Page 3049 of 3371

INFINITI QX56 2004 Factory Service Manual SE-100 FRONT SEAT Revision: August 20072004 QX56 2. Unhook the j-channel. 3. From inside of the seatback, squeeze the headrest holder tabs at the base of the stay pipe and pull up to remove. NOTE: Bef

Page 3050 of 3371

INFINITI QX56 2004 Factory Service Manual FRONT SEAT SE-101 C D E F G H J K L MA B SE Revision: August 20072004 QX56 4. From inside of the seatback, squeeze the headrest holder tabs at the base of the stay pipe and pull up to remove. NOTE: Be

Page 3051 of 3371

INFINITI QX56 2004 Factory Service Manual SE-102 FRONT SEAT Revision: August 20072004 QX56 3. Remove four bolts and the seat cushion assembly. 4. Remove the retainer on the seat cushion frame, then remove the harness connector for the seat he

Page 3052 of 3371

INFINITI QX56 2004 Factory Service Manual REAR SEAT SE-103 C D E F G H J K L MA B SE Revision: August 20072004 QX56 REAR SEATPFP:88300 Removal and InstallationEIS002ZK SECOND ROW OUTBOARD Removal 1. Remove seat base trim cover. 2. Lift handle

Page 3053 of 3371

INFINITI QX56 2004 Factory Service Manual SE-104 REAR SEAT Revision: August 20072004 QX56 4. Remove the rear anchor bolts from the seat assembly. 5. Remove the seat assembly. Installation Installation is in the reverse order of removal. LIIA1

Page 3054 of 3371

INFINITI QX56 2004 Factory Service Manual REAR SEAT SE-105 C D E F G H J K L MA B SE Revision: August 20072004 QX56 Disassembly and AssemblyEIS002ZL Second Row RH WIIA0473E

Page 3055 of 3371

INFINITI QX56 2004 Factory Service Manual SE-106 REAR SEAT Revision: August 20072004 QX56 1. Headrest 2. Seatback pad 3. Seatback frame 4. Rear seat bezel 5. RH Headrest guide 6. LH Headrest guide 7. Seat back panel 8. Seat actuator assembly

Page 3056 of 3371

INFINITI QX56 2004 Factory Service Manual REAR SEAT SE-107 C D E F G H J K L MA B SE Revision: August 20072004 QX56 Second row center WIIA0410E 1. Seatback pad 2. Armrest finisher 3. Headrest 4. Seat belt retractor cover 5. Seat belt bezel 6
