CONNECTOR 1. Turn ignition switch OFF. 2. Disconnect the negative battery terminal. 3. Check ter

Page 2312 of 3371

INFINITI QX56 2004 Factory Service Manual CAN SYSTEM (TYPE 1) LAN-49 [CAN] C D E F G H I J L MA B LAN Revision: August 20072004 QX56 2. CHECK HARNESS FOR SHORT CIRCUIT With all module and control unit connectors disconnected, check continuity
