Page 2897 of 3371

INFINITI QX56 2004 Factory Service Manual RSU-38 FRONT LOWER LINK Revision: August 20072004 QX56 NOTE: Measurement point “A” is at the bolt groove of the ball stud. INSTALLATION Installation is in the reverse order of removal. Tighten th

Page 2898 of 3371

INFINITI QX56 2004 Factory Service Manual REAR LOWER LINK & COIL SPRING RSU-39 C D F G H I J K L MA B RSU Revision: August 20072004 QX56 REAR LOWER LINK & COIL SPRINGPFP:551B0 Removal and Installation EES0011P REMOVAL 1. Remove the wheel and

Page 2899 of 3371

INFINITI QX56 2004 Factory Service Manual RSU-40 REAR LOWER LINK & COIL SPRING Revision: August 20072004 QX56 8. Remove the rear lower link adjusting bolt and nut from the rear suspension member using power tool, then remove the rear lower li

Page 2900 of 3371

INFINITI QX56 2004 Factory Service Manual STABILIZER BAR RSU-41 C D F G H I J K L MA B RSU Revision: August 20072004 QX56 STABILIZER BARPFP:56230 Removal and Installation EES0011R REMOVAL 1. Disconnect the stabilizer bar ends from the connect

Page 2901 of 3371

INFINITI QX56 2004 Factory Service Manual RSU-42 REAR LOAD LEVELING AIR SUSPENSION COMPRESSOR ASSEMBLY Revision: August 20072004 QX56 REAR LOAD LEVELING AIR SUSPENSION COMPRESSOR ASSEMBLYPFP:53400 Removal and InstallationEES0011T Rear Load Le

Page 2902 of 3371

INFINITI QX56 2004 Factory Service Manual REAR LOAD LEVELING AIR SUSPENSION COMPRESSOR ASSEMBLY RSU-43 C D F G H I J K L MA B RSU Revision: August 20072004 QX56 5. Remove the four bolts that mount the rear load leveling air sus- pension compr

Page 2903 of 3371

INFINITI QX56 2004 Factory Service Manual RSU-44 HEIGHT SENSOR Revision: August 20072004 QX56 HEIGHT SENSORPFP:53820 Removal and InstallationEES0011U Rear Load Leveling Air Suspension System REMOVAL 1. Use CONSULT-II “EXHAUST SOLENOID” ac

Page 2904 of 3371

INFINITI QX56 2004 Factory Service Manual HEIGHT SENSOR RSU-45 C D F G H I J K L MA B RSU Revision: August 20072004 QX56 INSTALLATION Installation is in the reverse order of removal. 1. Start the engine. 2. Use CONSULT-II to perform "STANDARD
