Page 1905 of 3371

INFINITI QX56 2004 Factory Service Manual EM-22Revision: August 2007 OIL PAN AND OIL STRAINER 2004 QX56 OIL PAN AND OIL STRAINERP F P : 1111 0 Removal and InstallationEBS00ILH REMOVAL WAR NIN G: To avoid the danger of being scalded, never dra

Page 1906 of 3371

INFINITI QX56 2004 Factory Service Manual OIL PAN AND OIL STRAINER EM-23 C D E F G H I J K L MA EM Revision: August 20072004 QX56 b. Remove the oil pan (lower) using Tool. CAUTION: Do not damage mating surface. 3. Remove the oil strainer from

Page 1907 of 3371

INFINITI QX56 2004 Factory Service Manual EM-24Revision: August 2007 OIL PAN AND OIL STRAINER 2004 QX56 INSTALLATION 1. Install the oil pan (upper) using the following steps. a. Apply liquid gasket thoroughly as shown. Use Genuine RTV Silicon

Page 1908 of 3371

INFINITI QX56 2004 Factory Service Manual OIL PAN AND OIL STRAINER EM-25 C D E F G H I J K L MA EM Revision: August 20072004 QX56 b. Tighten the oil pan (lower) bolts in numerical order as shown. 4. Install the oil pan drain plug. 5. Installa

Page 1909 of 3371

INFINITI QX56 2004 Factory Service Manual EM-26Revision: August 2007 IGNITION COIL 2004 QX56 IGNITION COILPFP:22448 Removal and InstallationEBS00ILI REMOVAL 1. Remove the engine room cover using power tool. Refer to EM-11 . 2. Disconnect the

Page 1910 of 3371

INFINITI QX56 2004 Factory Service Manual SPARK PLUG (PLATINUM-TIPPED TYPE) EM-27 C D E F G H I J K L MA EM Revision: August 20072004 QX56 SPARK PLUG (PLATINUM-TIPPED TYPE)PFP:22401 Removal and InstallationEBS00ILJ REMOVAL 1. Remove the ignit

Page 1911 of 3371

INFINITI QX56 2004 Factory Service Manual EM-28Revision: August 2007 SPARK PLUG (PLATINUM-TIPPED TYPE) 2004 QX56 CAUTION: Do not drop or shock spark plug. Do not use a wire brush for cleaning. If plug tip is covered with carbon, spark plug

Page 1912 of 3371

INFINITI QX56 2004 Factory Service Manual FUEL INJECTOR AND FUEL TUBE EM-29 C D E F G H I J K L MA EM Revision: August 20072004 QX56 FUEL INJECTOR AND FUEL TUBEPFP:16600 Removal and InstallationEBS00ILK CAUTION: Do not remove or disassemble p
