Page 3249 of 3371

INFINITI QX56 2004 Factory Service Manual TF-124 CENTER CASE Revision: August 20072004 QX56 OIL FILTER 1. Remove bolts for oil filter. 2. Remove the oil filter using suitable tool as shown. 3. Remove the O-rings (1) from the oil filter (2). 4

Page 3250 of 3371

INFINITI QX56 2004 Factory Service Manual FRONT CASE TF-125 C E F G H I J K L MA B TF Revision: August 20072004 QX56 FRONT CASEPFP:33107 DisassemblyEDS00190 1. Remove rear case from center case. Refer to TF-112, "Disassembly" . 2. Remove the

Page 3251 of 3371

INFINITI QX56 2004 Factory Service Manual TF-126 FRONT CASE Revision: August 20072004 QX56 2. Remove shift rod components together with 2-4 sleeve and L-H sleeve. 3. Remove the shift cross from the front case. 4. Remove 2-4 sleeve and L-H sle

Page 3252 of 3371

INFINITI QX56 2004 Factory Service Manual FRONT CASE TF-127 C E F G H I J K L MA B TF Revision: August 20072004 QX56 PLANETARY CARRIER, SUN GEAR AND INTERNAL GEAR 1. Remove oil seal from the front case, using suitable tool. CAUTION: Be carefu

Page 3253 of 3371

INFINITI QX56 2004 Factory Service Manual TF-128 FRONT CASE Revision: August 20072004 QX56 5. Remove the sun gear assembly from the planetary carrier assembly. 6. Remove the snap ring from the sun gear assembly, using suit- able tool. NOTE: D

Page 3254 of 3371

INFINITI QX56 2004 Factory Service Manual FRONT CASE TF-129 C E F G H I J K L MA B TF Revision: August 20072004 QX56 9. Remove the metal bushing from the sun gear, using suitable Tool. 10. Remove snap ring, and remove internal gear. 11. Remov

Page 3255 of 3371

INFINITI QX56 2004 Factory Service Manual TF-130 FRONT CASE Revision: August 20072004 QX56 13. Remove the mainshaft front bearing from the front case, using Tool. Tool number : ST33200000 (J-26082) SDIA2178E

Page 3256 of 3371

INFINITI QX56 2004 Factory Service Manual FRONT CASE TF-131 C E F G H I J K L MA B TF Revision: August 20072004 QX56 FRONT CASEPFP:33107 InspectionEDS00191 PLANETARY CARRIER Measure end play of each pinion gear, and make sure the mea- sureme
